DEGEN DE1129 Bedienungsanleitung

OPERATION MANUAL

FM STEREO AM SW DSP RECEIVER

MP3 PLAYER

DIGITAL RECORDER

REPEAT

LOUDSPEAKER

Radio/MP3 / Re co rd er

DE A-RDS

MUTE

ESC

MIC FM SW

REC

FM AM S W RA DIO/MP3 /R ECORDER

2011- 08-15

15 : 30 : 22

1129

DE1129

Radio/MP3 / Re co rd er

DE A-RDS

MUTE

ESC

MIC FM SW

REC

FM AM S W RA DIO/MP3 /R ECORDER

2011- 08-15

15 : 30 : 22

1129

Display

1 1 1 2

1 3

1 4

1 5

1 6

1 7

1 8

1 9

2 0

2 1

1 2

1 3

1 1

LOCATION OF CONTROLS

Speaker

Menu: Press to enter

Hold to go back to main menu

Escape

Mute: Turn off/on speaker

Key lock: Hold to lock/unlock

M+

In radio mode: SW button(press in SW mode to change

M Bands)

In music mode: Directly shift repeat mode

Record button: In radio mode, press to start recording

In other modes, hold to directly start MIC

recording

Volume+

Volume-

In radio mode: Frequency+

In music mode: Next song/FF

1 4

1 5

1 6

1 7

1 8

1 9

2 0

2 1

Power on/off

Stop button

Play/Pause

AM button

In music mode: press to set A-B repeat

Frequency-

In music mode: Preview song/REW

Radio/Music mode selection

FM stereo/moo selection

Built-in MIC

Antenna

Battery compartment

MICRO SD card slot

Strap hole

Tuning knob

Mini-USB jack

Line-in jack

Earphone jack

LOCATION OF CONTROLS

FM/A M/ SW R AD IO

MP3/ RE CO RD ER

FM 64 0/ 87 0-10 8 0M Hz

AM 522 -1710 KH z

5V 500 mA

2 30-2 3 00MHz

DE A-R DS

1129

BATTERY POWER SUPPLY

1. Full

4. Exhausted

2. Medium

3. Low

Before initial use, open the battery compartment (behind

the back stand), make sure the lithium battery is installed.

INSTALLING THE BATTERY

1. Turn off the unit and open the battery cover.

2. Install the provided lithium battery according to the battery

polarity.

3. Close the battery cover.

BATTERY CONSUMPTION INDICATION

Mini-USB jack

CHARGING THE LITHIUM BATTERY

To charge the battery, connect the unit to the mini-USB port

and opposite end to a power source(5V DC/≥500mA, not

provided). While charging, the battery symbol shown on the

display “ ” moves from right to left, and stops when the

battery is full charged.

A computer with a USB jack can also be used as a power

source to charge the battery.

After installing the lithium battery, connect the unit and the

computer with the provided USB cable to charge the battery.

Left side

Note: 1. Please turn off the radio while charging the battery

to avoid interference.

2. Prior to first use, fully charge and drain the battery

three times to extend the battery’s life.

Caution: 1. Improperly change of battery will cause explosion,

please only use recommended type of battery.

2. Do not expose the battery to strong sunlight, heat

or other high temperature environment.

3. Do not use the unit when charging with PC to

prevent any damage to computer power source.

Radio

SELECT

MAIN MENU

1. Turn ON/OFF manually: Press the < > button.

2. Turn off the unit by using “Alarm off” or “Sleep timer”.

3. Auto Turn Off: The unit will turn off automatically in 3

minutes if not in either Recording, Music or Radio playing

mode.

Note: If the unit can not be turned on/off, please check the

battery or the key lock button.

TURN ON/OFF THE UNIT

MAIN MENU

In any Mode, hold the < > button or press the< >

button can go back to Main Menu.

In Main Menu mode, rotate the Tuning Knob or press the

< > or < > button to select either of below function

and press the Tuning Knob to enter.

