OPERATOR'S MANUAL
TDU series
Touch Display Unit
4189341218G
1. About the Operator's manual
1.1 Symbols for notes..................................................................................................................................................................................................................... 4
1.2 Symbols for hazard statements......................................................................................................................................................................................... 4
1.3 Intended users of the Operator's manual.....................................................................................................................................................................5
1.4 Software versions......................................................................................................................................................................................................................5
1.5 Technical support .....................................................................................................................................................................................................................5
1.6 Warnings and safety.................................................................................................................................................................................................................6
1.7 Legal information.......................................................................................................................................................................................................................6
2. Getting started
2.1 About controller operation .................................................................................................................................................................................................. 8
2.2 About the TDU............................................................................................................................................................................................................................. 9
2.2.1 Layout of unit........................................................................................................................................................................................................................9
2.2.2 Top bar................................................................................................................................................................................................................................. 10
2.2.3 Touch screen areas.........................................................................................................................................................................................................11
2.2.4 Core connections.............................................................................................................................................................................................................12
2.2.5 Extended connections................................................................................................................................................................................................... 13
3. Operating the system
3.1 Menus.............................................................................................................................................................................................................................................15
3.1.1 Return (back) navigation.............................................................................................................................................................................................. 15
3.2 Keyboards............................................................................................................................................................................................................................16
3.2.1 Text keyboard....................................................................................................................................................................................................................16
3.2.2 Value keyboard.................................................................................................................................................................................................................17
3.3 Controller basic actions...................................................................................................................................................................................................... 18
3.3.1 Modes...................................................................................................................................................................................................................................18
3.3.2 Start the genset................................................................................................................................................................................................................ 18
3.3.3 Stop the genset................................................................................................................................................................................................................ 19
3.3.4 Close the genset breaker............................................................................................................................................................................................. 19
3.3.5 Open the genset breaker..............................................................................................................................................................................................20
3.4 Software update using USB......................................................................................................................................................................................21
3.4.1 Before you begin..............................................................................................................................................................................................................21
3.4.2 Download and update software.................................................................................................................................................................................21
4. Features
4.1 Home : Control panel..................................................................................................................................................................................................... 22
4.1.1 Change instrument..........................................................................................................................................................................................................23
4.1.2 Instrument property.........................................................................................................................................................................................................24
4.1.3 Engine information................................................................................................................................................................................................... 25
4.2 Supervision......................................................................................................................................................................................................................... 26
4.3 Controller settings...........................................................................................................................................................................................................27
4.3.1 Edit settings................................................................................................................................................................................................................ 28
4.3.2 Filter groups................................................................................................................................................................................................................29
4.4 Alarms.................................................................................................................................................................................................................................... 30
4.4.1 Alarm popup.......................................................................................................................................................................................................................31
4.5 DM1 Active alarms......................................................................................................................................................................................................... 32
OPERATORS MANUAL 4189341218G EN Page 2 of 53
4.6 DM2 Inactive alarms...................................................................................................................................................................................................... 33
4.7 Logs.........................................................................................................................................................................................................................................34
4.8 Exhaust After-Treatment Dashboard (Tier4)..................................................................................................................................................... 35
4.9 Alternator curve................................................................................................................................................................................................................ 36
4.10 Additional Operator Panel (AOP)..........................................................................................................................................................................37
4.11 Language............................................................................................................................................................................................................................38
4.12 User permissions.......................................................................................................................................................................................................... 39
4.12.1 Password levels.............................................................................................................................................................................................................39
4.12.2 User permissions.......................................................................................................................................................................................................... 39
4.13 Display config..................................................................................................................................................................................................................40
4.13.1 More settings.................................................................................................................................................................................................................. 41
4.13.2 Top bar colour.................................................................................................................................................................................................................42
4.13.3 Widget config...........................................................................................................................................................................................................43
4.14 Language Mgt..................................................................................................................................................................................................................44
5. Functions
5.1 Branding images......................................................................................................................................................................................................................45
5.1.1 How it works.......................................................................................................................................................................................................................45
5.1.2 Before you begin..............................................................................................................................................................................................................45
5.1.3 Import branding images................................................................................................................................................................................................ 46
5.2 Language translations..........................................................................................................................................................................................................47
5.2.1 How it works.......................................................................................................................................................................................................................47
5.2.2 Before you begin..............................................................................................................................................................................................................47
5.2.3 Create or edit language translation..........................................................................................................................................................................47
5.3 Export or import settings....................................................................................................................................................................................................49
5.3.1 How it works.......................................................................................................................................................................................................................49
5.3.2 Before you begin..............................................................................................................................................................................................................49
5.3.3 Export or import configuration file.............................................................................................................................................................................49
5.4 Widget config......................................................................................................................................................................................................................50
5.4.1 How it works.......................................................................................................................................................................................................................50
5.4.2 Before you begin..............................................................................................................................................................................................................50
5.4.3 Add or configure widgets..............................................................................................................................................................................................50
5.5 Access lock................................................................................................................................................................................................................................ 52
6. End-of-life
6.1 Disposal of waste electrical and electronic equipment..................................................................................................................................... 53
OPERATORS MANUAL 4189341218G EN Page 3 of 53
1. About the Operator's manual
1.1 Symbols for notes
More information
This highlights where to find more information.
