Dell Color Laser Printer 2130cn Bedienungsanleitung

Dell 2130cn

Service Manual

22 April 2010

Information in this document is subject to change without notice.

Reproduction in any manner whatsoever without the written permission of Dell Inc.is strictly forbidden.

Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.

Other trademarks and trade names may be used in this document to refer to the entities claiming the marks and

names of their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than

its own.

Version record

Refer to the portion indicated by change bar in each section.

Also refer to the reasons in table below.

Version Issu e date Note

1st March 19, 2010 1st issued

1.1st April 30, 2010

1.1st version issued

Introduction

- The content was reviewed.

Chapter 1:Troubleshooting

- The content was reviewed.

Chapter 2:Operation of Diagnostic

- The content was reviewed.

Chapter 3:RRP

-The content was reviewed.

Chapter 4:Plug/Jack Connector Locations

- The illustration was changed.

Chapter 6:Principles of Operation

-The content was reviewed.

Chapter 8:Printer Specifications

- The content was reviewed.

1.2st May 19, 2010

1.2st version issued

Introduction

- The content of "4.5.2 Caution la bel f or tone r

cartridges" was updated.

Chapter 5 : Parts List

- Correction according to change of spare parts.

2nd June 16, 2010

2nd version issued

Chapter 1:Troubleshooting

- The check result of development was

reflected.

Chapter 3:RRP

- The error in writing was corrected.

Chapter 4: Plug/Jack Connector Locations

- The error in writing was corrected.

Chapter 5: Parts List

- The error in writing was corrected.

Chapter 6:Principles of Operation

- The content was reviewed.

Chapter 7: Wiring Diagrams and Signal

Information CONTENTS

- The content was reviewed.

Chapter 8: Printer Specifications

- The content was reviewed.

Cautions

Operation contents of this document may be subject to modification without notice.

Dell Inc. will not assume responsibility for accidental or incidental damages resulting from technical

or editorial errors or omissions in this manual, the issue of this manual, the execution of descriptions

in this manual, or the use of this manual.

This document is protected by copyright. Do not photocopy or duplicate any part of this document in

any form without written permission from Dell Inc.

1. About this manual

This manual is a standard service manual of 'HOO,QF containing informationUHTXLUHGIRUPDLQWHQDQFH

of this laser printer (standard specifications).

2. Marks giving caution

Maintenance operations requiring special cautions or additional information regarding descriptions in

this manual are presented as "Warning," "Caution," or "Note," depending on their nature.

If instructions are not observed, death or serious injury may result.

If instructions are not observed, injuries to workers or physical damage to assets

(including this laser printer) may result.

Essentials for procedures, steps, rules, and others.

Reference Incidental information to descriptions.

3. Related documents

-Instruction manuals (standard manuals)

Describe the operation and handling of this laser printer.

-Performance specifications

Describe in detail various specifications of this laser printer.

(In the event of a discrepancy between this manual and the performance specifications, the

performance specifications take precedence.)

-Spare parts list

Information on maintenance parts (spare parts) for this laser printer.

iii

4. Safety

To prevent possible accidents during maintenance operation, you should observe strictly the "Warning"

and "Caution" information in this manual.

Avoid dangerous operations and operations out of the scope of this manual.

Various processes not covered by this manual may be required in actual operations, and should be

performed carefully, always giving attention to safety.

4.1 Power source

Keep the power plug disconnected during the maintenance operation to prevent electric shock, burns

and other damages.

If the power supply should be kept connected to measure voltage or for other similar reasons, take

sufficient care to prevent electric shock, by following the procedures in this manual.

While the printer is on, never touch live parts if not required.

Power is supplied to the power switch / inlet even while the printer is off. Never

touch its live components.

Do not touch live parts unless otherwise specified.

Rio00002KA

4.2 Driving units

When servicing gears or other driving units, be sure to turn off the power switch and unplug the power

cord. Drive them manually when required.

Do not do the print work removing the cover of the printer to confirm the operation

of driving part.

4.3 High-temperature units

When servicing high-temperature units (securing unit, etc.), be sure to turn them off to prevent burns,

injuries and other troubles. Remove the power plug and start service processes after they have cooled

down sufficiently.

Because high-temperature units are still hot after they complete an operation, wait

at least 40 minutes before starting maintenance service.

4.4 Laser beams

• If your eyes are exposed to laser beams, you may lose your eyesight.

• Never open the cover if the warning label for laser beams is attached there.

• Before disassembling and reassembling this laser printer, be sure to turn it OFF.

• When servicing this laser printer while it is running, be sure to follow the

procedures specified in this manual.

• You should be well aware that the laser beams are capable of injuring you and

other people near the printer.

Laser beams have features as follows:

• Frequencies are smaller in width than other beams (sun and electric bulbs) and

phases are uniform so that high monochromatic and convergence performance

can be obtained and thin beams of light can reach places at a long distance.

• Being highly converged, the laser beams exert a heating action that may be

harmful to human body.

Reference: The laser beams of this laser printer are invisible rays.

Rio00003KA

ROS

4.5 Warning/caution labels

Warning labels and caution labels are attached to this laser printer to prevent accidents Check those

labels for peeling or stains when servicing the printer.

4.5.1 Caution label for high-temperature units

Rio00004KA

vii

4.5.2 Caution label for toner cartridges

Rio00006KA
