Danfoss FP715Si Bedienungsanleitung

FP715Si

Electronic 2-Channel Full Programmer for

Heating and Hot Water with Service Interval Timer

Installation Guide

Danfoss Heating

MAKING MODERN LIVING POSSIBLE

FP715SI

For a large print version of these instructions

please call Marketing on 0845 121 7400.

Danfoss can accept no responsibility for possible errors in catalogues, brochures, and other

printed material. All trademarks in this material are property of the respective companies.

Certification Mark

Danfoss Heating 3

FP715Si

Electronic 2-Channel Full Programmer for

Heating & Hot Water with Service Interval Timer

Index

1.0 Installation Overview..............................................................................4

2.0 Product Speciﬁcation..............................................................................4

3.0 Installation

3.1 Wiring.....................................................................................................5

3.2 DIL Switch Settings ...........................................................................6

4.0 Advanced Programming Options .....................................................6

5.0 Copy Functions Explained ....................................................................7

6.0 Service Interval Timer .............................................................................9

7.0 Wiring Conversions .........................................................................10-17

FP715SI

Speciﬁcation 230V model 24V model

Power supply

230 Vac,

±15%,

50/60 Hz

24 Vac,

±15%,

50/60 Hz

Switching action

2 x SPDT internally linked, Type 1B

Unit switch rating 230 Vac, 3(1)A 24 Vac, 3(1)A

Battery back-up 24 hours minimum

Programme resolution ± 1 minute

Dimensions, mm (W, H, D) 135 x 88 x 32

Design standard EN 60730-2-7

Control Pollution Situation Degree 2

Rated Impulse Voltage 2.5 kV

Ball Pressure Test 75°C

• Remove wallplate from unit by unscrewing the two screws on the

bottom edge of the unit.

• From the top left hand corner of the wallplate, there must be

clearances of at least 140 mm to the right, 15mm to the left,

30mm above and 100mm below in order to mount the plug-on

module.

1.0 Installation Overview

2.0 Product Speciﬁcation

Please Note:

This product should only be installed by a qualiﬁed electrician or

competent heating installer and should be in accordance with the

current edition of the IEEE wiring regulations.

3.0 Installation

Danfoss Heating 5

NL1234

230V

Fused

OFF

DHW

OFF

HTG

DHW

HTG

ELECTRONICS

N/O

N/C

N/O

N/C

• The wallplate must be securely mounted either directly to the

wall using suitable wood screws or to a ﬂush mounted 1-gang

electrical accessory box using M3.5 screws.

• Cable access can either be from behind for concealed cabling, or

from below for surface cabling. If surface cable is used, cut out

cable access slot on plug-on module prior to mounting.

• For wiring connections refer to diagram below.

FP715 Si models are double insulated and do not require an

earth connection, however a parking terminal is provided on the

wallplate. This is clearly marked with an Earth symbol.

• Prior to mounting the plug-on module, DIL switches on the rear

of the plug-on module must be set. See diagram on page 6 for

available options.

• Mount plug-on module to wallplate by locating tabs on top of

wallplate in apertures on rear of module, hinge down and press

ﬁrmly to wallplate before tightening securing screws on bottom

of wallplate.

Please Note:

Always switch oﬀ mains ﬁrst and never ﬁt programmer to a live

wallplate.

Please Note:

On 24 volt models power

supply must be wired to

A & B on wallplate.

3.1 Wiring

For wiring conversion tables please see pages 10-17).

FP715SI

GB Not Used

Gravity

5/2 Day

7 Day

Sw.1

Sw.2

Sw.3

Sw.4

Not Used

Pumped

7 Day or 24 Hour

24 Hour

Before mounting the unit, ensure the 4 DIL switches on the rear have

been moved to the required settings.

Tick the INSTALLER SETTING box on the inside ﬂap label to notify user

in which mode their unit is set (24hr, 5/2 day or 7 day).

3.2 DIL Switch Settings

INSTALLER SETTING

24 Hour

5+2 Day

7 Day

4.0 Advanced Programming Options

To enter advanced programming press PROG, +and DAY/HOL

together and hold for 5 seconds.

Option 1 - (3 or 2 On/Oﬀs per day)

Use +or - to change between 3 or 2 on/oﬀs each day.

Option 2 - (Disable or enable auto time change)

Press NEXT, then use + or -to change between auto time change

enabled to auto time change disabled.

3 on/oﬀs each day (Factory setting) 2 on/oﬀs each day

Auto time change enabled (Factory setting) Auto time change disabled

Danfoss Heating 7

Option 8 - (Advanced Copy Functions)

Press NEXT, then +or -to change between the following copy

options:

(0) Standard copy in 7 day and 5+2 day.