FM Radio: FM/AM/SW Radio

Music: MP3 music play mode

Record: MIC Recording mode

Voice: Recording file play mode

Ebook: Text reading mode (Support TXT)

Sys Set (system setting): Time set, date set, calendar info,

alarm set, backlight, language, sleep timer, power off mode,

contrast, memory info, firmware version, firmware upgrade,

date format, time format, exit.

Main Menu

MENU ESC

FM RADIO

In Main menu, select [FM Radio] by press the Menu button.

- Record: Select 129k/40k BPS direct radio recording

- Delete: Delete single memory

- Delete all: Delete all stored memory

- ATS: Auto tunes and store all stations into memory

- Normal Band: 87~108MHz

- Japan Band: 76~90MHz

- School Band: 64~108MHz

- Open RDS: Press to Open/Close RDS

- Update RDS time:

- AM Spacing Switch: Repeatedly press to select

9K/10K tuning step and direct enter AM listening

9K Frequency range: 522~1710KHz

10K Frequency range: 520~1710KHz

- Exit

- Save: Manual store the station into memory from 1~50

Syn the RDS time to the unit

89.8

M02

MHz

FM Radio

select your desired band. The top left corner of the

display will show the band you are listening to. When

listening to SW, press the < > button can change

<m> bands.

In Radio Mode, press the< >,< > or< > button to

CHOOSE BANDS

Press the < > button to enter either Radio or Music mode.

FM Radio

SELECT

FM AM SW

In Radio mode, press the < > button to enter radio menu.

Rotate the Tuning knob or press the < >, < > button to

select either of the below functions:

Note: 1. Do not use stereo when listening to stations with

weak signal, because the decoding process of stereo

will cause a lot of noise.

2. If you select stereo listening, but the < > symbol

is not shown on the display, it is because the signal

of the station is too weak.

VOLUME ADJUSTMENT

Press the < > or < > button to adjust your desired

volume level, the display will show the volume level.

Repeatedly press the < > button to turn on/off the

speaker.

MUTE

To activate stereo listening, press the < > button

and the display will show < > symbol; press again to

deactivate, and the mono symbol < > will show.

FM STEREO/MONO SELECTION

ANTENNA RECEPTION

1. It only works when listen to FM and SW.

2. When listen to FM or SW, you can change the length of

the antenna according to the signal intensity to get better

reception.

TUNE IN STATIONS

89.8

M02

MHz

Band symbol

Frequency display

Frequency point

Signal intensity

STORING STATIONS

Volume level (0~31)

Stereo symbo

USING BUILT-IN ANTENNA

1.It only works when listen to AM Broadcast..

2. While listening to AM station, rotate the radio to find the

position which gives the best reception, as the built-in

ferrite bar is located inside the unit and it is strongly

affected by the direction of placing of the unit.

Note: 1. To have better reception, go near a window when tuning

indoor.

2. Keep away from electrical equipment, AC power supply when

using the unit to avoid interference.

2. Do not use the unit while charging because of the interference.

Turn on the radio and select [FM Radio] in Main menu,

Press the < > button to enter, then choose your desired

band by pressing on either the FM, AM or SW button.

Using either of the methods below to tune into your desired

station:

1. Rotate the Tuning Knob or press the < >,< >

button.

2.Press and hold the < > or < > button for about

two seconds, then release to auto tune into the next

available station.

TUNE IN STATIONS

MANUAL TUNING

AUTO TUNING STORAGE(ATS)

89.8

M50

MHz

Memory Locations

In radio mode, press the < > button and rotate the Tuning

knob to select [ATS]. Press the < > button again to start

auto scan and store the available stations within the memories.

Memory Locations:

FM/SW(ATS): M51 ~ M99

AM(ATS): M26 ~ M50

NOTE: Do not use ATS while charging the unit to avoid interference.

STORING STATIONS MANUALLY

Select your desired station, press the < > button and

rotate the Tuning knob to select [Save], then rotate the

Tuning knob or press the < >,< > button to select

memory location from 1~50 in FM/SW mode or 1~25 in

AM mode. Press the < > button again to confirm.

