Daewoo DTY-25G1 Bedienungsanleitung

Instruction Manual

Colour Television

DTY-25G1

DTY-29G1

Important Safeguards

For your protection, please read these safety instructions completely before operating the appliance, and

keep this manual for future reference.

Carefully observe all warnings, precautions, and instructions on the appliance, or the one described in the

operating instructions and adhere to them.

USE

INSTALLATION

Power Sources - This set should be operated only

from the type of power source indicated on the

marking label.

Overloading - Do not overload wall outlets, exten-

sion cords or convenience receptacles beyond their

capacity, since this can result in fire or electric

shock.

Alternate Warning - For the set with a three-wire

grounding type AC plug.

This plug will only fit into a grounding type power

outlet. This is a safety feature. lf you are unable to

insert the plug into the outlet contact your electrician

to have a suitable outlet installed. Do not defeat the

safety purpose of the grounding plug.

Object and Liquid Entry - Never push objects of

any kinds into the set through openings as they may

touch dangerous voltage points or short-out parts

that could result in a fire or electric shock. Never spill

liquid of any kind on the set

Attachments - Do not use attachments not recom-

mended by the manufacturer, as they may cause

hazards.

Cleaning - Unplug the set from the wall outlet before

cleaning it. Do not use liquid cleaners or aerosol

cleaners. Use a cloth lightly dampened with water

for cleaning the exterior of the set.

Voltage?

UNPLUG

Water and Moisture - Do not use power-line oper-

ated sets near water for example, near a bathtub,

washbowl, kitchen sink, or laundry tub, in a wet

basement, or near a swimming pool.

lf you pour a cold liquid into a glass, water vapor in

the air will condense on the surface of the glass.

This is moisture condensation. Moisture condensa-

tion on the head drum, one of the most crucial

parts of the Video recorder, will cause damage to

the tape. Whenever the Video recorder is exposed

to extreme cold and heat at the time, some conden-

sation will occur. When moisture is present, turn the

power switch on, and allow at least 2 hours for the

Video recorder to dry out.

Accessories - Do not place the set on an unstable

cart, stand, tripod, bracket, or table. The set may fall,

causing serious injury to a child or an adult, and seri-

ous damage to the set. Use only a cart stand tripod,

bracket, or table recommended by the manufactur-

er.

Ventilation - These slots and openings in the cabi-

net are provided for necessary ventilation. To ensure

reliable operation of the set, and to protect if from

overheating, these slots and openings must not be

blocked or covered.

- Never cover the slots and openings with a cloth

or other materials.

- Never block the slots and openings by placing

the set on a bed, sofa, rug or other similar sur-

face.

- Do not allow anything to rest on the power cord.

Do not locate this television equipment where

the cord will be abused by persons walking on

it.

Portable Cart warning - An appliance and cart

combination should be moved with care. Quick

stops, excessive force, and uneven surfaces may

cause the appliance and cart combination to

overturn.

- Never place the set in a confined space such as a

bookcase, or built-in cabinet, unless proper ven-tila-

tion is provided.

Power-Cord Protection - Route the power cord so

that it is not likely to be walked on or pinched by items

placed upon or against them, paying particular atten-

tion to the plugs, receptacles, and the point where the

cord exits from the appliance.

- Do not place the set near, over a radiator or heat reg-

ister, or where it is exposed to direct sunlight.

Lightning-For protection for this set during a light-

ning storm, or when it is left unattended and

unused for long periods of time, unplug it from

the wall outlet. This will prevent damage to the

set due to lightning and power-line surges.

POWERLINE EXPOSURE

Damage Requiring Service - Unplug the set

from the wall outlet and refer servicing to quali-

fied service personnel under the following condi-

tions:

- When the power cord or plug is damaged or

frayed.

- lf liquid has been spilled or objects have

fallen into the set.

- lf the set has been subject to excessive shock

by being dropped, or the cabinet has been dam-

aged.

- lf the set does not operate normally when fol-

lowing the operating instructions. Adjust only

those controls that are specified in the operating

instructions. lmproper adjustment of other con-

trols may result in damage and will often require

extensive work by a qualified technician to

restore the set to normal operation.

- When the set exhibits a distinct change in

performance-this indicates a need for

service.

