Understanding your printer



Use the:

When you want to:

Paper support

Load paper in the printer.

Power button

Turn the printer on or off, or cancel a print job.

Paper exit tray

Stack paper as it exits the printer.

Front cover

Change cartridges.

Paper guide

Make sure paper feeds correctly into the printer.

Paper feed button

Feed a sheet of paper through the printer.

USB cable

Connect your printer to a computer.

Power supply

Supply power to the printer.

Appendix

Dell technical support policy

Contacting Dell

Warranty and return policy

Dell technical support policy



Technician-

assisted technical support requires the cooperation and participation of the customer in the troubleshooting process and provides for restoration of

the Operating System, application software and hardware drivers to the original default configuration as shipped from Dell, as well as the verification of

appropriate functionality of the computer unit and all Dell-installed hardware. In addition to this technician assisted technical support, online technical support

is available at Dell Support. Additional technical support options may be available for purchase.



Dell provides limited technical support for the printer and any Dell-installed software and peripherals. Support for third-party software and peripherals is

provided by the original manufacturer, including those purchased and/or installed through Software & Peripherals (DellWare), ReadyWare, and Custom Factory

Integration (CFI/DellPlus).

Contacting Dell



You can access Dell Support at support.dell.com. Select your region on the WELCOME TO DELL SUPPORT page, and fill in the requested details to access help

tools and information.



You can contact Dell electronically using the following addresses:



lWorld Wide Web

www.dell.com/

www.dell.com/ap/ (for Asian/Pacific countries only)

www.euro.dell.com (for Europe only)

www.dell.com/la/ (for Latin American countries)



lAnonymous file transfer protocol (FTP)

ftp.dell.com/



lElectronic Support Service

[email protected]

[email protected] (for Asian/Pacific countries only)

support.euro.dell.com (for Europe only)



lElectronic Quote Service

[email protected]

[email protected] (for Asian/Pacific countries only)



lElectronic Information Service

[email protected]

Warranty and return policy



Dell Computer corporation ("Dell") manufactures its hardware products from parts and components that are new or equivalent to new in accordance with

industry-standard practices. For information about the Dell warranty for your printer, refer to your Owner's Manual.

Finding information



Refer to:

When you need help with:

Setup Diagram



Setup information.

Drivers and Utilities CD



Drivers for your inkjet printer.

Documentation and drivers are already installed on your printer when shipped from Dell. You can use the CD to

uninstall/reinstall drivers or access your documentation.

Readme files may be included on your CD to provide last-minute updates about technical changes to your printer or

advanced technical reference material for experienced users or technicians.

Owner's Manual



Information about:

lBasic usage

lCreative projects

lInk cartridge ordering information

lSetup troubleshooting

lGeneral troubleshooting

Express Service Code and Service

Tag number



Express Service Code and Service Tag number.

This label is located on your printer.



Dell Support Web site

Online tools, including:

lSolutions —Troubleshooting hints and tips, articles from technicians, and online courses

lUpgrades —Upgrade information for components, such as memory

lCustomer Care —Contact information, order status, warranty, and repair information

lDownloads —Drivers

lReference —Printer documentation and product specifications

You can access Dell Support at support.dell.com. Select your region on the WELCOME TO DELL SUPPORT page, and fill in

the requested details to access help tools and information.

Dell™PersonalInkjetPrinterJ740User'sGuide



Click the links to the left for information on the features and operation of your printer. For information on other documentation included with your printer, see

Finding information.



To order ink or supplies from Dell:

1. Double-click the icon on your desktop.



2. Visit Dell's cartridge ordering Web site at www.dell.com/supplies or order Dell printer supplies by phone.

For best service, have your Dell printer Service Tag available.

For help locating your Service Tag number, see Express Service Code and Service Tag number.

Notes, Notices, and Cautions



____________________



Information in this document is subject to change without notice.



Reproduction in any manner whatsoever without the written permission of Dell Computer Corporation is strictly forbidden.



Trademarks used in this text: Dell and DELL logo are trademarks of Dell Computer Corporation; Microsoft and Windows are registered trademarks of Microsoft

Corporation.



Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names of their products. Dell Computer

Corporation disclaims any proprietary interest in trademarks and trade names other than its own.



____________________



UNITED STATES GOVERNMENT RESTRICTED RIGHTS

This software and documentation are provided with RESTRICTED RIGHTS. Use, duplication or disclosure by the Government is subject to restrictions as set

forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013 and in applicable FAR provisions: Dell

Computer Corporation, One Dell Way, Round Rock, Texas, 78682, USA.



April 2003SRVT0669Rev.A00

NOTE: A NOTE indicates important information that helps you make better use of your printer.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.

CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.