Memory Locations:

FM/SW(manual storage): M1 ~ M50

AM(manual storage): M1 ~ M25

LISTENING TO STORED MEMORIES

After storing stations into memory, press the < > or < >

button with the memory address M01~M99 shown on the

display(next to the frequency) to select your desired station

memory.

910

DELETE STORED MEMORIES

DELETE SINGLE/ALL MEMORIES

Press the < > button in radio mode, and rotate the

Tuning knob to select either <Delete> or <Delete All>

and press the < > button again to delete single

memory or all memories.

FM RDS

1. Select an FM station, press the < > button and select

<Open RDS>, the symbol < > will show on the

display.

2. Press the < > button to shift the transmitted details

(display on the bottom of the screen).

FM RDS

87.8

M50

MHz

PTY

info. SZ87.8

RDS is on

3. Update RDS time:

display, press the < > button and rotate the Tuning

knob to select <Update RDS Time>.

4. Press the < > button and rotate the Tuning knob to

select <Close RDS> to turn RDS off.

Only when the time shows on the

PTY: Program Type

PS: Station Name

RT: Station Text Message (Only display if the station has

transmitted)

CT: Update RDS time (wait about 2-3 minutes to get the

RDS time)

Note: 1. You can receive the RDS information only if the

station has this function.

2. You can get the complete RDS information when

the signal is full. If the RDS signal is weak, please

find another location to receive clear reception.

11 12

LISTEN TO MP3 FILES

1. Turn on the unit and select [Music] from Main menu, then

press the < > button to enter.

003 00:01:57

Gaga Poker Face

Play( ) Pause( ) Stop ( )

No. of the music files

Name of the song and players

“T” refers to LRC available

format and Kbps

Sound quality mode

Repeat mode

2. Rotate the Tuning Knob or press the < > or < >

button to select music file.

To search for a particular song, you can press the < >

button in Stop Playing Mode and select Local folder to find.

3. Press the < > button to play, press it again to pause;

press the < > button to stop.

4. While playing music file, press the < > button to enter

the following settings:

- Repeat: Normal [ ], Repeat One [ ], Repeat All [ ],

Random [ ]

- Equalizer: Natural, Rock, Pop, Classic, Soft, Jazz, Bass,

3D sound

- Tempo rate: -8 to 8 levels, 0 refers to normal speed.

- Lyrics: Press the the < > button to turn on/off

- Exit

Note: 1. A shortcut to the Music playing in radio mode is to

directly press the < > button.

2. The Lyrics must be in LRC format, use the same

name as the song and must be located in the same

folder.

RECORD RADIO

While listen to the FM/AM/SW stations, you can directly

record the programs by following the steps below:

1. Adjust the volume level up to 10 (minimum).

2. Press the < > button and select [Record], then rotate

the Tuning knob to choose either of below recording

formats:

- 129k BPS (WAV format, max 68 hours, 4G,)

- 40k BPS (MP3 format, max 215 hours, 4G)

3. Press the < > button to confirm your selection and

start recording. The timer on the display starts to count.

4. Press the < > button to pause and press it again to

restart, press the < > button to stop and auto store

the recorded file into the memory.

All recorded files can be located in the <Voice> folder of the

<Main Menu>.

Note: A shortcut to the recording function is to directly press

the < > button, recording format is according to your

last selection.

REC

RECORD RADIO

LISTEN TO MP3 FILES

13 14

LISTEN TO MP3 FILES A-B REPEAT

DELETE MUSIC FILES

While not playing any music, press the < > button to enter

the following settings:

- Local folder: Select music file

- Delete file: Delete a single music file

- Delete all: Delete all music files

- Exit

3. When playing the music, press the < > and the < >

button can directly shift Repeat Type and Equalizer.

4. Bass equalizer is used for earphone listening, please

select other equalizer when using speaker.

