Important Information

•When using electrical appliances, basic safety precautions should always be fol-

lowed, including the following:

•Read all instructions.

•To protect against fire, electrical shock and personal injury, do not immerse cord,

plug or appliance in water or other liquid.

•Close supervision is necessary when any appliance is used by or near children.

•Do not operate with a damaged cord or plug, or after the appliance malfunctions,

or has been damaged in any manner. Return the appliance to the nearest authori-

zed De’ longhi service facility for examination, repair or adjustment.

•The use of accessory attachments or spare parts is not recommended by the

appliance manufacturer. It may result in fire, electrical shock or personal injury.

•Do not use outdoors.

•Do not use the appliance for other than the intended use.

•Do not place any strain on the power cord. Avoid twisting and/or tangling.

•Ensure that outlet vent of exhaust hose is kept debris-clear and obstruction free.

•Ensure that ventilation holes on the rear of the machine and front louvers are not

blocked.

•The Pinguino should not be installed where the atmosphere could contain combusti-

ble gases.

•Avoid using Pinguino in oily or sulphurous atmospheres or near sources of heat.

•Wait at least 3 minutes before restarting, after the airconditioner has been switched

off or the thermostat setting changed.

•Before moving the airconditioner, remove tank and empty water from collectiong

tray (see instructions for drainage at page 14).

•Do not place hot or heavy objects on the appliance.

•Clean air filter every week (see instructions at page 14).

•Important: If you need to use an extension cord, please be sure to use a heavy duty

extension cord (minimum 14 gauge).

SAVE THESE INSTRUCTIONS

pac360U OK GB 24-04-2003 16:32 Pagina 2

ENGLISH

Dear user,

We thank you for purchasing Pinguino airconditioner

and congratulate you on your wise choice.

For optimal results please read this manual carefully

before installing or operating.

We know that the Pinguino will keep your environment

pleasingly comfortable at all times.

With best wishes

pac360U OK GB 24-04-2003 16:32 Pagina 3

Specifications

30.65

Water tank capacity pints

Power supply voltage V 115

10000

6.5

adjustable

R 22

yes

see rating label

22.05” (560)

28.74” (730)

15.35” (410)

Frequency Hz

Cooling capacity:

With water Btu

Current consumption A

Room thermostat

Dimensions: width in.

height in.

depth in.

Net weight lbs.

Refrigerant system (freon)

Compressor protection

Freon charge lb. (gr)

OPTIMUM OPERATING RANGE

ROOM TEMPERATURE 21° - 35° C (70°F - 95°F)

ROOM HUMIDITY FACTOR

FREQUENCY

VOLTAGE

50% - 80% RH

POWER

SUPPLY

60 HZ

115V

pac360U OK GB 24-04-2003 16:32 Pagina 4

ENGLISH

Air outlet grille

Air filter

Air intake grid

Exhaust hose compartment

Power cord compartment

Manual reset button

Castors

Castor stops

Water collecting tray

Water container compartment door

Control panel

Water container

Programmer (timer)

Handle

Drainage tube

Description of main features

pac360U OK GB 24-04-2003 16:32 Pagina 5

Illustrated accessory list

DESCRIPTION SUPPLIED

Exhaust hose 1

Permanent wall vent 1

Caster stop 2

Descaling fluid 1

Window nozzle 1

Suction disc 2

ACCESSORY CHECK

Check that all parts listed in Table are included.

Window bracket +

door bracket 1

Electrostatic filter 1

pac360U OK GB 24-04-2003 16:32 Pagina 6

ENGLISH

PERMANENT INSTALLATION

Our air-conditioner is portable and versatile: it can be

used for a permanent installation or easily moved from

one room to another.

In case of permanent installation, air discharged from

rear hose has been extracted from the room where

the appliance is installed.

Check that the room (especially if small) is “air-tight”;

a drop in pressure would cause irregular functioning,

which could consequently activate the reset switch.

Air entering through door and window cracks is nor-

mally sufficient. If deemed necessary leave a door

open (approx. 1/2 inch is enough).

The unit can also be used as a “temporary” installation

for use in any room with a window or french window;

this “temporary” installation can be used at any time

until it is ready for permanent installation.