Maintenance

Ordering supplies

Replacing an ink cartridge

Aligning the ink cartridges

Cleaning ink cartridge nozzles and contacts

Ordering supplies



Your Dell Personal Inkjet Printer J740 comes with software installed to detect the ink levels in the printer. During a print job, a screen appears on your

computer to warn you if the ink levels are low. To order more ink, follow the instructions on the screen or visit the Dell Web site at www.dell.com/supplies.



Your printer has been designed to print using the following cartridges.



Replacing an ink cartridge

1. Make sure the printer is on.

2. Open the front cover.



The ink cartridge carrier moves and stops at the loading position unless the printer is busy.

3. Press the cartridge carrier tab down, and then lift the cartridge carrier lid.



Item:

Part number:

Black ink cartridge

T0601

Color ink cartridge

T0602

Black high yield ink cartridge

T0722

CAUTION: Before performing any of the procedures listed in this section, read and follow the Safety Instructions in your Owner's Manual.

4. Remove the old cartridge. Store it in an air-

tight container or dispose of it by placing it inside the recycling bag that came with your new ink cartridge and

mailing the recycling bag to Dell.



5. If you are installing a new cartridge, remove the sticker and tape from the bottom of the cartridge.



6. Insert the new cartridge. Make sure the color ink cartridge is secure in the right carrier and the black ink cartridge is secure in the left carrier, and then

snap the lid closed.



7. Close the front cover.

Aligning the ink cartridges



There are two instances when you will align your ink cartridges.



lAfter installing cartridges



lTo improve print quality

To align the ink cartridges:

1. Load plain paper in the printer. For help, see Loading paper.

2. Open the Dell Printer Solution Center. Click Start®Programs®Dell Printers®Dell Inkjet Printer J740®Dell Printer Solution Center.

3. From the Maintenance tab, click Align to fix blurry edges.

4. Click Print.

An alignment page prints, automatically aligning the cartridges.

Cleaning ink cartridge nozzles and contacts



NOTICE: Do not touch the gold contact area on the cartridge.

NOTE: If the alignment page does not print, make sure you have completely removed the stickers and transparent tape from both ink cartridges, and

then try to align the cartridges again.

If you are not satisfied with the print quality of your document, make sure you:



lUse the appropriate paper for the document. For example, use photo paper if you are printing photos.



lUse paper that is bright white or coated.



lSelect a higher print quality.

a. From your program, click File®Print.

The Print dialog box appears.

b. From the Print dialog box, click Properties, Preferences, or Options.

c. From the Quality/Speed area on the Quality/Copies tab, select Better or Best.



If your document still does not have the print quality you expect, follow these steps:

1. Reinsert the ink cartridges:

a. Remove the ink cartridges. For help, see Replacing an ink cartridge.

b. Insert the ink cartridges. For help, see Replacing an ink cartridge.

c. Print your document again.

d. If print quality has not improved, continue with step 2.

2. Clean the print nozzles:

a. Load paper. For help, see Loading paper.

b. Click Start®Programs®Dell Printers®Dell Inkjet Printer J740®Dell Printer Solution Center.

c. Click the Maintenance tab.

d. From the Maintenance tab, click Clean to fix horizontal streaks.

e. Click Print.

A nozzle page prints, forcing ink through the nozzles to clean the clogged nozzles.

f. Print your document again to verfiy that your print quality has improved.

g. If you are not satisfied with the print quality, continue with step 3, and then print your document again.

3. Wipe the ink cartridge nozzles and contacts:

a. Remove the ink cartridges. For help, see Replacing an ink cartridge.

b. Dampen a clean, lint-free cloth with water and place it on a flat surface, such as a table.

c. With the nozzles pointing down, gently hold the cartridge against the cloth for about three seconds.

d. Slowly wipe the nozzles in the direction shown.



e. With another clean section of the cloth, repeat steps c through d.

f. Gently hold another clean section of the cloth against the contacts for about three seconds, and then wipe in the direction shown.



g. With another clean section of the cloth, repeat step f.

NOTE: To avoid getting ink on the flat surface, place two sheets of paper under the cloth.

h. Let the nozzles and contacts dry completely.

i. Reinsert the ink cartridges and wait five minutes before printing.

j. Clean the ink nozzles. For help see step2.

k. Print your document again.

l. If the print quality does not improve, repeat step 3 up to two more times.

m. If print quality is still not satisfactory, replace the ink cartridges. For information on ordering supplies, refer to the Owner's Manual, or open the

Dell Printer Solution Center.

Regulatory notices



Federal Communications Commission (FCC) compliance information statement



The Dell Personal Inkjet Printer J740 has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.



The FCC Class B limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one

or more of the following measures:



Reorient or relocate the receiving antenna.



Increase the separation between the equipment and receiver.



Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.



Consult your point of purchase or service representative for additional suggestions.



The manufacturer is not responsible for any radio or television interference caused by using other than recommended cables or by unauthorized changes or

modifications to this equipment. Unauthorized changes or modifications could void the user's authority to operate this equipment.



