Danfoss CF-WR Bedienungsanleitung
088U0252
CF-WR Electronic Wireless Relay
Danfoss Heating Solutions VISPP21C © Danfoss 11/20112
3© Danfoss 11/2011 VISPP21C Danfoss Heating Solutions
Instruction ...........................................................4
Instruktion ...........................................................9
Vejledning ..........................................................14
Instruction .........................................................19
Bruksanvisning .................................................24
Instrukcja obsługi .............................................29
Handleiding .......................................................34
Istruzioni ............................................................39
GB
DE
DK
FR
SE
PL
NL
Instruction CF-WR Electronic Wireless relay
IT
Danfoss Heating Solutions VISPP21C © Danfoss 11/20114
1. Functional overview
CF-WR Wireless Relay CF-MC Master Controller
PROG button with PROG LED.
Button not used for CF2+.
Menu Selection button.
Install LED.
OK button.
Instruction CF-WR Electronic Wireless Relay
5© Danfoss 11/2011 VISPP21C Danfoss Heating Solutions
2. Installation
Activate CF-MC Master Controller:
• Select Install Mode with the Menu Selection button . The Install LED
flashes.
• Press the OK button to activate Install Mode. The Install LED lights
continously.
Instruction CF-WR Electronic Wireless relay
GB
Danfoss Heating Solutions VISPP21C © Danfoss 11/20116
Instruction CF-WR Electronic Wireless Relay
Activate CF-WR Wireless Relay:
• Press the PROG button . The PROG LED flashes during communication.
• If installation succeeded: The PROG LED turns off.
• If installation fails: The PROG LED flashes 5 times. Repeat the installation
procedure.
3. Configuration
Configuration of CF-WR Wireless Relay is made with the CF-RC Remote Con-
troller.
Please refer to the instruction for CF-RC for further information.
4. Uninstallation / Factory Reset
1. Disconnect CF-WR Wireless Relay from the power supply.
2. Press and hold the PROG button .
3. While pressing the PROG button , reconnect the power supply.
4. Release the PROG button , when the PROG LED first turns on and then off.
7© Danfoss 11/2011 VISPP21C Danfoss Heating Solutions
Instruction CF-WR Electronic Wireless relay
5. Wiring
Electronics
N
L
1 Not in use
2 Com
3 Zone 1 on
4 Zone 1 off
N L 1 2 3 4
Note: For mains voltage applications link terminals L and 2.
6. Troubleshooting
Error indication Possible cause
The PROG LED flashes 5 times Installation / Link test has failed
GB
Danfoss Heating Solutions VISPP21C © Danfoss 11/20118
7. Specifications
Supply voltage 230 Vac ± 15%, 50 Hz
Construction EN 60730-1, EN 300-220-1
Max. ambient temperature 45°C
Switch type 1 x SPDT, type 1B
Switch rating 230 Vac, 12 (6) A
IP class IP 40
Control pollution situation Degree 2
Max. range 30 m
Operating frequency 868.42 MHz
Software classification Class A
Rated impulse voltage 2.5 kV
Ball pressure test 75°C
Instruction CF-WR Electronic Wireless Relay
9© Danfoss 11/2011 VISPP21C Danfoss Heating Solutions
1. Funktionsübersicht
Funkgesteuertes Relais CF-WR CF-MC-Hauptregler
Taste PROG mit LED PROG.
Die Taste wird nicht für CF2+
verwendet.
Menü-Auswahltaste.
Installieren Sie die LED.
OK-Taste.
Instruktion Funkgesteuertes Relais CF-WR
DE
Danfoss Heating Solutions VISPP21C © Danfoss 11/201110
2. Installation
Aktivieren Sie den CF-MC-Hauptregler:
• Wählen Sie den Installationsmodus anhand der Menü-Auswahltaste . Die
Installations-LED blinkt.
• Drücken Sie die Taste OK, um den Installationsmodus zu aktivieren. Die
Installations-LED leuchtet dauerhaft.
Instruktion Funkgesteuertes Relais CF-WR