Servicing - Do not attempt to service the set

yourself as opening or removing covers may

expose you to dangerous voltage or other haz-

ards.

Refer all servicing to qualified service personnel.

Replacement parts - When replacement parts

are required, be sure the service technician has

used replacement parts specified by the manu-

facturer that have the same characteristics as the

original parts. Unauthorized substitutions may

result in fire, electric shock, or other hazards.

Safety Check - Upon completion of any service

or repairs to the set, ask the service technician to

perform routine safety checks (as specified by

the manufacturer) to determine that the set is in

safe operating condition.

FRAYED OR CUT

-AC LINE

CRACKED PLUG.

SERVICE

CONTENTS

* Important safeguards 1

* Identity of features on Local and Remote Control 5

* Installation 6

After moving the set 6

Inserting Batteries into the Remote Control Unit 6

Aerial connection 6

Mains connection 7

Switching the set on and off 7

Tuning the TV Channels 8

Edit 8

Manual Channel Setting 9

* Daily use 10

Selecting a Programme Number 10

Volume, Picture and Sound control 10

Timer 11

Sleep 11

Recall 11

Child Lock 12

Time 12

Mode 12

* Teletext 13

* Connecting the External Equipment 15

* Troubleshooting 16

* Specification 17

IDENTITY OF FEATURES ON LOCAL AND REMOTE CONTROL

LOCAL CONTROL

REMOTE CONTROL

AV1 AV2

VIDEO

AUDIO

L R

Front

MAIN

POWER

BUTTON

VIDEO

INPUT HEAD

PHONE STAND-BY

INDICATOR REMOTE

SENSOR AV

BUTTON VOLUME

DOWN/UP

BUTTONS

PROGRAMME

DOWN/UP

BUTTONS

SCART

SOCKET1 SCART

SOCKET2

AERIAL

TERMINAL

Back

AUDIO

INPUT

SLEEP RECALL

SKIPMOVEDEL

TIME MODE

NORMAL

123

456

TELETEXT mode

POWER

NUMBER 0-9

Not Used

PAGE UP

SUBPAGE

INDEX

PAGE DOWN

HOLD

MUTE

REVEAL

SIZE

CANCEL

G (VOLUME UP)

R (VOLUME DOWN)

C (BRIGHT UP)

Y (BRIGHT DOWN)

TV mode

POWER

NUMBER 0-9

PR (CURSOR)UP

VOLUME UP (CURSOR RIGHT)

OK(NORMAL)

PR(CURSOR) DOWN

VOLUME DOWN(CURSOR LEFT)

MUTE

RECALL

SLEEP

SKIP

MOVE

DELETE

TELETEXT

Audio MODE

TIME

INSTALLATION

If the used set is moved or placed in a different direction, the

MAIN POWER button must be switched off for at least 15 min-

utes in order to take out a colour strain on the screen.

AFTER MOVING THE SET

Press down the battery compartment grip and slide the cover,

Insert the batteries supplied(two 1.5v, type AA).

Make sure that the polarity matches with the (+) and (-) marks

inside of the battery compartment.

Used batteries should be disposed of properly.

INSERTING BATTERIES INTO THE REMOTE CONTROL UNIT

For better picture and sound quality, an effective aerial installa-

tion is the most important.

If you are located in a relatively strong area, you will be able to

use the indoor aerial.

When using an outdoor aerial, it is usually connected to the set

by means of 75 ohm coaxial cable.

AERIAL CONNECTION

- The appliance is not intended for use by young children

or infirm persons without supervision;

- Young children should be supervised to ensure that

they do not play with the appliance.

Plug the mains cable into the power socket with 240V~, 50Hz.

MAINS CONNECTION

Switching On

Switch the set on with the MAIN POWER button, ( ). The set will turn on.

If not, press either : - PR UP or DOWN button on the front of set - or POWER button or the

UP/DOWN buttons or one of the NUMBER buttons 0..9 on the remote controller.

The STAND-BY INDICATOR will turn off and a picture will appear on the screen.

Switching off

Press POWER button ( ) on the remote controller to return the set to its stand-by mode.

The STAND-BY INDICATOR will illuminate.

If you don't use the set for extended period of time, turn it off with MAIN POWER button .

SWITCHING THE SET ON AND OFF

Warning: This television has been factory pretuned to channels 2, 7, 9, 10 and 28. If

the auto search function is activated, these preset channels will be deleted

and new channels tuned to 1, 2, 3 etc..