NOTE * This highlights a referenced note.
Example heading
This highlights an example.
How to ...
This shows a link to a video for help and guidance.
This highlights tapping or pressing the screen area.
This highlights pressing and holding the screen area for an amount of seconds.
This highlights swiping the screen area, up or down.
This highlights swiping the screen area, left or right.
1.2 Symbols for hazard statements
DANGER!
This shows dangerous situations.
If the guidelines are not followed, these situations will result in death, serious personal injury, and equipment damage or
destruction.
WARNING
This shows potentially dangerous situations.
If the guidelines are not followed, these situations could result in death, serious personal injury, and equipment damage
or destruction.
CAUTION
This shows low level risk situation.
If the guidelines are not followed, these situations could result in minor or moderate injury.
OPERATORS MANUAL 4189341218G EN Page 4 of 53
NOTICE
This shows an important notice
Make sure to read this information.
1.3 Intended users of the Operator's manual
This is the Operator's manual for DEIF's Touch Display Unit, TDU for controlling the AGC-4 Mk II or AGC-4 genset or mains
controller.
The manual is for the operator who uses the TDU. The manual includes an introduction to the display, basic operator tasks, alarms,
logs, and more advanced operator tasks.
NOTE The manual does not describe self-explanatory functions that the operator can easily explore. For example, the Service
menu and its Live Data and Service Timers pages.
1.4 Software versions
The information in this document corresponds to the following software versions.
Table 1.1 Software versions
Software Details Version
AGC-4 Mk II Controller application 6.00.x or later
AGC-4 Controller application 4.76.x or later
• TDU 107 Core
• TDU 107 Extended
• TDU 110 Extended
• TDU 115 Extended
Display application 1.3.9.x or later
1.5 Technical support
You can read about service and support options on the DEIF website, http://www.deif.com. You can also find contact details on the
DEIF website.
You have the following options if you need technical support:
• Technical documentation: Download all the product technical documentation from the DEIF website: http://www.deif.com/
documentation
• Support: DEIF offers 24-hour support. See http://www.deif.com/support for contact details. There may be a DEIF subsidiary
located near you. See http://www.deif.com/support/local-office
OPERATORS MANUAL 4189341218G EN Page 5 of 53
1.6 Warnings and safety
DANGER!
Hazardous live currents and voltages
Risk of electrical shock
Switchboard access must only be carried out by authorised personnel who understand the risks involved in working with
electrical equipment. Do not touch any terminals, especially the controller AC measurement inputs and the relay
terminals. Touching the terminals could lead to injury or death.
WARNING
Possible automatic genset starts
Risk of personal injury
The power management system automatically starts gensets when more power is needed. It can be difficult for an
inexperienced operator to predict which gensets will start. In addition, gensets can be started remotely (for example, by
using an Ethernet connection, or a digital input). To avoid personal injury, the genset design, the layout, and
maintenance procedures must take this into account.
NOTICE
Manually overriding alarm actions
Risk of damage to genset or equipment
Manually overriding alarm actions could cause damage to the genset or equipment. Do not use manual control to
override the alarm action of an active alarm.
