Datecs LineaPro 7 UHF Bedienungsanleitung

1 DATECS

LineaPro 7 UHF

User Manual

1 DATECS LINEAPRO 7 UHF USER MANUAL

UM 07.01.18/v1.1.0 2

LEGAL NOTICE

THE INFORMATION IN THIS DOCUMENT CANNOT BE REPRODUCED IN ANY MECHANICAL, ELECTRICAL

OR ELECTRONIC WAY AND UNDER ANY CIRCUMSTANCES WITHOUT THE WRITTEN CONSENT FROM DATECS LTD.

Address: 4 Datecs Street, Sofia 1592, Bulgaria

Phone: +359 2 816 55 50

Fax: +359 2 816 55 65

E-mail: [email protected]

1 DATECS LINEAPRO 7 UHF USER MANUAL

UM 07.01.18/v1.1.0 3

REVISION HISTORY

Version

Data

Change description

1.0.0

07.04.2020

First Release

1.1.0

28.05.2020

Added notice in section “GETTING STARTED” while is using RF

function

1 DATECS LINEAPRO 7 UHF USER MANUAL

UM 07.01.18/v1.1.0 4

CONTENTS

REGULATORY........................................................................................................................................................................... 5

TECHNICAL SPECIFICATIONS ................................................................................................................................................... 6

GENERAL VIEW........................................................................................................................................................................ 9

GETTING STARTED................................................................................................................................................................. 11

BATTERY LED INDICATIONS...................................................................................................................................................... 12

ATTACHING APPLE DEVICE TO LINEAPRO 7 UHF.................................................................................................................. 13

OPERATION MODES .............................................................................................................................................................. 14

SCANNING BARCODES ............................................................................................................................................................. 14

HF CONTACTLESS CARDS READING............................................................................................................................................. 15

UHF CONTACTLESS CARDS/TAGS READING.................................................................................................................................. 15

TRANSFERRING DATA BETWEEN APPLE DEVICE AND PC OR MAC..................................................................................................... 16

TURN OFF DEVICE FUNCTION .................................................................................................................................................... 16

CHARGING APPLE DEVICE......................................................................................................................................................... 16

UPDATING FIRMWARE ............................................................................................................................................................ 16

CARE, MAINTENANCE AND WARRANTY............................................................................................................................... 17

1 DATECS LINEAPRO 7 UHF USER MANUAL

UM 07.01.18/v1.1.0 5

REGULATORY

FCC ID: YRW-LINEAPRO7UHF

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference that may cause

undesired operation.

Any change or modification to the product not expressly approved by Datecs Ltd could void the user's

authority to operate the device.

This device complies with portable RF exposure requirements in accordance with FCC rule part 2.1093

and KDB 447498 D01

1 DATECS LINEAPRO 7 UHF USER MANUAL

UM 07.01.18/v1.1.0 6

TECHNICAL SPECIFICATIONS

Keyboard and Buttons

Two Scan buttons

Battery status button

Reset device button

Contactless Card Reader (optional)

Supports:

ISO/IEC 14443 Type-A/MIFARE

- MIFARE MINI

- MIFARE CLASSIC-1K, MIFARE CLASSIC-4K

- MIFARE ULTRALIGHT, ULTRALIGHT-C

- MIFARE PLUS 2K/4K

- MIFARE DESFire

- and other

ISO/IEC 14443 Type-B

- supports most of the cards

ISO/IEC 15693

- supports most of the cards

JIS X 6319-4

- compatible with FeliCa

ISO/IEC 18000-3 mode 3

- NFC

UHF RFID Reader (optional)

Supported protocols:

ISO 18000-6C/EPC Global Gen II

Frequency range:

US 902–928 MHz

Power Range:

13-27dBm

1D Barcode Reader

1D Opticon MDL1000* - Laser Barcode Scan Engine (optional)

