DBI SALA 8001717 Montageanleitung

User Instruction Manual

Tripod Anchorage Connectors

This manual is intended to meet the

Manufacturer'sInstructionsasrequiredby

ANSI Z359.1 and ANSI A10.14, and

shouldbe usedas partof anemployee

trainingprogramas requiredbyOSHA.

The 8000000 and 8000010 Tripods

are Classified by Underwriters

Laboratories Inc. as to the 350 lb.

load capacity only.

WARNING:

Thisproduct ispartofapersonalfallarrest,work positioning,

personnelriding, material handling,orrescue andevacuationsystem.The

user must read and follow the manufacturer's instructions for each

component or part of the complete system. These instructions must be

providedtotheuserofthisequipment.The user mustreadandunderstand

these instructions or have them explained to them before using this

equipment.Manufacturer's instructions mustbefollowed forproperuseand

maintenance of this product. Alterations or misuse of this product or failure to

follow instructions may result in serious injury or death.

IMPORTANT:

Ifyou haveany

questions on the use, care,

application, or suitability for

use of this safety equipment,

contact DBI/SALAimmediately.

IMPORTANT:

Beforeusingthis

equipment,recordthe product

identificationinformationfound

on the ID label of the tripod on

theinspectionandmaintenance

manual.

* If additional information on

this product is necessary,

supplementalinstructions

will be included.

Figure 1

8001717and 8001718 Parts Identification

Figure 2

8000000and 8000010 Parts Identification

DESCRIPTIONS

8001717 Tripod: 7 ft. maximum height to eye bolt, 5 ft. minimum.Aluminum

construction with adjustable locking legs and safety chains. Fitted rubber

safety shoes with spiked edges.

8001718 Tripod: 9 ft. maximum height to eye bolt, 7 ft. minimum.Aluminum

construction with adjustable locking legs and safety chains. Fitted rubber

safety shoes with spiked edges.

8000000 Tripod: 7 ft. maximum height to eye bolt, 5 ft. minimum.Aluminum

construction with adjustable locking legs and safety chains. Fitted rubber

safety shoes with spiked edges. Includes head mount pulley assembly and

mounting bracket for DBI/SALASalalift® Winch or Self Retracting Lifeline.

8000010 Tripod: 9 ft. maximum height to eye bolt, 7 ft. minimum.Aluminum

construction with adjustable locking legs and safety chains. Fitted rubber

safety shoes with spiked edges. Includes head mount pulley assembly and

mounting bracket for DBI/SALASalalift® Winch or Self Retracting Lifeline.

IMPORTANT: Forspecial(custom) versionsofthisproduct, followthe

instructionsherein.If enclosed, seeattachedsupplement foradditional

instructionstobe followedwhenusing acustomproduct.

1.0 APPLICATIONS

1.1 PURPOSE: DBI/SALAtripods are to be used as part of a work

positioning,personnel riding, personalfallarrest, materialhandling,or

rescue and evacuation system.The tripod is a support structure or

anchorage for these systems.

1.2 LIMITATIONS:Thefollowingapplication limitationsmustbe

consideredbefore using thisproduct.Failure to observeproduct

limitations could result in serious injury or death.

A. INSTALLATION: The tripod mustbeproperly installed in

accordance with the requirements stated in section 3.0 of this

manual.

B. CAPACITY: Themaximum working loadfor this productis 350lbs.

(160kg).

C. PERSONAL FALLARREST SYSTEMS: Personalfall arrest

systems used in combination with the tripod must meet applicable

stateand federalregulations and therequirements insection 3.3.

D. PHYSICALAND ENVIRONMENTALHAZARDS: Use ofthis

equipmentin areas containingphysicalor environmentalhazards

mayrequire thatadditional precautionsbe taken to reduce the

possibility of damage to this equipment or injury to the user.

Hazards may include, but are not limited to; high heat (welding

metalcutting); strong orcaustic chemicals; corrosiveenvironments

(seawater);high voltage powerlines; explosive ortoxic gases;

moving machinery; or sharp edges. Contact DBI/SALA if you have

any questions about the application of this equipment in areas

wherephysicalor environmentalhazardsare present.

E. TRAINING:Thisequipment isto be installed and used by persons

who have been trained in its correct application and use.

