Dangbei C2 Bedienungsanleitung

User Manual

Dear Customer ········································································01

Packing List ·············································································02

Projector ··················································································03

Remote Control········································································05

Remote Control Pairing ···························································06

Connect The Wi-Fi Network·····················································07

Focus Settings·········································································07

Keystone Correction Settings··················································08

Bluetooth Speaker Mode·························································08

Screen Mirroring······································································09

More Functions········································································09

Statement ················································································10

Important Precautions·····························································12

Language Contents

English ···············································································

España ··············································································

Français ·············································································

日本語················································································

01-12

14-25

27-38

40-51

Please read the product instruction carefully：Thank you for purchasing and using the products of Hangzhou Dangbei Network Technology Co., Ltd. (hereinafter referred to as “Dangbei”).

For your safety and interests, you should read the Product Instruction carefully before using this product.

About the product instruction:

The copyright of the instruction belongs to Dangbei.

Trademarks and names mentioned in the instruction belong to their respective right owners.

In case of inconformity between the content of the instructions and the actual product, the actual product shall prevail.

Dear Customer

* Dangbei reserves the right to interpret and modify the instructions.

If you fail to follow the product instructions or precautions, and cause any personal injury, property or other losses, Dangbei will not be liable.

Packing List

Before using the device,please check all things included.

Adapter AC Cable ProjectorUser Manual Remote Control

Projector

Overview and interface description.

Volume -

Play/Pause PTZ bracket socket

Volume +

Battery indicator

Buttom ViewTop View

On/Off button,working indicator

Audio

HDMI

USB2.0

DC interface

Rear view Left View

Remote Control

ㆍOpen the battery holder cover of the remote control.

ㆍInstall 2 AAA batteries. *

ㆍPut back the cover.

Battery Holder

Install 2 AAA batteries.

Menu key

Access more options during play

(available options depend upon the source).

Volume key

Volume up/down.

OK key

Press to confirm a selection or entry.

Pause/resume play.

Return key

Return to the previous page.

Navigation keys

Navigate menus or adjust the selected content.

Indicator light

When press key,it will be flashed.

Side key

Long press:automatic focus adjustment.

Short press:pop-up quick setting window.

Home key

Open the home page.

Mouse key

Press to enter or exit mouse key mode.

Power key

* Please insert new batteries matching the polarity(+/-) as indicated.

ㆍPlace the remote control within 10cm of the device.

ㆍPress the Home key and Menu key simultaneously until an indicator light begins flashing and a “Di” is heard.

ㆍThis means that the remote control enters the pairing mode.

ㆍWhen a "DiDi" is heard,the connection is successful.

Remote Control Pairing 10 cmIndicator light

Hold to press for pairing *

* If pairing is unsuccessful,repeat the above steps after the

remote control indicator light stop flashing.

* Manual focus through the remote control up and down keys,

adjust the picture definition.

Hold to press the Side keyFocus Settings

Method 1:Hold to press the remote control Side key,will automatic

focus adjustment.

Method 2:Go to [Settings] and select [Focus Setting] to focus.

Connect The Wi-Fi Network

ㆍInto [Settings] - [Network]

ㆍSelect the wireless network,and enter the password.

Method 1:Boot, short press the remote control [power button] to select [sound box mode], in the sound box mode . Connect bluetooth device to play songs, and press [Power key] to exit the mode;Method 2:Long press the "Play/Pause" button of the projector for two seconds when it is oﬀ to enter the speaker mode, and then connect the bluetooth of the mobile phone to play music;Press the [power button] of the body or remote control to exit the mode;* Into [Settings] - [Keystone correction] - [Manual correction]

To adjust the four points and the size of the frame.

Go to [Settings] and select [Trapezoidal Correction] for correctionThe machine supports automatic trapezoidal correction (vertical direction), and the correction eﬀect can be furtherﬁne-tuned by manual correction if there is a little deviation in diﬀerent use scenarios.Keystone Correction Settings Bluetooth Speaker Mode

Play/Pause

Short press the

Power key
