Dell All-In-One Printer 948 User's Guide

file:///T|/htdocs/systems/prn948/en/en/index.html[10/10/2012 11:05:17 AM]

Dell™ All-In-One Printer 948 User's Guide

To order ink or supplies from Dell:

1. Double-click the icon on your desktop.

2. Visit Dell's website, or order Dell printer supplies by phone.

www.dell.com/supplies

For the best service, make sure you have the Dell printer Service Tag available.

Finding Information Understanding the Software

About Your Printer Wireless Networking

Understanding the Operator Panel Menus Peer-to-Peer Networking

Loading Paper and Originals Maintenance

Printing Troubleshooting

Printing From a Memory Card or USB Key Specifications

Copying Appendix

Scanning Licensing Notice

Faxing

Notes, Notices, and Cautions

Information in this document is subject to change without notice.

Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell, the DELL logo, Dell Picture Studio, and Dell Ink Management System are trademarks of Dell Inc.; Microsoft and

Windows are registered trademarks of Microsoft Corporation in the United States and/or other countries. Windows Server and Windows NT are

registered trademarks of Microsoft Corporation. Windows Vista is either a trademark or a registered trademark of Microsoft Corporation in the United

States and/or other countries. Bluetooth is a registered trademark owned by Bluetooth SIG, Inc. and is used by Dell Inc. under license. EMC is a

registered trademark of EMC Corporation.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products.

Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.

UNITED STATES GOVERNMENT RESTRICTED RIGHTS

This software and documentation are provided with RESTRICTED RIGHTS. Use, duplication or disclosure by the Government is subject to restrictions

as set forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013 and in applicable FAR

provisions: Dell Inc., One Dell Way, Round Rock, Texas, 78682, USA.

NOTE: A NOTE indicates important information that helps you make better use of your printer.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the

problem.

CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.

Dell All-In-One Printer 948 User's Guide

file:///T|/htdocs/systems/prn948/en/en/index.html[10/10/2012 11:05:17 AM]

Model 948

July 2007 SRV UY127 Rev. A00

Finding Information

file:///T|/htdocs/systems/prn948/en/en/d0e56.html[10/10/2012 11:05:19 AM]

Finding Information

What are you

looking for? Find it here

Drivers for my

printer

My User's

Guide

Drivers and Utilities CD

If you purchased your Dell computer and printer at the same time, documentation and drivers for your

printer are already installed on your computer. You can use the CD to uninstall/reinstall drivers or

access your documentation. Readme files may be included on your CD to provide last-minute updates

about technical changes to your printer or advanced technical reference material for experienced users

or technicians.

How to set up my

printer Setting Up Your Printer poster

Safety

information

How to set up

and use my

printer

Warranty

information

Owner's Manual

Express Service

Code and Service

Tag number

Express Service Code and Service Tag number

Finding Information

file:///T|/htdocs/systems/prn948/en/en/d0e56.html[10/10/2012 11:05:19 AM]

For more information, see Express Service Code.

Latest drivers

for my printer

Answers to

technical

service and

support

questions

Documentation

for my printer

Dell Support Website: support.dell.com

The Dell Support website provides several online tools, including:

Solutions—Troubleshooting hints and tips, articles from technicians, and online courses

Upgrades—Upgrade information for components, such as memory

Customer Care—Contact information, order status, warranty, and repair information

Downloads—Drivers

Reference—Printer documentation and product specifications

How to use

Windows

Vista™

Documentation

for my printer

Windows Vista Help and Support Center

1. Click ®Help and Support.

2. Type a word or phrase that best describes your problem, and then click the arrow icon.

3. Click the topic that describes your problem.

4. Follow the instructions shown on the screen.

How to use

Windows®XP

Documentation

for my printer

Windows XP Help and Support Center

1. Click Start®Help and Support.

2. Type a word or phrase that best describes your problem, and then click the arrow icon.

3. Click the topic that describes your problem.

4. Follow the instructions shown on the screen.

Understanding the Software

file:///T|/htdocs/systems/prn948/en/en/d0e8996.html[10/10/2012 11:05:21 AM]

Understanding the Software

Using the Dell All-In-One Center

Using the Dell Fax Solutions Software

Using Printing Preferences

Using Memory Card Manager

Dell Ink Management System

Removing and Reinstalling Software

The printer software includes:

Dell All-In-One Center– Allows you to perform various scan, copy, fax, and print operations with newly scanned and

previously saved documents and images.

