Dell™ PowerVault™ 100

Getting Started Guide

With Your System

Guide de mise en route

Primeiros passos com o sistema

Procedimientos iniciales con el sistema

Dell™ PowerVault™ 100 Systems

Getting Started With

Your System

Model MVT01

Notes, Notices, and Cautions

NOTE: A NOTE indicates important information that helps you make better use of

your computer.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data

and tells you how to avoid the problem.

CAUTION: A CAUTION indicates a potential for property damage, personal injury,

or death.

____________________

Information in this document is subject to change without notice.

Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell, the DELL logo, and PowerVault, are trademarks of Dell Inc.;

Intel Core and Core 2 Duo are trademarks and Intel, Pentium and Celeron are registered trademarks

of Intel Corporation in the U.S. and other countries; Microsoft, Windows and Windows Storage Server

are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or

other countries.

Other trademarks and trade names may be used in this document to refer to either the entities claiming

the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and

trade names other than its own.

Model MVT01

August 2007 P/N JU892 Rev. A00

Contents 3

Contents

System Features . . . . . . . . . . . . . . . . . . . . . . 5

Supported Operating Systems . . . . . . . . . . . . . . . 7

Other Information You May Need . . . . . . . . . . . . . 7

Obtaining Technical Assistance . . . . . . . . . . . . . 8

Installation and Configuration. . . . . . . . . . . . . . . 8

Unpacking the System . . . . . . . . . . . . . . . . 8

Connecting the Keyboard, Mouse, and Monitor . . . 9

Connecting the Power . . . . . . . . . . . . . . . . 9

Turning on the System . . . . . . . . . . . . . . . 10

Complete the 0perating System Setup. . . . . . . . . . 10

Technical Specifications . . . . . . . . . . . . . . . . 11

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

4Contents

Getting Started With Your System 5

System Features

This section describes the major hardware and software features of your

system. It also provides information about other documents you may need

when setting up your system and how to obtain technical assistance.

Major hardware and software features of your system include:

• One of the following processors:

–Intel

Core™ 2 Duo

– Intel Celeron

D, 300 sequence

– Intel Pentium

4, 600 sequence

NOTE: Use the System Setup program to view processor information.

See ”Using the System Setup Program” in your Hardware Owner’s Manual.

• A minimum of 512 MB of 533-MHz or 667-MHz DDRII SDRAM memory,

upgradable to a maximum of 8 GB by installing combinations of 512-MB,

1-GB, or 2-GB unbuffered ECC memory modules in four memory module

sockets on the system board, single or dual rank.

• The following expansion slots:

– One PCIe x1 (3.3-V) slot

– One PCIe x8 (3.3-V) slot

– One 32-bit, 33-MHz PCI (5-V) slot

– Two 64-bit, 133-MHz PCI-X (3.3-V) slots

• An integrated Gigabit Ethernet NIC, capable of supporting 10-Mbps,

100-Mbps, or 1000-Mbps data rates, with support for IPMI 1.5 and

Wake-on-LAN.

• Four USB 2.0-compliant connectors (two on the front and two on the back)

capable of supporting a diskette drive, CD-ROM drive, keyboard, mouse,

or USB flash drive.

• An integrated ATI ES1000 SVGA video controller supporting true-color

graphics in the following resolutions: 640 x 480, 800 x 600, 1024 x 768,

1280 x 1024, and 1600 x 1200.

• Systems management circuitry that monitors critical system voltages and

fan speeds. The systems management circuitry works in conjunction with

the systems management software.

6Getting Started With Your System

• Standard baseboard management controller with serial access.

• Back-panel connectors include PS/2 mouse and keyboard, serial, video,

two USB connectors, and one NIC connector.

• One 3.5-inch CD, DVD, or combination CD-RW/DVD in a peripheral

drive bay.

NOTE: DVD devices are data only.

• Support for the following internal hard-drive configurations:

– Up to four internal, 1-inch, SATA hard drives with integrated drive

controllers.

– Up to four internal, 1-inch, Serial-Attached SCSI (SAS) hard drives

with an optional SAS controller card or backplane.

NOTE: Hot-plug capability is supported only when SATA or SAS drives are

connected to the optional SAS controller card or backplane.

• Optional Dell Remote Access Card (DRAC 4) for remote systems

management. This option requires a dedicated PCI slot.

• One 420-W power supply.

For more information about specific features, see “Technical Specifications”

on page 11.

The following software is included with your system:

• A System Setup program for quickly viewing and changing system

configuration information. For more information on this program, see

“Using the System Setup Program” in the

Hardware Owner’s Manual

• Enhanced security features, including a system password and a setup

password, available through the System Setup program.

• System diagnostics for evaluating system components and devices.

For information about using the system diagnostics, see “Running the

System Diagnostics” in your

Hardware Owner’s Manual

• Video drivers for displaying many popular application programs in high-

resolution modes.

• SATA or SAS device drivers that allow the operating system to

communicate with devices attached to the integrated SATA or SAS

subsystem. For more information about these drivers, see “Installing

Drives” in your

Hardware Owner’s Manual

• Systems management software and documentation CDs.

Getting Started With Your System 7

Supported Operating Systems

Your system supports the following operating system:

• Microsoft

Windows Storage Server™ 2003 R2 Express Edition (x64)

• Microsoft

Windows Storage Server 2003 R2 Workgroup Edition (x64)

Other Information You May Need

CAUTION: The Product Information Guide provides important safety and

regulatory information. Warranty information may be included within this

document or as a separate document.

• The

Hardware Owner’s Manual

provides information about system

features and describes how to troubleshoot the system and install or

replace system components. The

Hardware Owner’s Manual

is available

on the CDs that came with your system or on

support.dell.com

• CDs included with your system provide documentation and tools

for configuring and managing your system.

• Systems management software documentation describes the features,

requirements, installation, and basic operation of the software.

• Operating system documentation describes how to install (if necessary),

configure, and use the operating system software.

• Documentation for any components you purchased separately provides

information necessary to configure and install these options.

• Updates are sometimes included with the system to describe changes

to the system, software, and/or documentation.

NOTE: Always check for updates on support.dell.com and read the updates

first because they often supersede information in other documents.

• Release notes or readme files may be included to provide last-minute

updates to the system or documentation or advanced technical reference

material intended for experienced users or technicians.

8Getting Started With Your System

Obtaining Technical Assistance

If you do not understand a procedure in this guide or if the system does not

perform as expected, see your Hardware Owner’s Manual.

Dell

™

Enterprise Training and Certification is available; see

www.dell.com/training for more information. This service may not be offered

in all locations.

Installation and Configuration

CAUTION: Before performing the following procedure, read and follow the safety

instructions and important regulatory information in your Product Information Guide.

This section describes the steps to set up your system for the first time.

CAUTION: Installing the feet on a stand-alone tower system is necessary to provide

a stable foundation for the system. Failure to install the feet poses the risk of having

the system tip over, possibly causing bodily injury or damage to the system.

CAUTION: Whenever you need to lift the system, get others to assist you. To avoid

injury, do not attempt to lift the system by yourself.

Unpacking the System

Unpack your system and identify each item.

Keep all shipping materials in case you need them later.

See the documentation included with your system on installing the

system stabilizer feet.
