Daikin ACEF 3AVE Bedienungsanleitung

Service

Manual

SiE00-06

Air Cleaners

ACEF 3AVE

SiE00-06

Table of Contents i

Air Cleaners

ACEF 3AVE

1. Safety Cautions......................................................................................iii

1.1 Cautions and Warnings...........................................................................iii

1.2 Using Icons.............................................................................................. v

1.3 Using Icons List....................................................................................... v

Part 1 Information.........................................................................1

1. General Description ................................................................................2

1.1 Introduction of Functions.........................................................................2

1.2 Accessories.............................................................................................3

1.3 Tips for Appropriate Use.......................................................................... 4

2. Names and Functions of The Operating Section....................................5

2.1 Names and Functions of Parts................................................................5

3. Names and Functions of The Indicator Lamps .......................................6

3.1 Indicator Lamps and Their Functions......................................................6

Part 2 Field Setting .......................................................................7

1. Setup and Installation..............................................................................8

1.1 Setup.......................................................................................................8

1.2 Installation ............................................................................................. 10

2. Operation of The Unit............................................................................11

2.1 How to Operate The Unit.......................................................................11

Part 3 Maintenance.....................................................................13

1. Cleaning of Prefilter and Ionizer............................................................14

1.1 Prefilter..................................................................................................14

1.2 Ionizer....................................................................................................15

2. Changing The Ion Filter (Roll)...............................................................16

2.1 How to Change The Ion Filter (Roll)......................................................16

Part 4 Troubles ooting ...............................................................19

1. Troubleshooting ....................................................................................20

1.1 Equipment does not Operate.................................................................20

1.2 Indicator does not Change from "Dirty" to "Clean."...............................22

1.3 Remote Controller Fails to Operate Equipment..................................... 23

1.4 Photocatalytic Operation does not Activate...........................................24

SiE00-06

ii Table of Contents

Part 5 Removal Procedure..........................................................25

1. Removal Procedure of ACEF3AVE.......................................................26

1.1 Removal of External Accessories..........................................................26

1.2 Removal of Ionizing Wire....................................................................... 29

1.3 Removal of Electrical Parts (Inverter Lamp).......................................... 30

1.4 Removal of PCB....................................................................................33

1.5 Removal of Fan Motor...........................................................................36

1.6 Removal of Safety Switch...................................................................... 38

1.7 Installation of Power Cable....................................................................39

Part 6 Reference Data ................................................................41

1. Optional Accessories ............................................................................42

1.1 Specifications ........................................................................................ 42

2. Wiring Diagram .....................................................................................43

2.1 ACEF3AVE............................................................................................43

3. Parts List...............................................................................................44

3.1 Parts Illustration.....................................................................................44

3.2 Parts List................................................................................................ 45

Index .............................................................................................i

Drawings & Flow C arts ...............................................................iii

SiE00-06 Safety Cautions

iii

1. Safety Cautions

1.1 Cautions and Warnings

Read the following warnings and cautions BEFORE operating the system and use it correctly.



This manual classifies the precautions to the user into the following two categories.

Each mention important cautions on safety, so be sure to keep them.

WARNING Failure to follow a warning is very likely to result in such grave consequences as death or serious

injury.

CAUTION Failure to follow a caution may result in serious injury or property damage, and in certain

conditions, may result in a grave consequence.



The pictograms in the text show the following meanings.

Absolutely prohibited

Be sure to operate following instructions

Be sure to unplug the power cable



After reading, keep this manual in a place where the actual user can see it whenever necessary. And in

case of changing user, be sure to hand it to the new user.

Warning

Do not disassemble, service or

modify this equipment.

Unwarranted tempering can lead to fire

and/or malfunction.

Do not operate the equipment with

wet hands.

Otherwise electrical shock can result.

Use only 220-240 VAC 50 Hz power

supply.

Otherwise fire and electrical shock can

result.

Do not use the power cable if it is

damaged.

Using a damaged power cable is

extremely hazardous; if the power cord

becomes damaged, you must obtain a

replacement from the manufacturer or

from a properly-authorized service

agent.