Dell Fax Solutions Software– Allows you to fax electronic or scanned documents.

Printing Preferences– Allows you to adjust printer settings.

Memory Card Manager– Allows you to display, manage, edit, print, and scan photos from your memory card or USB

memory key to your computer.

Dell Ink Management System™– Warns you when your printer is running low on ink.

Using the Dell All-In-One Center

The Dell All-In-One Center allows you to:

Scan, copy, fax, and use productivity tools.

Select where you want to send the scanned image.

Select the quantity and color of your copies.

Understanding the Software

file:///T|/htdocs/systems/prn948/en/en/d0e8996.html[10/10/2012 11:05:21 AM]

Access troubleshooting and maintenance information.

Preview images you want to print or copy.

Manage photos (copy them to folders, print them, perform creative copying).

To access the Dell All-In-One Center:

1. In Windows Vista™:

a. Click ®Programs.

b. Click Dell Printers.

c. Click Dell AIO Printer 948.

In Windows®XP and Windows 2000:

Click Start®Programs or All Programs®Dell Printers®Dell AIO Printer 948.

2. Select Dell All-In-One Center.

The Dell All-In-One Center includes four main sections:

In this section: You can:

Preview Now Select a portion of the preview image to scan or copy.

View an image of what will be printed or copied.

Scan and Fax Select the program where you want to send the scanned image.

Select the type of image being scanned.

Select a quality setting for your scan.

Select Scan Now to scan your document or photo.

Select Fax Now to scan, and then fax a copy of your document or photo.

NOTE: Click See More Scan Settings to view all settings.

Copy Select the quality and color of your copies.

Select a quality setting for your copies.

Specify the blank paper size.

Specify the size of the original document being copied.

Lighten or darken your copies (this can also be accomplished using the operator panel).

Resize your copies.

Select Copy Now to create copies.

NOTE: Click See More Copy Settings to view all settings.

Productivity Tools Fax an image or document.

Access the Dell Fax Setup Utility.

E-mail an image or document.

Repeat an image several times on one page.

Resize an image.

Print an image as a multi-page poster.

Print more than one page on a sheet of paper.

Save an image on your computer.

Save multiple photos.

Scan and save to PDF.

Edit text found in a scanned document (Optical Character Recognition).

Modify an image with a photo editor.

Understanding the Software

file:///T|/htdocs/systems/prn948/en/en/d0e8996.html[10/10/2012 11:05:21 AM]

For more information, click Help in the Dell All-In-One Center.

Using the Dell Fax Solutions Software

The Dell Fax Solutions Software allows you to:

Send fax.

Click Send a new fax, and then follow the instructions on the computer screen.

Adjust other fax settings.

Click Adjust speed dial list and other fax settings to customize various fax settings.

View and manage your phonebook.

Click View phonebook to open the Phone book. You can add, edit, or delete contact and group information. You can

also add a contact or group to your speed dial list.

View and customize cover page.

Click View cover pages to open the Cover Pages dialog. You can customize, add logos to, or choose from a variety of

different ready-made cover pages for your fax.

View fax history.

Click View full activity log to see or print a detailed list of all fax activity.

Create a fax report.

Click Print activity report to see a detailed report of all fax activity. Click the Print icon to print your activity report.

To access the Dell Fax Solutions Software:

1. In Windows Vista:

a. Click ®Programs.

b. Click Dell Printers.

c. Click Dell AIO Printer 948.

In Windows XP and 2000:

Click Start®Programs or All Programs®Dell Printers®Dell AIO Printer 948.