LISTEN TO THE FILES IN THE SD CARD

Transfer your selected MP3 format music files into the

MICRO-SD card, insert the SD card into the slot at the bottom

of the unit. Then turn on the unit, press the < > button in

the music mode to enter the [music playing menu], and find

the files.

NOTE:

may cause unit dead or file missing.

2. SD card can not save recording files, recorded files can only

be saved in the <Voice> folder.

1. Do not extract or insert the SD card when the unit is on. It

Note: Your can also connect the unit to the computer to

delete files.

To operate above settings, press the < > button to enter or

confirm, rotate the Tuning Knob or press the < >, < >

button for selection.

When playing the music, press < > once to activate,

< > appears on the display with “A” flashes, press < >

again to set the starting point “A”, then “B” flashes. When

reaches your desired position, press < > again to set the

ending point “B”. Then the unit will repeat from A to B. While

repeating, press < > can cancel the repeating and keep

on playing the music.

A-B REPEAT

15 16

MIC RECORD

other

audio

devices

USE AS AN ACTIVE LOUDSPEAKER(LINE-IN)

Connect the unit to other medias( MP3, voice recorder,

Laptop, etc.) with a Line-in cable, can increase the sound of

the connected media.

1. Plug one end of the Line-in cable to the earphone jack of

the audio equipment, and the other end into the Line-in jack

of the unit.

press the < > button to enter.

3. Adjust the volume to a proper level, turn on the audio

equipment, the sound will come out from the speaker of

the unit.

Turn on the unit and select [FM Radio] in [Main Menu],

Select [Record] in [Main Menu], press the < > to enter.

1. Press the < > button to select REC type:

- Long Rec (Long time recording- 64K, WAV format)

- High Rec (High quality recording- 129K, WAV format)

- Fine VOR (High quality voice sensor recording- 128K,

VOR format)

MIC Record Mode

018 30:01:50

REC019 11/01/20

File NO./ Time

Rest recording time

Year/Month/Date

Record format

019 00:00:00

Record mode symbol

Fine VOR: If the audio source volume is too low, the recording

will pause until the audio source volume increase

to a recognizable level.

2. After select desired record format, press the < > button

to start, press the < >button to pause/restart, and press

the < > button to stop. And the recorded file can be

found in the local folder of [Voice] .

REC

NOTE: Only under [FM Radio] mode, the unit be used

as an active loudspeaker.

can

USE AS AN ACTIVE LOUDSPEAKER

MIC RECORD

17 18

Inhaltsverzeichnis

Andere DEGEN MP3-Player Handbücher

DEGEN

DEGEN DE1128 Bedienungsanleitung

Beliebte MP3-Player Handbücher anderer Marken

Blaupunkt

Blaupunkt Compact Drive MP3 Bedienungsanleitung

Memorex

Memorex MMP9008 - 8GB USB 2.0 Bedienungsanleitung

Meizu Electronic Technology

Meizu Electronic Technology E5 Bedienungsanleitung

Naxa

Naxa NMV-173NX Bedienungsanleitung

Philips

Philips PSA250 Bedienungsanleitung

Zipy

Zipy go! Waving Bedienungsanleitung

Sylvania

Sylvania SMPK4068 Bedienungsanleitung

Sony

Sony NW-MS7 - Memory Stick Walkman Bedienungsanleitung

Irradio

Irradio RF-42UC Bedienungsanleitung

NABAIJI

NABAIJI SWIM MUSIC 100 Bedienungsanleitung

Laser

Laser MP3-A9-4GB Bedienungsanleitung

Samsung

Samsung YP-T7F Bedienungsanleitung

Savant

Savant SMS-1001-00 Kurzanleitung

Trevi

Trevi XP 71 BT Bedienungsanleitung

AGPtek

AGPtek C2 Bedienungsanleitung

MobiBlu

MobiBlu DAH-1500i Bedienungsanleitung

Denver

Denver MPS-201 Bedienungsanleitung

Steren

Steren MP3-002 Bedienungsanleitung
