Before you begin

Purpose of this document

Required:

❑Create an EMC Online Support account:

https://support.emc.com. You will need this

account later in the installation process to

activate software licenses and configure ESRS

(EMC Secure Remote Services).

❑If your Unity system arrived pre-racked, begin

installation at Step 4 of this guide.

❑Obtain the help of a second person to install

the enclosure into the rack, or use a mechanical

lift.

❑If you have more than one enclosure to install,

use the

Unity Installation Guide

to complete

your installation. The installation guide

includes racking and cabling instructions

required for additional enclosures, which are

not covered here. The

Unity Installation Guide

is located here: http://bit.ly/unityinfohub.

Recommended:

❑Download the Connection Utility at http://bit.ly/

unityinfohub. You will need this utility if you want to

assign static IP addresses to your system. You will not

need this utility if you plan to use DHCP to

automatically assign IP addresses to your system.

❑If you are installing your system in a location with

restricted internet access, download the Connection

Utility and your license files before starting the

installation process: http://bit.ly/unityinfohub.

❑Watch the Unity Quick Start Installation video: http://

bit.ly/unityinfohub.

❑Refer to the

What’s next

section for important details

about adding enclosures and using the Unisphere

online help.

Unpack

Record SNPower Up

Assign

Management

Address

Cable to

Network

Install

Rails

Launch

Unisphere

Install

System

EMC Unity™Quick Start >

1. Unpack your system

Verify that you have the following components:

❑2U Disk Processor Enclosure (DPE) with either 12-3.5” drive slots or 25-2.5” drive slots

❑Rail kit, including 2 rails with 6 mounting screws

❑2 power cables (100-240Vac)

❑Bezel

❑Not provided by EMC, but you will also need:

• A Phillips-head screwdriver with magnetic tip

• 2 CAT 5 or better Ethernet cables

2. Install the rails

The rails are designated Left and Right and cannot be interchanged.

1. First, orient the rails. Face the front of the cabinet when orienting the Left and Right rail placement. The

front of each rail is stamped L or R.

2. From the rear of the cabinet, insert the adaptors into the holes on the rear rack channel with the rail

extended as shown in the image below.

3. Push the rail into the rear mounting holes until the spring clips snap into place on the outside of the rear

rack channel:

CAUTION

Ensure the holes on the rail line up with the holes on the cabinet. This will ensure proper alignment of the

rails. Also, check that the rails are level from front-to-back and left-to-right. Ensure you are using the same

unit markers from the front of the cabinet to the rear of the cabinet.

Watch the Unity Quick Start Installation Video: http://bit.ly/unityinfohub

Extend rail

Rear

Channel

View from rear of rack

Front

Channel Spring Clips

Adaptors

CL5774

4. From the rear of the cabinet, secure the rails in place using one M5 screw on each rail:

5. Next, working from the front of the cabinet, align the adaptor with the mounting hole on the front of the

rack, as shown in the image below in Step 6.

CAUTION

Ensure the holes on the rail line up with the holes on the cabinet. This will ensure proper alignment of the

rails. Also, check that the rails are level from front-to-back and left-to-right. Ensure you are using the same

unit markers from the front of the cabinet to the rear of the cabinet.

6. Push in on the spring clip while pulling the rail forward. When the spring clip is forward of the front rack

channel, and the adaptor is in the mounting holes, release the spring clip so it holds the rail in place.

CAUTION

Ensure the spring clip is securely attached to the channel. It may be necessary to push in on the clip to

assist in snapping it into place.

CL5775

Right Rail

(viewed from rear)

Left Rail

(viewed from rear)

View from front of rack

3. Install the system onto the rails

CAUTION

The enclosure is heavy and should be installed into or removed from a rack by two people. To avoid

personal injury and/or damage to the equipment, do not attempt to lift and install the enclosure into a

rack without a mechanical lift and/or help from another person.

1. From the front of the rack, slide the enclosure onto the rails:

2. Secure the enclosure to the front vertical channels of the cabinet with 4 screws (2 per side).

CL5777

CL5778

4. Record your system serial number

Locate and record the product serial number tag on the front of the DPE chassis in either of the locations

shown below. You will use this number to obtain product licenses later in the installation process:

5. Cable the system to the network

Connect two CAT 5 (or better) ethernet cables from your local network (LAN) to the RJ45 management ports

at the rear of the system. The management ports have a white border around them.