2. Click Dell Fax Solutions.

Understanding the Software

file:///T|/htdocs/systems/prn948/en/en/d0e8996.html[10/10/2012 11:05:21 AM]

The Dell Fax Solutions Software dialog box opens.

Using Printing Preferences

You can change your printer settings in Printing Preferences depending on the type of project you want to create.

To access Printing Preferences when a document is open:

1. Click File®Print.

The Print dialog box opens.

2. Click Preferences, Properties, Options, or Setup (depending on the program or operating system).

The Printing Preferences dialog box opens.

To access Printing Preferences when a document is not open:

1. In Windows Vista:

a. Click ®Control Panel.

b. Click Hardware and Sound.

c. Click Printers.

In Windows XP, click Start®Settings®Control Panel®Printers and Other Hardware®Printers and Faxes.

In Windows 2000, click Start®Settings®Printers.

2. Right-click the Dell 948 icon.

3. Click Printing Preferences.

The Printing Preferences dialog box has three sections:

NOTE: Changes made to the printer settings from the Printers folder become the default settings for most

programs.

Tab Options

Understanding the Software

file:///T|/htdocs/systems/prn948/en/en/d0e8996.html[10/10/2012 11:05:21 AM]

Using Memory Card Manager

Print Setup Quality/Speed — Select Automatic, Draft, Normal, or Photo depending on your desired output quality.

Draft is the fastest option but should not be selected if you have a photo cartridge installed.

Media Type — Allows you to set the paper type manually, or have the printer detect the paper type

automatically.

Paper Size — Select the size of your paper.

Print in black and white — Print your color images in black and white to save the ink in your color cartridge.

NOTE: You cannot select this setting if you have selected Use Color Cartridge for all Black Printing.

Borderless — Select the check box if you want to print borderless photos.

Orientation — Select how the document is arranged on the printed page. You can print using portrait or

landscape orientation.

Envelope — Select the check box if you want to print an envelope. The Paper Size area lists the envelope

sizes available for printing.

Copies — Customize how the printer prints several copies of a single print job: Collated, Normal, or Print

Last Page First.

Advanced 2-sided printing — Select this to print on both sides of the paper. Select from Automatic, Manual, or Print

Duplex.

Extend dry time — Select this option if you notice ink is smeared on the bottom of the pages of your duplex

print jobs. This allows the ink on the paper to dry before the duplex unit feeds it back into the printer, and

prints on the other side.

NOTE: You will need to wait a few seconds longer for your duplex jobs to finish if your turn this feature on.

Layout — Select Normal, Banner, Mirror, N-up, Poster, Booklet, or Borderless.

Automatic Image Sharpening — Automatically select the best image-sharpening level based on image content.

Dell Customer Experience Improvement Program — Allows you to access information about, and change your

status in, the Dell Customer Experience Improvement Program.

More Options — Allows you to specify Appearance Mode and Complete-A-Print settings. You can also view

the paper type that the printer detects.

Maintenance Install Ink Cartridges

Clean Ink Cartridges

Align Ink Cartridges

Print a Test Page

Network Support

Understanding the Software

file:///T|/htdocs/systems/prn948/en/en/d0e8996.html[10/10/2012 11:05:21 AM]

Memory Card Manager allows you to display, manage, edit, print, and save photos from your memory card or USB memory

key to your computer.

To launch Memory Card Manager:

1. Insert a memory card into the memory card slot or a USB key into the PictBridge port on the front of the printer.

2. In Windows Vista:

a. Click ®Programs.

b. Click Dell Printers.

c. Click Dell AIO Printer 948.

In Windows XP and 2000:

Click Start®Programs or All Programs®Dell Printers®Dell AIO Printer 948.

3. Select Activate Memory Card Manager.

Dell Ink Management System

Each time you print a job, a printing progress screen appears, which shows the progress of the print job as well as the

amount of ink remaining and the approximate number of pages remaining in the cartridge. The page counter is hidden during

the first 50 pages of cartridge use, until printing habits are learned and a more accurate count can be given. The number of

pages remaining changes as a result of the type of print jobs the printer completes.

