Dacor Modernist Prorange Bedienungsanleitung
Installation Instructions
Modernist Prorange
DOP36M96GL*
Install_NX9900R_PRORANGE_DOP36M96_DA_DG68-01106C-00_EN+MES+CFR.indb 1 2019-02-15 5:46:13
English2
Contents
Contents
Before you begin 4
Important 4
About this manual 5
Important note to the installer 5
Important note to the consumer 5
Important note to the servicer 5
Customer service information 6
Important safety instructions 7
Read all instructions before using this appliance 8
Symbols used in this manual 8
Product specifications 21
What's in the box 21
Installation requirements 23
Pre-installation checklist 23
General requirements 23
Location requirements 27
Gas requirements 29
Special gas requirements (gas models sold in Massachusetts) 30
Electrical requirements 31
Installation instructions 32
Preparing for installation 32
Installing the knobs for surface burners 43
Cooktop assembly 44
Verifying proper operation 47
Removal and Re-installation 48
Installation checklist 49
Install_NX9900R_PRORANGE_DOP36M96_DA_DG68-01106C-00_EN+MES+CFR.indb 2 2019-02-15 5:46:13
English 3
WARNING: Failure to follow the instructions in this manual exactly
may cause a fire or explosion, and, consequently, property damage,
personal injury, or death.
• DO NOT keep or use gasoline or other flammable products near
this appliance.
• IF YOU SMELL GAS:
- DO NOT light any appliances.
- DO NOT touch any electrical switches.
- DO NOT use any phone in your building.
- Immediately call your gas supplier from a neighbor's phone,
and follow the supplier's instructions. (If you cannot reach
your gas supplier, call the fire department.)
• Installation and service must be performed by a qualified
installer, service agency, or the gas supplier.
Install_NX9900R_PRORANGE_DOP36M96_DA_DG68-01106C-00_EN+MES+CFR.indb 3 2019-02-15 5:46:13
English4
Contents
Before you begin
Important
• The overall design and/or accessories may
differ with the model.
Installer
• To promote safety and minimize
problems, read this manual thoroughly
before starting the installation. Leave
this manual with the user.
• Write the appliance’s model/serial
numbers in this manual for service/
maintenance reference.
User
• Keep this manual for personal and
professional reference.
Install_NX9900R_PRORANGE_DOP36M96_DA_DG68-01106C-00_EN+MES+CFR.indb 4 2019-02-15 5:46:13
English 5
Before you begin
About this manual
READ THESE INSTRUCTIONS COMPLETELY AND CAREFULLY.
Important note to the installer
• Read all instructions contained in these installation instructions before installing the
range.
• Remove all packing materials from the cooktop compartments before connecting the
electric and gas supply to the range.
• Observe all governing codes and ordinances.
• Be sure to leave these instructions with the consumer.
• Installation of this appliance requires basic mechanical skills.
• Proper installation is the responsibility of the installer.
• Product failure due to improper installation is not covered under the Warranty.
Important note to the consumer
Keep these instructions with your user manual for future reference.
• As when using any appliance generating heat, there are certain safety precautions you
should follow.
• Be sure your range is installed and grounded properly by a qualified installer or
service technician.
• Make sure the wall coverings around the range can withstand the heat generated by
the range.
• Cabinet storage space above the cooktop burners should be a minimum of 30 in
(76.2 cm).
Important note to the servicer
The electrical diagram is in an envelope attached to the back of the range.
Install_NX9900R_PRORANGE_DOP36M96_DA_DG68-01106C-00_EN+MES+CFR.indb 5 2019-02-15 5:46:13
English6
Customer service information
Customer service information
This section should appears as follows:
For installation issues, contact your Dacor dealer or Dacor Customer Assurance. Have
available the appliance's model and serial numbers. (See the graphic below for location.)
Dacor Customer Assurance
Phone: 833-35-ELITE (833-353-5483) USA, Canada
Mon – Fri, 5:00 a.m. to 5;00 p.m. Pacific Time
Model and Serial Number Location
Install_NX9900R_PRORANGE_DOP36M96_DA_DG68-01106C-00_EN+MES+CFR.indb 6 2019-02-15 5:46:13
English 7
Important safety instructions
Important safety instructions
ANTI-TIP DEVICE
WARNING
ALL RANGES CAN TIP, RESULTING IN PERSONAL INJURY.