INSIDE OUTSIDE

fig. 2

in a window pane

INSIDE OUTSIDE

fig. 3

through the wooden base-

section of a door or window

fig. 1

fig. 2 fig. 3

INSIDE OUTSIDE

fig. 4

through the wall

1”

fig. 4

The appliance must be fitted at least

30 cm. from the surrounding walls.

PERMANENT INSTALLATION WITH PLUG AND FLANGE

The outlet holes must be connected to the outside of the building and cannot be made in any

wall or panel.

3,75”-

95 mm

3,75”- 95 mm

Permanent installation

pac360U OK GB 24-04-2003 16:32 Pagina 7

Tempory installation

Note: In both cases (permanent and temporary installations) make sure that the Pinguino is posi-

tioned on level ground. If necessary, use the two caster stops for the front casters

This installation makes it easy to

use Pinguino in any room, provi-

ded there is a window or a door: it

allows you to use the Pinguino

immediately (Fig. 5).

Suction cups may be used to

keep window or door closed (Fig.

6).

Pinguino is equipped with an adju-

stable window bracket. If you have

a sliding window, place the bracket

on the window sill, extend the

bracket fully within the window

frame and lower the window onto

the bracket. Insert the nozzle of the

exhaust hose into the slot, then con-

nect the hose to the air conditioner

(Fig. 7). With the wing nut, it’s possi-

ble to use the window bracket also

for sliding windows. Position the hole

of the bracket so to allow a correct

installation of the exhaust hose (see

the following instructions).

PREPARING THE UNIT FOR USE

1) Fit the exhaust tube in place; if your conditioner is

supplied with a extendable tube, it is fitted as illu-

strated in the diagram.

2) For permanent installation, place the appliance

near the wall or window outlet. Make sure it is stan-

ding on a level surface and fit the special shock

absorbers/castor stops underneath the castors.

1) Water collects at this point 2) Bend this section 3) Bend this section

NO YES YES

ELECTRICAL CONNECTION

Check that the power supply voltage is 115 V ~ 60 Hz.

Important: If you need to use an extension cord, please be sure to

use a heavy duty extension cord (minimum 14 gauge).

Before connecting the Pinguino to a power supply, make sure

that all switches on the front control panel are in the OFF position.

Connect power cord found in storage compartment at rear of

the Pinguino (Fig. 9).

fig. 5 fig. 6 fig. 7

fig. 8

fig. 9

window

bracket

pac360U OK GB 24-04-2003 16:32 Pagina 8

ENGLISH

Pinguino is equipped with an adjustable win-

dow bracket (18). If you have a sliding win-

dow, place the bracket on the window sill,

extend the bracket fully within the window

frame and lower the window onto the brack-

et. Insert the nozzle of the exhaust hose into

the slot, then connect the hose to the air con-

ditioner (Fig.10).

With the wing nut, it’s possible to use the window

bracket also for sliding windows. Position the

hole of the bracket to allow for correction instal-

lation of the exhaust hose (see the following

instructions).

Setting up

If you have a sliding door, use the additional

set provided in order to extend the accessory

to the desired length; joining the two parts

(fig. 11), adjust the total length according to

your needs, then fit the bracket with the rele-

vant nuts, close the door and connect the

hose (fig. 12).

fig. 10

fig. 11

fig. 12

pac360U OK GB 24-04-2003 16:32 Pagina 9

Final check

-Doors and windows of room to be air con-

ditioned are closed (with the exception of

temporary installation where a partially

opened window is necessary).

-Shade the room as far as possible from

direct sunlight by drawing curtains

and/or lowering blinds or shutters, for

economical and efficient air-cooling.

-Ensure that intake and outlet vents (fig. 2

and 3) are not blocked.

-Make sure there are no sources of heat in

the room.

In order to obtain maximum performance from your air conditioner make sure that:

fig. 13

fig. 14

SPECIAL NOTE

This machine is designed to be used with or without water. Maximum performance is obtained

using water.

HOW TO PREPARE WATER CONTAINER

Use only clean, salt-free tap water. The water is essential for the air cooling operation and is

discharged in the form of steam through the exhaust outlet. A container full of water lasts for a

period that depends on a number of conditions; such as temperature, humidity, insulation, sun

exposure to the room, number of people present, etc. On average it will last approximately 7 to

10 hours.