MAIN MENU

Press the MENU button to call up the MAIN MENU.

The MAIN MENU is consist of 6 sub-menus:

PICTURE, SOUND, TIMER, LANGUAGE, PRESET, EDIT

menu.

LANGUAGE SELECTION

Select a LANGUAGE menu at the MAIN MENU by placing the

cursor on the LANGUAGE with UP/DOWN buttons and press-

ing the OK button. You can choose language you require with

UP/DOWN buttons.

Press the MENU button to return to the MAIN MENU.

AUTOMATIC TUNING SYSTEM

Select the PRESET menu at the MAIN MENU.

Place the cursor to " " with the RIGHT button.

Press and hold down OK button until the tuning screen

appears above the PRESET menu.

The cursor will move from left to right on the VHF-L line, then

VHF-H, then UHF.

Please wait until EDIT MENU appears.

TUNING THE TV CHANNELS

The EDIT menu shows you the programme position assignment.

You can change this programme position assignment accord-

ing to your personal preferences.

SKIPPING THE CHANNELS

You can select SKIP "YES" or "NO" with the SKIP button.

A programme marked with SKIP "YES" is skipped when

changing channel using the UP/DOWN buttons. A skipped

programme number selected by NUMBER buttons 0..9 will be

displayed in red.

DELETE PROGRAMME POSITION DATA

Position the cursor to programme number to delete with the

UP/DOWN, LEFT/RIGHT buttons.

Press the DEL button. While this is being carried out the

"DELETE" Prog. No." appears and the "deleted" programme is

moved to the programme No. 69 and changed SKIP "YES".

The programme located in the programme No. 69 will move to

the programme No. 68.

CHANGING THE ORDER OF THE CHANNELS

Position the cursor to programme number to move and press

the MOVE button. The "MOVE Prog. No." will appear.

Position the cursor to programme number to exchange and

press the MOVE button. Two programmes will be exchanged.

ENTER A STATION NAME, CHANGING THE PROGRAMME

NUMBER AND COPYING A PROGRAMME

You can go to the PRESET menu directly for entering a station

name and changing the programme number and copying a

programme to another programme No. by pressing the OK

button.

Refer to the MANUAL CHANNEL SETTING.

EDIT

MAIN MENU

LANGUAGE


SOUND

TIMER

LANGUAGE

PRESET

EDIT

00 - - - - NO

01 - - - - NO

02 - - - - NO

03 - - - - NO

04 - - - - NO

P SKIP P SKIP

05 - - - - NO

06 - - - - YES

07 - - - - NO

08 - - - - NO

09 - - - - NO

AUTO SEARCH UHF >>

EDIT

00 - - - - NO

01 - - - - NO

02 - - - - NO

03 - - - - NO

04 - - - - NO

P SKIP

DELETE 01

P SKIP

05 - - - - NO

06 - - - - NO

07 - - - - NO

08 - - - - NO

09 - - - - NO

EDIT

00 ARD NO

01 ZDF NO

02 BR3 NO

03 SAT1 NO

04 PR07 NO

P SKIP

MOVE 06

P SKIP

05 RTL2 NO

06 - - - - NO

07 - - - - NO

08 - - - - NO

09 - - - - NO

EDIT

ENGLISH

FRANCAIS

DEUTSCH

ITALIANO

ESPA„OL

PRESET

P01 P

PRESET

P01 P

You can also call up the PRESET menu at the MAIN MENU.

Press the NUMBER buttons 0..9 or UP/DOWN buttons to

select a programme number you want.

The screen will change according to the selected programme

number.

SEARCHING A CHANNELS

Locate a cursor to “ ” with LEFT/RIGHT buttons and then

press the UP or DOWN button.

The tuning screen will appear and the cursor will move from

left to right or right to left.

Pressing and holding down the UP/DOWN buttons during 2

seconds, the band will change as follows:

VL-VH-U (For GB, U only).

After searching a station, the tuning screen will disappear.

To stop searching, press the MENU button.

FINE TUNING

If you are unable to get a good picture or sound because of a

poor broadcasting signal, it is possible to adjust the fine tuning.

Move the cursor to and press UP or DOWN button to

activate fine tuning up or down.