Supported Symbology 1D

JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11, Code 39,

Code 93, Code 128, GS1-128(EAN-128), GS1 DataBar (RSS), IATA,

Industrial 2of5, Interleaved 2of5, ISBN-ISMN-ISSN, Matrix 2of5,

MSI/Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey

Postal code: Chinese Post, Korean Postal Authority code

Composite codes, MicroPDF417, PDF417

2D Barcode Reader

2D Newland EM3096 CMOS Imager 752 x 480 pixels (optional)

2D Newland EM3296 CMOS Imager 640 x 480 pixels (optional)

2D Newland EM3396 CMOS Imager 752 x 480 pixels, AIMER Laser

Diode (optional)

2D Opticon MDI-4000* CMOS Imager 640 x 480 pixels (optional)

2D Honeywell N660x series CMOS Imager 844 x 640 pixels

(optional)

2D Motorola SE4710/PL3307 CMOS Imager 1280 x 800 pixels

(optional)

2D Motorola SE4750/PL3307 CMOS Imager 1280 x 960 pixels

(optional)

Supported 1D and 2D Symbology

BARCODE 1D: JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11,

Code 39, Code 93, Code 128, GS1-128 (EAN-128), GS1 DataBar

(RSS),

IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISSN-ISMN, Matrix

2of5, MSI/

Plessey, S-Code, Telepen, Tri-Optic, UK/ Plessey POSTAL CODE:

Chinese

Post, Intelligent Mail Barcode, Korean Postal Authority code,

POSTNET

2D CODE: Aztec Code, Aztec Runes, Chinese Sensible code,

Codablock F,

1 DATECS LINEAPRO 7 UHF USER MANUAL

UM 07.01.18/v1.1.0 7

Composite codes, Data Matrix (ECC200), Passport MRZ (OCR-B),

Maxi Code

(mode 2~5), MicroPDF417, Micro QR Code, PDF417, QR code

Connectivity

Apple 9 pin connector

Pass-through sync through USB type-C

SAM card holder (Optional)

Device Compatibility

Apple iPhone 8, Apple iPhone 7, Apple iPhone 6S, Apple iPhone 6

LED Indication

4 LEDs for battery status

Audio Features

Electro-Magnetic Buzzer

Power Supply

DC 5V through USB type-C

DC 5V through single or 5 station charger

Battery

Rechargeable Li-Ion Battery 3.6V / 2330mAh

Precise battery management by Fuel Gauge microcontroller for

remaining battery capacity

Certificates

MFi, CE, FCC, RCM

Dimension W x H x D, mm

76.9 x 156.7 x 26.3

Weight, g

166

Operational temperature range

-10 °C to +40 °C / 5 to 90% RH

Storage temperature range

-20 °C to +50 °C / 5 to 90% RH

Compatible Accessories

Single charger (GT1)

5 stations charger (GT5)

Holsters

* Specification can be change without any notice.

1 DATECS LINEAPRO 7 UHF USER MANUAL

UM 07.01.18/v1.1.0 8

Use only original equipped DATECS cable USB-A to USB-C (Z05C000000-05) for

charging Apple device.

Use only UL approved USB adapters. The minimum requirements of USB

adapter is 5V/2.1A!

Waste Electrical & Electronic Equipment

The symbol means that according to local laws and regulations your product

shall be disposed of separately from household waste at the end of its working

life. To prevent possible harm to the environment or human health from

uncontrolled waste disposal, please separate this from other types of wastes

and recycle it responsibly to promote the sustainable reuse of material

resources.

1 DATECS LINEAPRO 7 UHF USER MANUAL

UM 07.01.18/v1.1.0 9

GENERAL VIEW

1 DATECS LINEAPRO 7 UHF USER MANUAL

UM 07.01.18/v1.1.0 10

1. Barcode engine

7. Volume buttons of Apple device

2. On/Off button of Apple device

8. Back Cover

3. Left and Right scan buttons

9. RFID HF Reader

4. USB type-C connector

10. Battery status button and LED indication

5. Charging pads

11. RFID UHF Reader

6. Reset button