When your ink cartridge levels are low, a Low Ink Warning appears on your screen when you try to print. This warning is

displayed every time you print until you install a new ink cartridge. For more information, see Replacing Ink Cartridges.

When one or both of your ink cartridges are empty, the Reserve Tank window appears on your screen when you try to print.

If you continue printing, the print job may not print as you expect.

If your black ink cartridge is out of ink, you can choose to print black from the color ink cartridge (Process Black) by selecting

Complete-A-Print before clicking the Continue Printing button. If you select Complete-A-Print and click Continue

NOTICE: Do not remove the memory card or USB key, or touch the printer near the area of the memory card or

USB key while actively reading, writing, or printing from these devices. Data corruption can occur.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Dell Multifunktionsdrucker Handbücher

Dell

Dell B5465dnf Mono Laser Printer MFP Bedienungsanleitung

Dell

Dell A960 All In One Personal Printer Bedienungsanleitung

Dell

Dell H815dw Bedienungsanleitung

Dell

Dell V525W Bedienungsanleitung

Dell

Dell 924 - Photo All-In-One Inkjet Bedienungsanleitung

Dell

Dell Printer 964 Bedienungsanleitung

Dell

Dell 7330 Stücklistenhandbuch

Dell

Dell 7330 Bedienungsanleitung

Dell

Dell A920 - Personal All-in-One Printer Color... Bedienungsanleitung

Dell

Dell 962 Bedienungsanleitung

Dell

Dell A960 - Personal All-in-One Printer Color... Bedienungsanleitung

Dell

Dell 7330 Bedienungsanleitung

Dell

Dell P513w Series Bedienungsanleitung

Dell

Dell 2135CN Bedienungsanleitung

Dell

Dell 968w - All-in-One Wireless Printer Color... Bedienungsanleitung

Dell

Dell B3465DN Bedienungsanleitung

Dell

Dell A920 - Personal All-in-One Printer Color... Bedienungsanleitung

Dell

Dell 1355CNW Bedienungsanleitung

Dell

Dell B5465dnf Mono Laser Printer MFP Bedienungsanleitung

Dell

Dell 922 - Photo All-in-One Printer 922 Bedienungsanleitung

Dell

Dell H815dw Bedienungsanleitung

Dell

Dell 7330 Handbuch

Dell

Dell Multifunction Laser Printer 5535dn Bedienungsanleitung

Dell

Dell 962 All In One Photo Printer Bedienungsanleitung

Beliebte Multifunktionsdrucker Handbücher anderer Marken

Triumph Adler

Triumph Adler DC 2016 Handbuch

Epson

Epson WorkForce WF-2510 Benutzerhandbuch

Epson

Epson Stylus Scan 2000 Installations- und Betriebshandbuch

Epson

Epson PictureMate Snap PM 240 Bedienungsanleitung

Konica Minolta

Konica Minolta bizhub C35 Bedienungsanleitung

Brother

Brother MFC-J430w Bedienungsanleitung

Konica Minolta

Konica Minolta BIZHUB 558 Bedienungsanleitung

Lexmark

Lexmark MX710 Series Handbuch

Brother

Brother MFC-9760 Bedienungsanleitung

Lexmark

Lexmark XC8155 Bedienungsanleitung

Lexmark

Lexmark X642E Bedienungsanleitung

Sharp

Sharp MX-2310U Leitfaden

Aficio

Aficio 200 Bedienungsanleitung

Canon

Canon ImageCLASS 2300 Handbuch

Ricoh

Ricoh Pro C900 Bedienungsanleitung

Lexmark

Lexmark X925 Bedienungsanleitung

Brother

Brother Business Smart MFC-J4510dw Bedienungsanleitung

Epson

Epson Stylus CX8400 Series Bedienungsanleitung