PROD ID/SN: FNM01234567891

PN: 123-456-789 (OBERON)

PROD ID/SN: FNM01234567891

PN: 123-456-789 (OBERON)

CL5779

PRODID/SN: FNM01234567891

PN:123-456-789 (OBERON)

PROD ID/SN: FNM01234567891

PN: 123-456-789 (OBERON)

CL5780

12-drive enclosure: The underside of the top edge

near the right side.

25-drive enclosure: Below the power status LED

located between drive slots 16 and 17.

Serial Number:

___________________________________

XXX XXX XXXX X

REV:XXX

XXX

XXXX

REV

XXX

1 GbE

10 GbE

1GbE

1 GbE

10 GbE

1GbE

CL5782

6. Power up

1. Verify that the cabinet’s circuit breakers are in the ON position and power is connected to the cabinet.

2. Connect each DPE power cable to the system power component and to the PDUs. After you plug in the

power cables, the system immediately powers up:

3. Secure each cable to the system component with the cable clip:

4. Ensure that the Service Processor LEDs display the correct condition before continuing with system

initialization (initial system boot could take 15-60 minutes to complete, depending on factory

configuration).

IMPORTANT: Refer to the

Unity Installation Guide

( http://bit.ly/unityinfohub) to verify system LED

conditions or to install additional drive enclosures.

7. Assign a management address

Before you can configure and manage the Unity system, you must assign a network address to it. There are

two ways to do this:

Note: It can take the Connection Utility 10-15 minutes to recognize and populate the serial number.

Note: Disable any security software running on your workstation that may prevent the initialized system

from being detected.

❑Allow the system to dynamically acquire an IP address by using DHCP. If DHCP is supported on your

network, the Unity system automatically obtains a network address when you power it up. Check with

your network administrator about DHCP availability on your network.

❑Assign a static address to the system. Download, install, and run the Connection Utility software. This

must be done on a computer with access to the subnet where you installed your Unity system. The

Connection Utility requires the following:

• Your system serial number. This identifies the system on the network.

• The system IP address. Obtain an IP address from your network administrator.

•Subnetmask.

•Defaultgateway.

CL5781

8. Launch the Unisphere Initial Configuration Wizard

The Initial Configuration Wizard walks you through the steps to install licenses, configure network settings,

create pools, manage alerts, define support options, configure network interfaces, and create NAS servers.

1. Complete the

Configuration Worksheet

. This worksheet is located in the

Unity Installation Guide

or as a

separate download from the Unity Info Hub: http://bit.ly/unityinfohub.

2. Access the Unisphere management application.

• If you manually configured the system with the Connection Utility, click Launch Unisphere, or open a

web browser and enter the IP address that you assigned to the Unity system.

• If the system automatically acquired an IP address through DHCP, enter the Unity system serial

number and its network domain in the browser's address bar as follows:

Sample URL: FM100000000017.mylab.xyz.com

Note: If you receive a certificate error when trying to access Unisphere, refer to your internet browser

instructions to either bypass the error or to install the self-signed array certificate. For more detail

about your system certificate, refer to the

EMC Unity Family Security Configuration Guide

• Log in with the default user name and password. Please complete the tasks associated with this

wizard before placing the system into use.

• Username: admin

• Password: Password123#

• Licensing your system includes:

• The Unisphere Initial Configuration Wizard automatically takes you to SW Licensing Central.

• Register, activate, and download your license files as described on SW Licensing Central.

• Install licenses on your array using the Unisphere Initial Configuration Wizard.

What’s next?

❑Use the

Unisphere Online Help

to further guide you through the configuration process.

❑If you need to add Disk Array Enclosures (DAEs) to the system at a later time, use the (15- or 25-drive)

Installing an Optional Disk-Array Enclosure

guide at http://bit.ly/unityinfohub_cru.

Other languages

You can access localized versions of this and other documents at support.emc.com.

您可以在 support.emc.com 上访问本文及其他文档的本地化版本。

Локализованные версии этого идругих документов можно найти на веб-сайте support.emc.com.

Você pode acessar versões localizadas deste e de outros documentos em support.emc.com.

본 문서 및 기타 문서의 한국어 버전은 support.emc.com 에서 이용할 수 있습니다 .

このドキュメントおよびその他のドキュメントの日本語版は、 support.emc.com からご覧いただけます。

Des versions traduites du présent document et d’autres documents sont disponibles sur le site Web

support.emc.com.

Puede obtener acceso a versiones traducidas de este y otros documentos en support.emc.com.

Lokalisierte Versionen dieses Dokuments und anderer Dokumente finden Sie unter http://

support.emc.com.
