Daviscomms Br502 Bedienungsanleitung
User Manual
:
Contents
Introduction ........................
Effective Use of Your Pager..
Features ...............................
Getting Started ...................
Battery Information ...............
Installing/Replacing
the Battery ............................
Caution..................................
Control Buttons .....................
Turning Your Pager On .........
Turning Your Pager Off .........
Backlight ...............................
Using the Function Menu.......
Status Indicators ...................
Function Menu ...................
Setting the Alert Type ..........
Deleting All Messages .............
Setting the Alarm .....................
Setting the Time ......................
Setting the Date ......................
Setting Reminder Alert ............
Setting Low Battery Alert .........
Setting Message Information ..
Setting Private Time ................
Messages ................................
Reading Messages...................
Protecting/Unprotecting
Messages ...............................
Deleting Messages .................
Deleting Individual Messages..
1
1
2
3
3
4
5
6
7
7
8
8
9
10
10
11
12
13
14
15
16
17
18
19
19
20
21
21
:
CONTENTS
1
:
INTRODUCTION
INTRODUCTION
Congratulations on the purchase of your Br502 POCSAG Numeric pager.
This booklet contains operation instructions that explain how to use your
new pager and provide helpful suggestions for first-time as well as
experienced users.
Effective Use of Your Pager
The Br502 pager keeps you in close contact with business associates,
family, and friends. This new generation of pagers enable on-the-go
professionals to stay connected wherever business or life takes them.
Features
· Up to 18 personal memory slots
· Protects up to 10 messages
· Individual message delete or
delete all
· Backlight
· Private time
· Daily alarm
· Time and date display
· Time and date message
stamping
· Alert types: Melody,
Chirp, Vibration, Vibration-chirp,
Silent
· Battery low indicator and alert
· Unread message reminder alert
· Duplicate message indication
· Continuous message indication
· Error message indication
· Memory full indication
· Memory retention for 30 seconds
during battery change
· Removable belt clip
2
INTRODUCTION
:
GETTING STARTED
Battery Information
Your pager is powered by a single AAA-size alkaline battery. Do not use
any other battery type other than AAA alkaline.
When the battery is low, the pager will emit a low battery alert and the
battery icon will flash. The pager may not perform optimally under low
battery conditions.
While the pager does have a backup power source to protect data stored in
memory, you should still replace a low battery immediately. Otherwise,
WARNING - Use of a battery other than an Energizer E92 OR a Duracell
MN2400, 1.5V AAA Alkaline Battery may affect the Intrinsic Safety UL rating
of the device.
:
3
GETTING STARTED
messages and settings will be lost when the backup power source goes flat.
4
GETTING STARTED
:
Installing/Replacing the Battery
- Hold the pager face down
- Open the battery compartment
by pressing down with your thumb
on the battery door and sliding the
battery door in the direction indicated
by arrow 1 in the illustration
- Lift up the battery door to access the battery
- Remove the old battery by pulling the ribbon
towards the top end of the pager as indicated
by arrow 2 in the illustration
- Insert a new battery so the polarity markings on the battery
match the polarity diagram on the housing
- If the pager does not turn on, then check to make certain the battery has
been inserted correctly.
GETTING STARTED
1
2
5
:
GETTING STARTED
CAUTION
If there is no display on the LCD when a
new battery is inserted, perform the
following:
- Open the battery cover, take out the
battery
- Use a screwdriver or conductive material
to connect the two circular reset pads
indicated in the diagram
- Insert a new battery
-The pager will turn on as per normal.
screw driver
reset pads
6
GETTING STARTED
:
Control Buttons
READ/SELECT Button:
Press to read messages, select a
feature or move from one field to
another.
FUNCTION Button:
Press to enter the function menu,
scroll through the function menu or
change the value of a field, hold for
two seconds to turn on or off backlight.
+ Button COMBINATION:
Press the Read/Select and the
Function button simultaneously to
escape back to the Status screen from
the message or function screens.
7
:
Turning Your Pager On
- Make sure that a new battery is properly
installed as discussed in the "Installing/
Replacing the Battery" section on page 5
- Your pager will turn on automatically upon insertion of battery
- When the pager is on and no activity is taking place, the Status screen
displays date, time and other relevant status indicators
Turning Your Pager Off
- Press the (Function) button 3 times
until " " displays, then press the
(Read/Select) button and the pager will turn off
- Note that the screen will display the word "OFF" and the time.
- To turn your pager back on, press and hold down the
(Read/Select) button for 2 seconds.
GETTING STARTED
8
GETTING STARTED
:
Backlight
In low-light conditions, you can turn the pager's backlight on or off at any
time (even when the pager is turned off). Press and hold down the
(Function) button for two seconds. You may repeat this step to manually
turn off the backlight, or after 15 seconds of inactivity, the backlight
automatically turns off.
Using the Function Menu
The function menu provides access to your pager's features through the
use of symbols and prompts.
(Read/ Select) button to select the displayed feature,
(Function) button to navigate through the function menu,
+ (Read/Select + Function button combination) any time to
return to the Status screen.
