Modulens EN
Gas fired floor-standing condensing boiler
AGC 10/15
AGC 15
AGC 25
AGC 35
User Guide
300026080-001-02
Contents
1 Introduction ................................................................................................4
1.1 Symbols used .......................................................4
1.1.1 Symbols used in the manual ...................................4
1.1.2 Symbols used on the equipment .............................4
1.2 Abbreviations ........................................................5
1.3 General ..................................................................5
1.3.1 Manufacturer’s liability .............................................5
1.3.2 Installer’s liability .....................................................6
1.3.3 User’s liability ..........................................................6
1.4 Certifications .........................................................6
2Safety instructions and recommendations ..............................................7
2.1 Safety instructions ...............................................7
2.2 Recommendations ................................................8
3Description ..................................................................................................9
3.1 Operating principle ...............................................9
3.1.1 Gas/air setting .........................................................9
3.1.2 Combustion .............................................................9
3.2 Main parts ............................................................10
3.3 Control panel .......................................................10
3.3.1 Description of the keys ..........................................10
3.3.2 Description of the display ......................................11
3.3.3 Browsing in the menus ..........................................14
4 Operating the appliance ..........................................................................15
4.1 Putting the appliance into operation ................15
4.2 Reading out measured values ...........................15
4.3 Changing the settings ........................................17
4.3.1 Setting the set point temperatures ........................17
4.3.2 Selecting the operating mode ...............................18
4.3.3 Forcing domestic hot water production .................19
4.3.4 Setting the contrast and lighting on the
display ...................................................................19
4.3.5 Setting the time and date ......................................20
4.3.6 Selecting a timer programme ................................20
4.3.7 Customising a timer programme ...........................21
102/04/2013 - 300026080-001-02
4.4 Installation shutdown .........................................23
4.5 Antifreeze protection ..........................................23
5 Checking and maintenance .....................................................................25
5.1 General instructions ...........................................25
5.2 Periodic checks ..................................................25
6 Troubleshooting .......................................................................................27
6.1 Anti-hunting ........................................................27
6.2 Messages (Code type Bxx or Mxx) ....................27
6.3 Faults (Code type Lxx or Dxx) ...........................29
7 Technical specifications ..........................................................................35
7.1 Technical specifications ....................................35
8 Energy savings .........................................................................................37
8.1 Energy-saving advice .........................................37
8.2 Recommendations ..............................................37
9 Warranty ....................................................................................................38
9.1 General ................................................................38
9.2 Warranty terms ...................................................38
Contents
202/04/2013 - 300026080-001-02
302/04/2013 - 300026080-001-02
1 Introduction
1.1 Symbols used
1.1.1. Symbols used in the manual
In these instructions, various danger levels are employed to draw the
user’s attention to particular information. In so doing, we wish to
safeguard the user’s safety, obviate hazards and guarantee correct
operation of the appliance.
DANGER
Risk of a dangerous situation causing serious physical
injury.
WARNING
Risk of a dangerous situation causing slight physical
injury.
CAUTION
Risk of material damage.
Signals important information.
¼Signals a referral to other instructions or other pages in the
instructions.
1.1.2. Symbols used on the equipment
4Protective earthing
~Alternating current
Before installing and commissioning the device, read
carefully the instruction manuals provided.
Dispose of the used products in an appropriate recovery
and recycling structure.
This appliance must be connected to the protective earth.
D000241-C
AGC 10/15 AGC 15 AGC 25 AGC 35 1. Introduction
02/04/2013 - 300026080-001-02 4
Caution: danger, live parts.
Disconnect the mains power prior to any operations.