1.3 Refer to national standards, including; ANSI Z359.1, ANSI A10.14,

ANSI Z117.1, and applicable local, state, and federal (OSHA)

requirements,including 29 CFR1910.146,for moreinformationon the

applicationof thisandassociated equipment.

2.0 SYSTEM REQUIREMENTS

2.1 COMPATIBILITY OF COMPONENTS: DBI/SALAequipmentis

designedfor use withDBI/SALA approvedcomponents and

subsystems only. Substitutions or replacements made with non-

approved components or subsystems may jeopardize compatibility of

equipment and may effect the safety and reliability of the complete

system.

2.2 COMPATIBILITY OF CONNECTORS: Connectorsare considered to

becompatible withconnecting elements whenthey havebeen

designed to work together in such a way that their sizes and shapes

do not cause their gate mechanisms to inadvertently open regardless

of how they become oriented. Contact DBI/SALA if you have any

questionsabout compatibility.

Connectors(hooks, carabiners, andD-rings) mustbecapable of

supportingat least5,000 lbs. (22kN). Connectors must be compatible

with the anchorage or other system components. Do not use

equipmentthat is notcompatible. Non-compatibleconnectors may

unintentionallydisengage.See Figure 3.Connectorsmust be

compatible in size, shape, and strength. Self locking snap hooks and

carabinersare required byANSI Z359.1 andOSHA.

2.3 MAKING CONNECTIONS: Onlyuseself-lockingsnap hooks and

carabiners with this equipment. Only use connectors that are suitable

to each application. Ensure all connections are compatible in size,

shape and strength. Do not use equipment that is not compatible.

Ensure all connectors are fully closed and locked.

DBI/SALAconnectors (snaphooks and carabiners)are designedto be

used only as specified in each product’s user’s instructions. See

Figure4 for inappropriateconnections. DBI/SALA snaphooks and

carabinersshould not beconnected:

A. To a D-ring to which another connector is attached.

B. In a manner that would result in a load on the gate.

NOTE:Largethroatopeningsnap hooksshouldnotbeconnectedto

standardsize D-ringsor similarobjects whichwill resultina loadon thegate

ifthe hookorD-ring twistsorrotates. Largethroat snaphooksare designed

foruseon fixedstructuralelements suchas rebarorcross membersthatare

not shaped in a way that can capture the gate of the hook.

C. Ina falseengagement, where features that protrudefrom thesnap

hook or carabiner catch on the anchor and without visual

confirmation seems to be fully engaged to the anchor point.

D. Toeachother.

E. Directly to webbing or rope lanyard or tie-back (unless the

Figure 3 - Unintentional Disengagement (Roll-out)

If the connecting element that a snap hook (shown) or carabiner attaches to is

undersized or irregular in shape, a situation could occur where the connecting

element applies a force to the gate of the snap hook or carabiner. This force may

cause the gate (of either a self-locking or a non-locking snap hook) to open,

allowing the snap hook or carabiner to disengage from the connecting point.

1. Force is applied to

the snap hook. 2. The gate presses against

the connecting ring. 3. The gate opens

allowing the snap

hook to slip off.

Small ring or other

non-compatibly

shapedelement

manufacturer’sinstructionsforboth the lanyardand connector

specifically allows such a connection).

F. To any object which is shaped or dimensioned such that the snap

hook or carabiner will not close and lock, or that roll-out could

occur.

2.4 STRUCTURALSTRENGTH: The structure (mounting surface) onto

which the tripod is erected (floor, tank top, roof, etc.) must meet

minimum strengths given below for the applications selected:

FallArrest: FromANSIZ359.1; “The structure(mountingsurface)

selected for personal fall arrest systems (PFAS) shall have a strength

capable of sustaining static loads in the direction(s) permitted by the

PFAS when in use of at least (A) 3,600 lbs. (16kN) when certification

exists (seeANSI Z359.1 for certification definition), or (B) 5,000 lbs.

(22.2kN) in absence of certification. When more than one tripod is

installed on a structure for fall arrest, and the systems will be used

simultaneously, the strengths set forth in (A) and (B) above shall be

multiplied by the number of systems attached to the structure.” From

OSHA1926.500and1910.66;“Anchorages (mounting surface)used

for attachment of personal fall arrest systems (PFAS) shall be

independentof any anchoragebeing usedtosupport orsuspend

platforms, and capable of supporting at least 5,000 lbs. (22.2kN) per

user attached, or be designed, installed, and used as part of a

complete PFAS which maintains a safety factor of at least two and is

underthe supervision ofaqualified person.”