(1) Enhanced copy in 7 day and 5+2 day.

(2) Enhanced copy in 7 day and AB copy in 5+2 day.

For an explanation of the copy features and how to use them please

see below.

Press PROG to return to RUN.

There are 3 possible copy functions available. These are; Standard

Copy, Enhanced Copy, and AB copy. Copy functions are enabled/

disabled in the Advanced Programming Options (page 6).

Standard Copy: Pressing copy will copy the previous days events

into the displayed day. The unit will then display the 1st event for the

new day. This copy function is present only if the unit is set to run in

5+2 or 7 day mode.

Enhanced Copy: The enhanced copy function is available in 7 day

mode only. This allows any day to be copied to any other day, or days.

To use the enhanced copy function go into the event programming

using the PROG button, then:

1. Use the DAY button to ﬁnd the day to be copied from.

2. Press the COPY button to select the day to be copied from. When

selected, the day should begin to ﬂash.

3. Use the DAY button to ﬁnd the day to be copied to.

4. Press COPY button to copy the selected day.

5. Repeat steps 3 and 4 to select and copy other days.

6. To stop copying, use the DAY button to go back to the ﬂashing

day and press the COPY button. The previously ﬂashing day will

stop ﬂashing to indicate it has been de-selected.

NOTE: When a day has been copied to, it will remain visible and not

ﬂashing when the DAY button is used to select other days.

5.0 Copy Functions Explained

FP715SI

AB Copy: The AB copy function is available in 5+2 mode only and

only if activated in the Advanced Programming setting.

A and B days, when selected, can be any group of days e.g. 5+2,

4+3 etc. The days do not have to run in sequence. For example, to

operate in a 5+2 day mode the days can be set as follows:

To use the AB copy function – press the PROG button:

1. This will show the“A”days, with all the days selected.

2. Use the DAY button to highlight a day.

3. Subsequent presses of the DAY button will increment through

the days.

4. Press the +button to select a speciﬁc day as an “A” day, or press

the –button to specify a day as a “B” day.

5. Once the day has been selected as an“A”or“B”day the programme

will automatically jump to the next day.

6. When the last day of the week is active, pressing +, -, or DAY will

move back to the “A” days displayed with no selected (ﬂashing)

days (see image below).

7. Repeat 2 to 6 until all selections have been made.

8. When selections are completed, press the PROG button to move

to event programming.

Event Programming in AB mode

1. Programme “A” day events using the +(time advance), - (time

decrease), and NEXT (next period) buttons.

2. Press the DAY button to change to programme the “B” days.

3. Programme “B” day events using the +(time advance), -(time

decrease), and NEXT (next period) buttons.

A Days B Days

Mon Tues Thurs Fri Sat Wed Sun

Danfoss Heating 9

The FP715 Si is ﬁtted with an installer setback service interval timer.

If this feature is required please contact our technical department.

Setting instructions for this gas safety feature are only available to

bona ﬁde heating installers.

6.0 Service Interval Timer

FP715SI

(Applies only to 230 volt models)

Wiring conversions can be used when replacing the following

programmers with the FP715 Si. Some time controls are connected

diﬀerently depending on the type of system they are controlling.

Consult the column headed “NOTE This conversion ...” to determine

whether Table A (pages 10-13) or Table B (pages 14-17) should

Table A

DANFOSS RANDALL

FP715, CP715

(PUMPED)

MAINS DHW

OFF

HTG

OFF

NL1 2 3

DANFOSS RANDALL 922/972 N L 1 4 3

DANFOSS RANDALL 4033 7 6 5 3 4

DANFOSS RANDALL SET 5 N L 3 6 1

HORSTMANN 423, AMETHYST 7 & 10 2,3 1 4 6 5

HORSTMANN 424 GEM 2,3 1,10 6 9 4

HORSTMANN LEUCITE 423 & 424 2 1 4 8 3

HORSTMANN 425 DIADEM N L 3 6 1

HORSTMANN 525 & 527 N L 3 6 1

HONEYWELL ST669 N L 7 4 6

HONEYWELL ST6300 & ST6400 N L 1 2 3

PEGLER SUNVIC SP50/SP100 N L 1 4 2

POTTERTON EP2000, EP3000 N L 1 2 3

RANDALL TSR3+3 3,6 7 2 5 1

RANDALL 3033 1,7 6 5 3 4

RANDALL 702 N L 4 2 3

SANGAMO FORM 1 410 & 414 4,5 6 2 7 1

SANGAMO S409/1 N,1,3 L - - 2

7.0 Wiring Conversions
