DataParts DAP-SW1004 Bedienungsanleitung
DAP-SW1004
SPDIF/TOSLINK Audio 3X1 Switcher
DAP-SW1004
SPDIF/TOSLINK AUDIO 3x1 SWITCHER
USER MANUAL
Contents
1.0 Introduction ................................................................................２
2.0 Features ......................................................................................２
3.0 Specifications ..............................................................................３
4.0 Package Contents........................................................................３
5.0 Panel Descriptions.......................................................................４
6.0 Connection and Operation..........................................................４
DAP-SW1004
SPDIF/TOSLINK Audio 3X1 Switcher
Thank you for purchasing this product. For optimum performance and
safety, please read these instructions carefully before connecting,
operating or adjusting this product. Please keep this manual for future
reference.
1.0 Introduction
This SPDIF/TOSLINK Digital Audio Switcher lets the user connect up to
three TOSLINK sources to one TOSLINK input on your AV amplifier.
2.0 Features
Supports signal retiming.
Audio formats supported: LPCM2.0/DTS/Dolby-AC3.
Control with included IR Remote or by directly pressing the
front panel buttons.
Remembers last selected input after power cycle.
LED status indication.
No loss of quality.
DAP-SW1004
SPDIF/TOSLINK Audio 3X1 Switcher
3.0 Specifications
Supported audio formats
LPCM2.0/DTS/Dolby-AC3
Peak wavelength
650nm
Max baud rate
16Mbps
Output cable distance
≤40m when used with quality optical
fibre cable (<0.2dB/m attenuation)
Power Supply
USB Power Cable
Operating Temperature range
(0°C to 40°C)
Operating Humidity range
5% to 90% RH(No condensation)
Note: Specifications are subject to change without notice.
4.0 Package Contents
1. Main unit
2. USB Power Cable
3. This user manual
4. Remote control
5. IR extender receiver
DAP-SW1004
SPDIF/TOSLINK Audio 3X1 Switcher
5.0 Panel Descriptions
6.0 Connection and Operation