To assure compliance with FCC regulations on electromagnetic interference for a Class B computing device, use a properly shielded and grounded cable. Use of

a substitute cable not properly shielded and grounded may result in a violation of FCC regulations.



Any questions regarding this compliance information statement should be directed to:



Dell Products, L.P.



One Dell Way



Round Rock, Texas, USA 78682



Industry Canada compliance statement



This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.



Avisdeconformitéauxnormesd'IndustrieCanada



CetappareilnumériquedelaclasseBrespectetouteslesexigencesduRèglementsurlematérielbrouilleurduCanada.



European Community (EC) directives conformity



A declaration of conformity with the requirements of the directives has been signed by the Director of Manufacturing and Technical Support, Lexmark

International, S.A., Boigny, France.



This product satisfies the Class B limits of EN 55022 and safety requirements of EN 60950.



Noise emission levels



The following measurements were made in accordance with ISO 7779 and reported in conformance with ISO 9296.



The United Kingdom Telecommunications Act 1984



This apparatus is approved under the approval number NS/G/1234/J/100003 for the indirect connections to the public telecommunications systems in the

United Kingdom.



ENERGY STAR



The EPA ENERGY STAR Office Equipment program is a partnership effort with office equipment manufacturers to promote the introduction of energy-efficient

products and to reduce air pollution caused by power generation.



Companies participating in this program introduce products that power down when they are not being used. This feature will cut the energy used by up to 50

percent. Dell is proud to be a participant in this program.



As an ENERGY STAR Partner, Dell International, Inc. has determined that this product meets the ENERGY STAR guidelines for energy efficiency.

1-meter average sound pressure, dBA

Printing

51 dBA

Andere Handbücher für J740

Inhaltsverzeichnis

Andere Dell Drucker Handbücher

Dell

Dell V310 Series Bedienungsanleitung

Dell

Dell 7330dn - Laser Printer B/W Handbuch

Dell

Dell W5300 Bedienungsanleitung

Dell

Dell 1133 Mono Laser Technische Daten

Dell

Dell 2230d Bedienungsanleitung

Dell

Dell Inspiron 1110 Bedienungsanleitung

Dell

Dell 2335dn - Multifunction Monochrome Laser Printer... Bedienungsanleitung

Dell

Dell E515dw Bedienungsanleitung

Dell

Dell DELL 7130CDN Service-Handbuch

Dell

Dell B5460dn Mono Laser Printer Bedienungsanleitung

Dell

Dell 924 - Photo All-In-One Inkjet Bedienungsanleitung

Dell

Dell B1260dn Bedienungsanleitung

Dell

Dell C3760DN Color Laser Bedienungsanleitung

Dell

Dell 3000cn Color Laser Printer Bedienungsanleitung

Dell

Dell 5330dn - Workgroup Laser Printer B/W Installations- und Betriebshandbuch

Dell

Dell 2330d - Laser Printer B/W Bedienungsanleitung

Dell

Dell S5840cdn Bedienungsanleitung

Dell

Dell B5460dn Mono Laser Printer Bedienungsanleitung

Dell

Dell B5460dn Mono Laser Printer Bedienungsanleitung

Dell

Dell B5460dn Mono Laser Printer Bedienungsanleitung

Dell

Dell B5460dn Mono Laser Printer Bedienungsanleitung

Dell

Dell S5830DN Bedienungsanleitung

Dell

Dell B5460dn Mono Laser Printer Bedienungsanleitung

Dell

Dell C2660dn Bedienungsanleitung

Beliebte Drucker Handbücher anderer Marken

Lexmark

Lexmark 1400 Series Handbuch

Canon

Canon i70 Series Bedienungsanleitung

Evolis

Evolis Elypso Bedienungsanleitung

Kyocera

Kyocera FS-9530DN Bedienungsanleitung

Canon

Canon LASER SHOT LBP-1210 Bedienungsanleitung

Samsung

Samsung BIXOLON SRP-350plusF Bedienungsanleitung

Canon

Canon PIXMA PRO-1 Series Bedienungsanleitung

Canon

Canon PIXMA G3560 Einrichtungshandbuch

Tektronix

Tektronix Phaser 840 Bedienungsanleitung

Epson

Epson ET-7750 Betriebsanleitung

Canon

Canon CLBR 460ps Bedienungsanleitung

Eltron

Eltron P210 Guide Bedienungsanleitung

Ricoh

Ricoh MD-P1 Bedienungsanleitung

Epson

Epson SC-F7100 series Bedienungsanleitung

Epson

Epson Stylus C40UX Bedienungsanleitung

Canon

Canon imagePASS-A2 Bedienungsanleitung

Canon

Canon S820D Bedienungsanleitung

IRA3D

IRA3D POETRY4 Bedienungsanleitung