It only operates while the UP or DOWN button is being

pressed.

ENTER A STATION NAME

Select station name in the station name list with UP/DOWN

buttons and press OK button.

If you want to delete a station name, select "----".

If you can't find the desired name in the list, you can enter your

own.

To do so, move the cursor to the right and press OK button.

Using the UP/DOWN buttons, select the desired letter, number

or blank.

Press the RIGHT button to select the next position.

Press the OK button to complete this procedure.

TO STORE PROGRAMME IN MEMORY

Move the cursor to the right end with the LEFT/RIGHT buttons.

Select the programme number that you want to store current

displaying programme with station name, fine tuning data

using the UP/DOWN buttons or NUMBERS 0..9.

Press the OK button.

MANUAL CHANNEL SETTING

PRESET

P01 P

SEARCH UHF >>

PRESET

P01 P

FINE TUNE UHF >

PRESET

P01 P

PRESET

P01 BBC1 P

PRESET

P01 BBC1 P02

- - - -

DRFS

BBC1

BBC2

ITU

CH4

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Daewoo Fernseher Handbücher

Daewoo

Daewoo DTT-3250MT Bedienungsanleitung

Daewoo

Daewoo DTH-29MS Bedienungsanleitung

Daewoo

Daewoo DTH-20D5FS Bedienungsanleitung

Daewoo

Daewoo DTB Series Bedienungsanleitung

Daewoo

Daewoo DTH-211F Bedienungsanleitung

Daewoo

Daewoo DTQ-19V6FCB Bedienungsanleitung

Daewoo

Daewoo DTQ 13P2FC Bedienungsanleitung

Daewoo

Daewoo DTQ-27U1SC Bedienungsanleitung

Daewoo

Daewoo DTQ 26S1FC Bedienungsanleitung

Daewoo

Daewoo E2019B Bedienungsanleitung

Daewoo

Daewoo DTA - 14C4TFF Bedienungsanleitung

Daewoo

Daewoo DTQ-29U9FS Bedienungsanleitung

Daewoo

Daewoo DTY-2896 TF Bedienungsanleitung

Daewoo

Daewoo DTQ-14U1FS/20U1FS Bedienungsanleitung

Daewoo

Daewoo DTR-14D9ME Bedienungsanleitung

Daewoo

Daewoo DTA-14C4TFF Bedienungsanleitung

Daewoo

Daewoo DTQ 13V6FC Bedienungsanleitung

Daewoo

Daewoo DTC-29M5ME Bedienungsanleitung

Daewoo

Daewoo DTH-291F Bedienungsanleitung

Daewoo

Daewoo CP-520 Bedienungsanleitung

Daewoo

Daewoo DTD-14D3 ME Bedienungsanleitung

Daewoo

Daewoo DTH-25G1FST/FSP/FS Bedienungsanleitung

Daewoo

Daewoo DTE-28 Series Bedienungsanleitung

Daewoo

Daewoo KR14E5/DTA-14V3VM Bedienungsanleitung

Beliebte Fernseher Handbücher anderer Marken

Philips

Philips Colour Television Bedienungsanleitung

Toshiba

Toshiba 27A10 Bedienungsanleitung

Philips

Philips 42PF9630A/37 Bedienungsanleitung

Hitachi

Hitachi 32FX48B Bedienungsanleitung

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Bedienungsanleitung

Changhong Electric

Changhong Electric uhd55b6000is Bedienungsanleitung

Philips

Philips Matchline 21CE7551 Bedienungsanleitung

Panasonic

Panasonic Genus TX-G10 Bedienungsanleitung

Toshiba

Toshiba 19A20 Bedienungsanleitung

Philips

Philips 25PT4523-16 Bedienungsanleitung

Sony

Sony XBR-100Z9D Bedienungsanleitung

Philips

Philips PR0930X3 Bedienungsanleitung

Philips

Philips Brilliance 231P4QPY Bedienungsanleitung

Samsung

Samsung 55S9 B Series Bedienungsanleitung

Philips

Philips 32HF9385D Fehlerbehebungshandbuch

Sharp

Sharp LC-40FI5012E Bedienungsanleitung

Loewe

Loewe Table Stand Reference 55 Bedienungsanleitung

Philips

Philips 32PFH5300 Bedienungsanleitung
