Short Form Specifications
Exterior Body is constructed of 18-gauge stainless steel side panels and
14-gauge galvanized bottom. All exterior side panels are reinforced with
overlapping corners and welded in place. All body cutouts and stress
points are reinforced with 14-gauge galvanized channel supports.
Exterior Top is constructed of 14-gauge stainless steel, welded, ground and
polished into one integral unit. Top is fabricated with square exterior corners.
Carving Tray; unit has a removable, stainless steel, perforated carving tray,
pan and meat holder. A 250 watt heat lamp is mounted directly over the
carving tray. Underneath the carving area is a stainless steel lining for easy
cleaning.
Au Jus Well; unit has a 250 watt heated stainless steel au jus well with
adjustable thermostat and stainless steel insert pan. Heat lamp and au jus
well are wired to a 120 volt, 50 Hertz, single phase, 3-wire grounded,
maximum 10’ (3m) cord and plug.
Dry Compartment; unit has a one-door dry compartment constructed of
18-gauge stainless steel. Compartment is equipped with a shelf. Door has
double-wall construction, with a stainless steel front panel.
Casters: units are mounted on 5” (12.7cm) diameter swivel casters
with non-marking polyolefin tires and plate brakes. Overall height of
casters assembly is 6” (15.2cm).
Optional Accessories and Modifications
A) 12” (30.5cm) wide stainless steel fold-down tray slide
C) 10” (25.4cm) wide three-bar fold-down tray slide
D) 10” (25.4cm) wide composite fold-down cutting boards
E) 10” (25.4cm) wide stainless steel fold-down work shelf
F) Line-up interlock device
Q) 120V/60Hz/1ø, 10 amp convenience outlet with breaker
ST) Stainless steel trim strips
T) Heated understorage (667 watt heating element) with wire shelf
U) 14” x 30” (35.6cm x 76.2cm) stainless steel end drop shelf
V) 6” (15.2cm) high adjustable stainless steel legs in lieu of casters
X) Laminate exterior panels in lieu of stainless steel exterior panels
Model SRB
Mobile Carving Counters
SRB