1.2 Abbreviations
43CE: Collective conduit for sealed boiler
4DHW: Domestic hot water
4Interscenario switch: Home automation switch that can be used
to centralise and control several scenarios
4Hi: Lower heating value LHV (Nett)
4Hs: Higher heating value HHV (Gross)
4PPS: Polypropylene hardly inflammable
4PCU: Primary Control Unit - PCB for managing burner operation
4PSU: Parameter Storage Unit - Parameter storage for PCBs
PCU and SU
4SCU: Secondary Control Unit - control panel PCB
4SU: Safety Unit - Safety PCB
43WV: 3-way valve
4HL: High Load - DHW tank with plate exchanger
4SL: Standard Load - DHW tank with coil
4SHL: Solar High Load - Solar DHW tank with plate exchanger
4SSL: Solar Standard Load - Solar DHW tank with coil
1.3 General
1.3.1. Manufacturer’s liability
Our products are manufactured in compliance with the requirements
of the various applicable European Directives. They are therefore
delivered with [ marking and all relevant documentation.
In the interest of customers, we are continuously endeavouring to
make improvements in product quality. All the specifications stated in
this document are therefore subject to change without notice.
Our liability as the manufacturer may not be invoked in the following
cases:
4Failure to abide by the instructions on using the appliance.
4Faulty or insufficient maintenance of the appliance.
4Failure to abide by the instructions on installing the appliance.
1 2
M002628-A
1. Introduction AGC 10/15 AGC 15 AGC 25 AGC 35
502/04/2013 - 300026080-001-02
1.3.2. Installer’s liability
The installer is responsible for the installation and inital start up of the
appliance. The installer must respect the following instructions:
4Read and follow the instructions given in the manuals provided
with the appliance.
4Carry out installation in compliance with the prevailing legislation
and standards.
4Perform the initial start up and carry out any checks necessary.
4Explain the installation to the user.
4If a maintenance is necessary, warn the user of the obligation to
check the appliance and maintain it in good working order.
4Give all the instruction manuals to the user.
1.3.3. User’s liability
To guarantee optimum operation of the appliance, the user must
respect the following instructions:
4Read and follow the instructions given in the manuals provided
with the appliance.
4Call on qualified professionals to carry out installation and initial
start up.
4Get your installer to explain your installation to you.
4Have the required checks and services done.
4Keep the instruction manuals in good condition close to the
appliance.
This appliance is not intended to be used by persons (including
children) whose physcial, sensory or mental capacity is impaired or
persons with no experience or knowledge, unless they have the
benefit, through the intermediary of a person responsible for their
safety, of supervision or prior instructions regarding use of the
appliance. Care should be taken to ensure that children do not play
with the appliance.
To prevent hazardous situations from arising, if the mains lead is
damaged it must be replaced by the original manufacturer, the
manufacturer’s dealer or another suitably skilled person.
1.4 Certifications
CE identification no CE-0085CM0178
NOx classification 5 (EN 297 pr A3, EN 483)
Type of connection Chimney: B23, B33
Flue gas outlet: C13(x), C33(x), C43(x), C53, C83(x),
C93(x)
AGC 10/15 AGC 15 AGC 25 AGC 35 1. Introduction
02/04/2013 - 300026080-001-02 6
2 Safety instructions and
recommendations
2.1 Safety instructions
DANGER
If you smell gas:
1. Do not use a naked flame, do not smoke, do not
operate electrical contacts or switches ( doorbell,
light, motor, lift, etc..).
2. Shut off the gas supply.
3. Open the windows.
4. Evacuate the premises.
5. Call your fitter.
DANGER
If you smell flue gases:
1. Switch the appliance off.
2. Open the windows.
3. Evacuate the premises.
4. Call your fitter.
WARNING
Depending on the settings of the appliance:
4The temperature of the flue gas conduits may exceed
60°C.
4The temperature of the radiators may reach 85°C.
4The temperature of the domestic hot water may reach
65°C.
CAUTION
Do not neglect to service the appliance:
4For completely safe and optimum operation, you
must have your boiler regularly serviced by an
approved installer.
2. Safety instructions and recommendations AGC 10/15 AGC 15 AGC 25 AGC 35
702/04/2013 - 300026080-001-02
2.2 Recommendations
WARNING
Only qualified professionals are authorised to work on the
appliance and the installation.