Before changing filters, cleaning the

equipment or moving it, turn it OFF

and unplug the power cable.

Working with power ON can lead to fire

and/or electric shock.

Do not use the power cable if

damaged or loose in the socket.

Using the power cable in anything but

proper working condition can lead to

short-circuits and subsequently electric

shock and/or fire.

Safety Cautions SiE00-06

Caution

Do not use the equipment in a place

filled with oily smoke such as a

kitchen or in a place filled with

combustible gas, corrosive gas or

metal dust.

Otherwise fire and equipment

malfunction can result.

Do not use in humid places or places

which might be wet, such as

bathrooms.

Contact with

water can lead to

electric shock or

damage the

equipment.

Do not use the equipment near a

lighting fixture (keep a distance of at

least 1 m).

Lighting equipment

can cause poor

reception of remote

controller signals

and equipment

discoloration.

Do not use outdoors or where

exposed to direct sunlight.

Direct sunlight can

weaken remote

control signal

reception sensitivity

and discolor the

casing.

Do not use near to sources of heat

such as heaters.

Heat can discolor and deform the

casing.

Keep the unit and remote control

minimum 1 m from lighting, TVs,

radios, stereos and aerials.

This unit can disturb TV

pictures and generate

interference. Illumination can

weaken remote control signal

reception sensitivity and discolor the

casing.

Keep the equipment 10 cm or more

away from the wall when used on a

table.

Otherwise the wall can become dirty.

Do not use in the place of kitchen

fans or cooker hood fans.

Adverse coditions of use can shorten

service-life of the prefilter and ion filter,

as well as lead to equipment damage.

Prevent combustibles (hair sprays,

etc.), sparks and incense from being

drawn into the unit.

Such substances can cause fire.

Do not insert fingers or objects into

the openings of the suction and

discharge grilles.

Otherwise

electrical shock

and equipment

malfunction can

result.

When used in conjunction with a

humidifier, keep mist from being

directly drawn into the unit.

Mists can lead to electric shock and/or

equipment damage.

Do not block the intake or outlet.

Blocked openings can

reduce capacity (air will

not be cleaned throughout

the entire room) and/or

damage the equipment.

SiE00-06 Safety Cautions

1.2 Using Icons

Icons are used to attract the attention of the reader to specific information. The meaning of each icon is

described in the table below:

1.3 Using Icons List

Do not place water containers such

as fish bowls and flower vases near

the equipment.

Water can cause electrical shock and

equipment malfunction when it enters

the equipment.

Do not wipe with benzene or thinner,

or spray with insecticide.

Such substances

can cause

cracking, electric

shock and/or fire.

If not using the unit for long periods

of time, unplug the power cable.

Dielectric breakdown can lead to

leakage current and subsequently

electric shock and/or fire.

Hold the plug to unplug the power

cord from the AC outlet. Do not pull

the cord to unplug.

Otherwise electrical

shock can result or

sparks may be

generated due to

shorting.

Do not operate the equipment without

the prefilter or roll filter.

Operating the equipment without the

filter can result in equipment

malfunction.

Do not sit or stand on the equipment.

Otherwise equipment malfunction can

result.

Do not position the equipment on its

side or tilt it during use.

Otherwise equipment

malfunction can

result.

Ventilate the room frequently when

used together with a heating device.

This product does not remove carbon

monoxide. Insufficient ventilation can

result in carbon monoxide poisoning.

Caution

Icon Type of

Information Description

Note:

Note A “note” provides information that is not indispensable, but may

nevertheless be valuable to the reader, such as tips and tricks.

Caution

Caution A “caution” is used when there is danger that the reader, through

incorrect manipulation, may damage equipment, loose data, get an

unexpected result or has to restart (part of) a procedure.

Warning

Warning A “warning” is used when there is danger of personal injury.

Reference A “reference” guides the reader to other places in this binder or in this

manual, where he/she will find additional information on a specific topic.

Safety Cautions SiE00-06