NOTICE
Manual control
Limited automatic protection actions
Under Manual control, the operator controls and operates the equipment from the switchboard. The controller does not; respond to
blackouts, provide any power management, accept operator commands, and/or prevent any manual operator actions. The
switchboard design must therefore ensure that the system is sufficiently protected when the controller is under Manual control.
1.7 Legal information
Trademarks
DEIF is a trademark of DEIF A/S.
All trademarks are the properties of their respective owners.
Third party equipment
DEIF takes no responsibility for the installation or operation of any third party equipment, including the genset. Contact the genset
company if you have any doubt about how to install or operate the genset.
OPERATORS MANUAL 4189341218G EN Page 6 of 53
Disclaimer
DEIF A/S reserves the right to change any of the contents of this document without prior notice.
The English version of this document always contains the most recent and up-to-date information about the product. DEIF does not
take responsibility for the accuracy of translations, and translations might not be updated at the same time as the English document.
If there is a discrepancy, the English version prevails.
Copyright
© Copyright DEIF A/S. All rights reserved.
OPERATORS MANUAL 4189341218G EN Page 7 of 53
2. Getting started
2.1 About controller operation
The Touch Display Unit (TDU) is a touch screen solution for controlling an AGC genset or mains controller using the Ethernet port. *
Example connection
Ethernet Service port Display
CAN A
CAN B
Ethernet
Power
Self check ok
Alarm inhibit Mk II
98 100 102 104 106 108 110 112 114 116
73 74 75 76 77 78
Ethernet connection
NOTE * The AGC-4 requires the Ethernet option N for connection.
The display gives user-friendly touch screen control, visualisation, and graphic displays from the AGC.
Simply operate the controller and access any feature by touching the screen.
This manual applies to all TDU series screens. Some features are only available on certain TDU versions.
NOTICE
Bridged Ethernet ports
The TDU 107 Extended, TDU 110 Extended, and TDU 115 Extended have two Ethernet that are bridged, ETH0 and
ETH1.
OPERATORS MANUAL 4189341218G EN Page 8 of 53
2.2 About the TDU
2.2.1 Layout of unit
AOP
1 / 6
SEMIAMF
09/05/2019 - 12:46:16
DEIF 24 %
Generator voltage L1-L2
Generator power
Total Running hours
Generator f L2
1* Hz
h
kW
V
400
0
400
50,00
1
2
No. Item Notes
1 Touch screen area Operate the controller by touching the screen.
2 Frame
OPERATORS MANUAL 4189341218G EN Page 9 of 53
2.2.2 Top bar
No. Item Use Notes
1 Fuel level * - Shows the fuel level.
2 Diesel Exhaust Fluid (DEF) percentage ** - Shows the DEF percentage.
3 Running hours *** - Shows the total of running hours.
4 USB drive
- Shows a USB drive was detected.
Prompts to remove the USB drive safely.
5 User logged on
Shows a user is logged on.
Displays prompt to logout.
6 Exhaust After-Treatment Dashboard Opens Exhaust After-Treatment Dashboard (Shortcut). *
7 Alarm(s) Opens Alarms (Shortcut).
8 Language Opens Language (Shortcut).
9 Date and Time - Shows the controller Date and Time.
NOTE * Only shown if the fuel level is configured with a multi-input. Use either multi-input 102 parameter 10980, multi-input 105
parameter 10990, or multi-input 108 parameter 11000 with RMI fuel level.
** Only shown if the Engine communication is configured.
*** Only shown for genset controllers and not on mains controllers.
OPERATORS MANUAL 4189341218G EN Page 10 of 53
Dieses Handbuch passt für folgende Modelle
4
Inhaltsverzeichnis
Beliebte Touch-Screen Handbücher anderer Marken
Elecro Engineering
Elecro Engineering Poolsmart Plus Montageanleitung
Johnson Controls
Johnson Controls IQ4 HUB Bedienungsanleitung
Elo TouchSystems
Elo TouchSystems ET2270L Bedienungsanleitung
Elo TouchSystems
Elo TouchSystems ET1002L Bedienungsanleitung
Elo TouchSystems
Elo TouchSystems 3201L Bedienungsanleitung
Duratec
Duratec S15 Bedienungsanleitung