4Regularly check the water pressure in the installation (minimum
pressure 0,8 bar, recommended pressure between 1,5 and 2,0
bar).
4Keep the appliance accessible at all times.
4Never remove or cover labels and rating plates affixed to the
appliance. Labels and rating plates must be legible throughout the
entire lifetime of the appliance.
4The appliance should be on Summer or Antrifreeze mode rather
than switched off to guarantee the following functions:
-Anti blocking of pumps
-Antifreeze protection
AGC 10/15 AGC 15 AGC 25 AGC 35 2. Safety instructions and recommendations
02/04/2013 - 300026080-001-02 8
3 Description
3.1 Operating principle
3.1.1. Gas/air setting
Air is sucked in by the fan and the gas injected into the venturi
attached to the fan inlet. The fan rotation speed modulates and adapts
to thermal energy requirements thanks to the temperatures measured
by the various sensors. The gas and air are mixed in the venturi, which
enables operation at a constant ratio. The noise of the venturi is
absorbed by a silencer attached to its inlet. The gas/air mixture is
carried to the burner in the top of the exchanger, guided by the pre-
mix channel.
3.1.2. Combustion
The burner heats the heating water circulating in the heat
exchanger. At a return temperature lower than around 55°C, the flue
gases cool down to a temperature lower than the dew point, thus
causing the condensation of the water vapour contained in the flue
gases in the lower section of the heat exchanger. The heat released
during this condensation process (the latent heat or condensing heat)
is also transferred to the heating water. The cooled combustion gases
are evacuated via the combustion gas outlet flue. The condensation
water is evacuated via a siphon.
3. Description AGC 10/15 AGC 15 AGC 25 AGC 35
902/04/2013 - 300026080-001-02
Andere Handbücher für AGC 35
1
Inhaltsverzeichnis
Andere DeDietrich Kessel Handbücher
DeDietrich
DeDietrich MODULENS O AFC 18 Handbuch
DeDietrich
DeDietrich Innovens MCA 35 Handbuch
DeDietrich
DeDietrich GT 123 A Handbuch
DeDietrich
DeDietrich NeOvo Condens EFU C-S 19 FF Bedienungsanleitung
DeDietrich
DeDietrich EASYLIFE CFU 36 F30 Bedienungsanleitung
DeDietrich
DeDietrich Elidens DTG130-45 Betriebsanleitung
DeDietrich
DeDietrich TwineoEGC 25 Bedienungsanleitung
DeDietrich
DeDietrich MODULENS O AFC 18 Bedienungsanleitung
DeDietrich
DeDietrich Elidens DTG130-45 Bedienungsanleitung
DeDietrich
DeDietrich GT 330 Handbuch
DeDietrich
DeDietrich C 610 ECO Bedienungsanleitung
DeDietrich
DeDietrich GTU C 330 Handbuch
DeDietrich
DeDietrich Innovens MCA 35 Bedienungsanleitung
DeDietrich
DeDietrich GT 330 Betriebsanleitung
DeDietrich
DeDietrich C 340 Series Bedienungsanleitung
DeDietrich
DeDietrich EVODENS PRO Amc 45 Bedienungsanleitung
DeDietrich
DeDietrich NeOvo Condens EFU C 19 Bedienungsanleitung
DeDietrich
DeDietrich WHE 2.24 FF-3S Bedienungsanleitung
DeDietrich
DeDietrich SOLNEO SGC 24 SOL Handbuch
DeDietrich
DeDietrich MCA 45 - 65 - 90 - 115 Handbuch
Beliebte Kessel Handbücher anderer Marken
Vaillant
Vaillant uniSTOR VIH SW GB 500 BES Bedienungsanleitung
Radijator
Radijator BIO max 23.1 Bedienungsanleitung
Brunner
Brunner BSV 20 Bedienungsanleitung
Buderus
Buderus Logamax GB062-24 KDE H V2 Bedienungsanleitung
Potterton
Potterton 50e Datenblatt
UTICA BOILERS
UTICA BOILERS TriFire Bedienungsanleitung
