Definitive Technology ProCenter 1000 Bedienungsanleitung

SPECIFICATIONS:

ProCenter 1000: Dimensions: 5"H x 5"D x 14

"W. Driver Complement:

Two 4

"cast basket bass/midrange drivers coupled to two 4

"pressure-

driven planar low-frequency radiators. 1" pure aluminum dome tweeter.

Rec. Assoc. Ampl.: 10 – 200 watts/channel. Frequency Response:

47 Hz – 30 kHz.

ProCenter 2000: Dimensions: 6

"H x 6

"D x 17"W. Driver Complement:

Two 5

"cast basket bass/midrange drivers coupled to two 5

"pressure-

driven planar low-frequency radiator. 1" pure aluminum dome tweeter. Rec.

Assoc. Ampl.: 10 – 250 watts/channel. Frequency Response: 42 Hz – 30 kHz.

ProMonitor 800: Dimensions: 8

"H x 5"D x 4

"W. Driver Complement:

One 4

"cast basket bass/midrange driver coupled to a 4

"pressure-driven

planar low-frequency radiator. 1" pure aluminum dome tweeter. Rec. Assoc.

Ampl.: 10 – 150 watts/channel. Frequency Response: 57 Hz – 30 kHz.

ProMonitor 1000: Dimensions: 10

"H x 6

"D x 6

"W. Driver

Complement: One 5

"cast basket bass/midrange driver coupled to a

"pressure-driven planar low-frequency radiator. 1" pure aluminum

dome tweeter. Rec. Assoc. Ampl.: 10 – 200 watts/channel. Frequency

Response: 47 Hz – 30 kHz.

New ProSub 800 and ProSub 1000 Subwoofers

The ProSubs are also completely new and incorporate SuperCube

technology for dramatically improved bass performance. Specially

engineered 8" or 10" high velocity long-throw drivers are combined

with downward ﬁring pressure-coupled medite sub-bass radiators and

300 watt digital ampliﬁers for exceptional low frequency response.

The ProSubs are capable of reproducing the subtlest nuances of the

ﬁnest musical performance as well as the dramatic ﬂoor shaking impact

of the most demanding cinematic action extravaganzas. The high density

medite cabinets are attractively ﬁnished in matte black and incorporate

aconvenient side-mounted volume control.

SPECIFICATIONS:

ProSub 800: Dimensions: 12

"H x 15

"D x 10

"W. Driver

Complement: One 8" woofer with polymer cone coupled to one 8"

infrasonic radiator.Ampliﬁer: 300 Watts RMS. Speaker Level High-Pass

Filter: 6 db/octave (80 Hz). High-Level Low-Pass Filter: 24 db/octave

continuously variable (40 Hz – 150 Hz) plus unﬁltered LFE direct-

coupled input. Frequency Response: 20 Hz – 150 Hz.

ProSub 1000: Dimensions: 14

"H x 17

"D x 12"W. Driver

Complement: One 10" woofer with polymer cone coupled to one 10"

infrasonic radiator. Ampliﬁer: 300 Watts RMS. Speaker Level High-Pass

Filter: 6 db/octave (80 Hz). High-Level Low-Pass Filter: 24 db/octave

continuously variable (40 Hz – 150 Hz) plus unﬁltered LFE direct-

coupled input. Frequency Response: 18 Hz – 150 Hz.

New high-deﬁnition drivers incorporate

our Balanced Double Surround System

(BDSS) technology (patent pending).

The new ProMonitors and the

ProCenters utilize pressure-coupled

planar medite passive radiators.

New ProSubs with 300 watt digital amps

feature forward-ﬁring woofers coupled to

down-ﬁring sub-bass radiators.

ProSub 1000 & 800

New ProCinema Technological Advancements