TIPPING RANGES CAN CAUSE BURNS FROM SPILLS,
PERSONAL INJURY, AND/OR DEATH.
INSTALL AND CHECK THE ANTI-TIP BRACKET FOLLOWING
THE INSTRUCTIONS AND TEMPLATE SUPPLIED WITH THE
BRACKET.
• To prevent accidental tipping of the range, attach an approved
anti-tip device to the floor. (See Installing the Anti-Tip Device
in the Installation Instructions.) Check for proper installation by
carefully tipping the range forward. The anti-tip device should
engage and prevent the range from tipping over.
• If the range is pulled out away from the wall for any reason, make
sure the anti-tip device is reengaged after the range has been
pushed back into place.
• Follow the installation instructions found in the Installation
Manual. Failure to follow these instructions can result in death,
serious personal injury, and / or property damage.
• DO NOT step / sit / lean on the door or drawer to prevent
accidental tipping of the range.
Install_NX9900R_PRORANGE_DOP36M96_DA_DG68-01106C-00_EN+MES+CFR.indb 7 2019-02-15 5:46:14
Important safety instructions
English8
Important safety instructions
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE
• Electrical and gas equipment with moving parts can be dangerous. The important
safety instructions in this manual are intended to minimize the risk of property
damage, personal injury, and death. Be sure to read them.
• Keep this manual in a handy place so you can refer to it as needed.
Symbols used in this manual
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in electric shock, personal injury, or property
damage.
NOTE
Useful tips and instructions.
These warning icons and symbols are intended to prevent property damage and personal
injury. Follow them explicitly.
Install_NX9900R_PRORANGE_DOP36M96_DA_DG68-01106C-00_EN+MES+CFR.indb 8 2019-02-15 5:46:14
English 9
Important safety instructions
California Proposition 65 Warning
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
Commonwealth of Massachusetts
This product must be installed by a licensed plumber or gas fitter qualified or licensed by
the State of Massachusetts. When using ball-type gas shut-off valves, you must use the
T-handle type. Multiple flexible gas lines must not be connected in series.
General safety
WARNING
To reduce the risk of fire, electric shock, personal injury, or death, observe these
precautions:
• Do not touch any surface, component,
or mechanism of the product during or
immediately after cooking.
• Learn where and how to open/close the
range's gas valve.
• Make sure the anti-tip device is properly installed. (See the Installation Instructions for
details.)
• Do not let children sit/stand on the product or play with any of its parts. Do not leave
children unattended in the kitchen when the product is in use.
• Remove all packaging before operating the product to keep this material from catching
fire. Keep all packaging away from children. Properly dispose of packaging as soon as
the product is unpacked.
• Do not keep objects of interest to children on or around the product.
• Do not operate the product if it is damaged in any way, if it malfunctions, or is missing
parts.
• Do not use the product as a space heater. This product is to be used for cooking
purposes only.
• Do not use oven cleaners or oven liners in or around any part of the oven.
Install_NX9900R_PRORANGE_DOP36M96_DA_DG68-01106C-00_EN+MES+CFR.indb 9 2019-02-15 5:46:14
Important safety instructions
English10
Important safety instructions
• Use only dry pot holders.
• Do not use the product to heat unopened food containers.
• Do not strike the oven glass.
• When disposing of the range, cut off the power cord and remove the door.
• Unplug the product before service/maintenance.
• Make sure all meat and poultry is cooked thoroughly. Meat should always be cooked
to an internal temperature of 160 °F (71 °C). Poultry should always be cooked to an
internal temperature of 180 °F (82 °C).
• An air curtain or other overhead range hood, which operates by blowing a downward
airflow onto a range, shall not be used in conjunction with a gas range unless the
hood and range have been designed and tested in accordance with the Standard
for Domestic Gas Ranges, ANSI Z21.1 • CSA1.1, and listed by an independent testing
laboratory for combination use.
Air Sled Insert
• Due to the weight, heavy equipment
movers such as Air Sled should be used
to move this unit. The weight must be
supported uniformly across the bottom.
After transporting the range by Air
Sled where you want, the range can
be leveled by adjusting the legs with a
wrench while Air Sled is supported.
WARNING
NEVER use this appliance as a space heater to heat or warm the room. Doing so may
result in carbon monoxide poisoning and overheating of the oven.
Install_NX9900R_PRORANGE_DOP36M96_DA_DG68-01106C-00_EN+MES+CFR.indb 10 2019-02-15 5:46:15