Figure 4 - Inappropriate Connections

Work Positioning:Thestructure (mountingsurface)selectedfor work

positioning applications must sustain a static load of at least 5,000 lbs.

applied in the directions permitted by the work positioning system

when in use. Each tripod installation must independently sustain this

load.

Personnel Riding:The structure(mountingsurface) selectedfor

personnel riding applications must sustain a static load of at least

2,500lbs. appliedin the directionspermitted bythe personnel riding

system when in use. Each tripod installation must independently

sustain this load.

Material Handling: Thestructure (mounting surface)selectedfor

material handling applications must sustain a static load of at least

2,500lbs. appliedin the directions permitted by the material handling

system when in use. Each tripod installation must independently

sustain this load.

Rescue: Thestructure(mounting surface) selectedforrescue

applications must be capable of sustaining a static load of at least

2,500 lbs. applied in the directions permitted by the rescue system

when in use. Each tripod installation must independently sustain this

load.

3.0 OPERATION AND USE

WARNING: Do notalterorintentionally misusethisequipment.Consult

DBI/SALAwhen usingthisequipment incombination withcomponentsor

subsystemsotherthanthose describedinthismanual.Some subsystemand

componentcombinationsmay interferewiththe operationof this equipment.

Usecautionwhenusing thisequipmentaroundmovingmachinery,electrical

hazards,chemicalhazards,andsharpedges.

WARNING: Consultyour doctorif thereisreason todoubtyour fitnessto

safelyabsorb theshock fromafall arrest.Age andfitness seriouslyaffect a

worker'sabilityto withstandfalls. Pregnantwomenor minorsmustnot use

theDBI/SALAtripods exceptfor emergencysituations.

3.1 BEFORE EACH USE: Before each useof thisequipment carefully

inspect it to ensure that it is in good working condition. Check for worn

or damaged parts. Ensure all parts (nuts, bolts, etc.) are present and

secure. Check legs to ensure they are straight, free of cracks, dents,

etc. Ensure pulleys rotate freely and entire system is free of corrosion.

Refer to section 5.0 for further inspection details. Do not use if

inspectionreveals anunsafe condition.

3.2 PLANNING:Plan your workpositioning,personnelriding, personal fall

arrest,material handling,or rescue andevacuation systembefore

starting your work. Consider all factors that affect your safety at any

timeduring use.Some important pointsto considerwhen planning

your system are:

A. HAZARD EVALUATION: An evaluation ofjob site hazardsis

necessary prior to starting work. Consult applicable OSHAand

industrystandardsfor guidelinesandregulatoryrequirements on

issues such as confined space entry, personal fall arrest

systems, single point adjustable suspended scaffolds, etc.

B. WORK SITE GEOMETRY: The installationand use ofthe tripod

must be consistent with the geometric requirements given in

section3.4 or3.5. When suspendingworking linesfrom the tripod

check for obstructions or sharp edges in the work path.Avoid

working where the user may swing and hit an object or where lines

may cross or tangle with that of another worker in the area.

C. SECONDARYOR BACK-UPFALLARRESTSYSTEM: When

using the tripod as a support for suspending a worker at a work

level,or forpersonnel ridingapplications, asecondary or back-up

fall arrest system is required. See OSHA 29 CFR 1910.28 and

1926.451.Thetripod has provisionsfor connectionof a secondary

or back-up personal fall arrest system. See sections 3.3 and 3.5.

D. RESCUE: In the event of an accident with injuries or other

medical emergency, it is critical that a means of dealing with such

asituation hasbeen plannedin advance.Response timeoften

plays an important role in the survival of an injured worker. Users

ofthis equipment must be trainedin emergency procedures.

3.3 REQUIREMENTS FOR PERSONAL FALLARREST SYSTEMS:

Personal fall arrest systems used with this tripod must meet

applicableOSHArequirements. Whenin use, thePFAS shouldbe

rigged to minimize any potential free fall and never allow a free fall

greater than six feet. It is recommended that the PFAS used with this

equipment include a full body harness as the body support

component.PFAS's that incorporate full bodyharnesses must

maintain fall arrest forces below 1,800 lbs. and arrest the fall within 42

inches. Body belts, unless incorporated into a full body harness, not

recommended for use with this equipment.Atypical PFAS includes a

full body harness, a connecting subsystem or component (self

retracting lifeline or a lifeline and rope grab) and the connectors to

couple the system together.

