Dato CL200 Benutzerhandbuch
CL
Smart Camera
Quick Operation Guide
Packing List
Product Introduction
Product Installation
The DATO intelligent PTZ camera can be placed on a writing desk, dining room
table, coffee table, etc., or it can be mounted on the wall.
Wall Mounting
①
According to the hole distance of the base, use the drilling tool to make two holes
onto the wall surface. It is recommended to mark and the wall with a pencil before
drilling. The diameter of the hole is about 1 cm, and the hole depth is about 5 cm.
②
Screw two plastic expansion nuts into the wall.
Product Installation
The reverse side of the base is in close contact with the wall surface and coincides with
the hole position of the wall surface, and the screw is inserted into the hole and nailed
into the expansion nut in the wall seat position.
Align the hole on the bottom of the camera with the screw on the ring of the base. After
the ring of the camera and the base are tightly fitted, tighten the screws on the back
clockwise. After the camera is fixed, the bottom of the base and the ring can be placed.
Loosen the screw counterclockwise to adjust the vertical angle of the camera. After
adjusting the angle, tighten the screw clockwise.
Wall-mounted installation notes:
* The wall surface needs to be at least 3 times more than the total weight of the camera.
* Please save the bottom device QR code before installing it to the wall.
Red light is blinking slowly: Power up and activating
Red light is blinking quickly: The device is restored to factory default
Blue light flashes slowly: The device is ready to connect
Blue light is blinking quickly: The device is receiving the Wi-Fi signal or connecting to the
Wi-Fi
Blue light goes off: The device failed to connect to the network
Blue and red lights are solid and steady: The device is connected to the network
①
The indicator red light flashes slowly until the red light is steady, indicating that the
power is turned on successfully.
②
After turning on the power, do not turn the camera's head to force it to rotate when
the red light is flashing. The camera will automatically position to the standard position.
If the lens is not positioned accurately, the lens can be rotated when the red light is
always on.
Product Use
Boot Device
Plug the power cable into the DC 5V power jack on the back of the camera and the
camera will automatically turn on.
Indicator status
Make sure the camera is off and adjust the lens to the up position to expose the SD card
slot. Insert the SD card with the contact side down into the card slot.
Note: When installing or removing the SD memory card, you need to turn off the power
of the camera before operating. Please use an SD card produced by a regular
manufacturer.
Product Use
Install SD Card
Download APP
Search for "Dato ai" in Google Play and APP Store or scan the QR code below to
download DATO APP
Product Use
①
Add device: Run APP, click “+” in the upper right corner, select “DATO camera PTZ
version”, scan the camera bottom body QR code
Quick Configuration
②
After the QR code is scanned, enter the Add Guide page and press and hold the
Camera Reset button for 5 seconds until the blue light flashes slowly.
③
After the blue light flashes slowly, click the blue light to flash slowly, enter the camera
parameter page, edit the camera name, click “Next” to enter the Wi-Fi configuration
page.
⑤
Align the vertical direction of the QR code generated by the mobile phone with the
camera lens. The distance between the QR code and the lens is 10-15cm. When the blue
indicator flashes quickly, click [Blue light has flashed] to enter the camera connection
status page.
Product Use
④
After entering the Wi-Fi account and password on the Wi-Fi configuration page (Note:
Please connect to the 2.4GHz band network, the device does not support the 5G band
network temporarily), click “Next”to enter the camera scan code configuration page.
⑥
When the camera receives the Wi-Fi signal, it will make two “drip” sounds, the
camera will connect successfully. At this time, the camera will always light red and
blue light; after 1 second, return to the home page and display it on the home page.
In the list; congratulations! Your camera has all been set up. Click on the camera to
enjoy viewing and camera related functions.
The IR-CUT automatically switches to night vision mode at night depending on how
much ambient light changes. It has 4 built-in infrared night vision lights, with a night
vision distance of up to 7 meters, and can also be clearly seen in the dark.
Note: The diagram is for reference only. Due to the different DATO play form version and
mobile phone system, the page display is slightly different.
Product features
Live View
Open DATO and select the connected DATO smart camera PTZ version for real-time
browsing. Through the camera's control interface, you can adjust the camera's
sharpness, horizontal and vertical angles, as well as screen capture and recording, as
well as voice calls and other operations.
Support Infrared Night Vision
Video Playback
In the DATO smart camera PTZ version control interface, click [Video Playback] to enter
the historical video playback interface, select the date and time period you want to view
to view