WARNING: Follow themanufacturer'sinstructionsforthe personalfallarrest

equipmentselected foruse withthe tripod.

IMPORTANT: Forfree fallandrescue applications,bodybelts arenot

recommendedforuse. Bodybeltsincrease therisk of injuryduring fallarrest

incomparisonto afullbody harnessanddrastically reducethetolerable

suspensiontimecompared toafullbody harness.Limitedsuspension time,

increasedrisk ofinjury,and thepotentialfor improperlywearing abody belt,

mayresult inadded dangerto theuser.DBI/SALArecommends usinga full

bodyharnessforfall arrestandrescueapplications.

3.4 INSTALLATION REQUIREMENTS OF TRIPOD

A. LOAD REQUIREMENTS: Dependingontheapplication,the

strengthrequirements forthe supporting structureonto whichthe

tripod is erected vary. See section 2.4 for application types and

the supporting structure load requirements. If an installation will be

used for more than one type of application, always select the

loadingfor the applicationwith the greaterloadrequirements.

B. GEOMETRIC REQUIREMENTS: Thetripodmustbemounted

where it can be leveled using the leg adjustments. The footing

must be solid under each leg, and support the intended loading.

Position the tripod such that the lifeline will be directly over the

intendedwork area wheninstalled. Do notposition the tripod

where the worker will have to swing under the tripod to reach the

workarea.Avoidpositioningthe tripodwherethe workingline may

abradeagainstsharp edges. SeeFigure5.

WARNING: Neverallow theworking linetoextend outsidethe legsofthe

tripod.Tippingof thetripodcould occur.

C. TO ERECT TRIPOD: The tripod is shipped with the legs set at full

retraction. Erect as follows, see Figure 5: 1) Lay the tripod on the

workingsurface; 2)Adjust legs to requiredworking height;3)Tilt

the tripod into an upright position; 4) Fully spread the legs, ensure

legsare against bearingsurface onhead.Thelegswill

automatically lock in place.To collapse tripod, pull leg down to

disengage leg lock and swing leg in; 5) Position tripod over

opening so working line will be located approximately in the center

of the opening. Ensure footing is solid under each leg and can

support the intended loads. Level the tripod by adjusting the leg

height; 6) Adjust the leg chain by removing excess slack.

WARNING:Exceptforemergencysituationswherelegchainsmayinterfere

withrescue, thetripod mustnever beusedwithout theleg chainsin place.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere DBI SALA Kamerazubehör Handbücher

DBI SALA

DBI SALA UCT-1000 Bedienungsanleitung

DBI SALA

DBI SALA UCT-1000 Bedienungsanleitung

Beliebte Kamerazubehör Handbücher anderer Marken

Viltrox

Viltrox EF-NEX Montageanleitung

Calumet

Calumet 7100 Series CK7114 Bedienungsanleitung

Ropox

Ropox 4Single Series Bedienungsanleitung

Cambo

Cambo Wide DS Digital Series Betriebsanleitung

Samsung

Samsung SHG-120 Bedienungsanleitung

Ryobi

Ryobi BPL-1820 Bedienungsanleitung

Aegis

Aegis ABL-36020P Bedienungsanleitung

Pentax

Pentax Data Back Fc Bedienungsanleitung

Fantasea

Fantasea EyeGrabber F Series Bedienungsanleitung

Honeywell

Honeywell HDZ20HD Bedienungsanleitung

EGO

EGO BA1400T Bedienungsanleitung

Sima

Sima SRW-62 Bedienungsanleitung

Shape

Shape A7SSMKIT Bedienungsanleitung

Slide Kamera

Slide Kamera HST-2 Bedienungsanleitung

Power works

Power works 2902613 Bedienungsanleitung

SES

SES SE-2047-2 Bedienungsanleitung

Olympus

Olympus PT-EP05L Bedienungsanleitung

Starlite

Starlite OctoDome nxt Bedienungsanleitung