When the container is empty, the appliance automatically changes function from water to air.At

the same time, the quantity of air discharged from the rear hose will increase.

Open the water container compart-

ment door, tip the container forwards

and lift up to remove.

Remove the cap, pull out the extenda-

ble tube and fill the container, standing

it on the floor.

After filling, replace the extendable tube,

screw the cap on tightly and return the

container to its place, making sure the

word FRONT is facing out.

During “water condensation” cooling function and in particularly quiet surroundings (eg.

bedroom), a slight gurgling noise may be heard. This is perfectly normal.

Warning: Do not use water containing salt, eg. seawater or water treated using softening systems

that utilize table salt.

fig. 17

fig. 15

fig. 16

pac360U OK GB 24-04-2003 16:32 Pagina 10

ENGLISH

Description of Pinguino

DESCRIPTION OF PINGUINO PAC 360 CONTROLS

ON/OFF pilot light ON/OFF button Thermostat

Fan speed select

button

Timer

ON/OFF

button

“Alarm” pilot light

Timer ON/OFF

pilot light

Timer

SETTING THE TIMER

The programmer/timer, like all clocks, must be

set to the exact time. If for example it is 4.00

p.m., turn the dial in a clockwise direction

(following the direction of the arrow) until the

number 4 is lined up with the arrow pointer

(the arrows indicates 4:00 p.m. approxima-

tely).

Note: Never turn the dial in a counter-

clockwise direction!

The timer is in effect, an electric clock and

works only if the plug is connected to the

power supply. Whenever the plug is discon-

nected or there is a power failure, the pro-

grammer stops (the clock is then “slow”) and

must be re-set.

The unit can be used in either programmed or

non-programmed mode.

PROGRAMMED MODE

1) Release B timer button.

2) Set the operating times by pushing out the

notches on the dial corresponding to the

period required (each notch represents 15

min).

3) Check that the timer indicates the correct

time (see instructions on setting).

4) Select the desired function as shown in the

chart.

The unit will now switch on and off each

day at the selected times.

Note: To override the programmed operating

times, simply press the ON/OFF key.

NON-PROGRAMMED MODE

1) B TIMER button must be pressed

2) Select the desired function as shown in the

chart on the following page.

arrow pointer

Note: For technical reasons, the temperature is not expressed in degrees but by a line increa-

sing in thickness. We therefore recommend that when starting up the appliance, the

thermostat be turned to maximum (thick line = maximum cold). When the desired tem-

perature has been reached, turn the thermostat slowly away from the maximum cooling

position until the appliance switches off. Leave the thermostat in this position. The air con-

ditioner is now programmed to maintain the exact temperature at all times.

After switching the appliance off, wait at least 3 min. before switching on again.

eg. from 9 to 11 a.m.

Operating time

pac360U OK GB 24-04-2003 16:32 Pagina 11

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere DeLonghi Klimaanlage Handbücher

DeLonghi

DeLonghi PINGUINO S1000 Bedienungsanleitung

DeLonghi

DeLonghi AIR CONDITIONER Bedienungsanleitung

DeLonghi

DeLonghi DD40P Bedienungsanleitung

DeLonghi

DeLonghi PAC T140HPEC Bedienungsanleitung

DeLonghi

DeLonghi PAC W110E Bedienungsanleitung

DeLonghi

DeLonghi PAC WE 110 Bedienungsanleitung

DeLonghi

DeLonghi Pinguino F110 Bedienungsanleitung

DeLonghi

DeLonghi PACCT 250 Bedienungsanleitung

DeLonghi

DeLonghi Artic Whisper PAC EM375WRC Bedienungsanleitung

DeLonghi

DeLonghi Pinguino PAC L10 Bedienungsanleitung

DeLonghi

DeLonghi CF 1130 Bedienungsanleitung

DeLonghi

DeLonghi Pinguino CF 210 Bedienungsanleitung

DeLonghi

DeLonghi PAC WE125 Bedienungsanleitung

DeLonghi

DeLonghi Pinguino Air-to-Air PAC EX130 Bedienungsanleitung

DeLonghi

DeLonghi PAC AN125HPEC Bedienungsanleitung

DeLonghi

DeLonghi PAC AN HPE Series Bedienungsanleitung

DeLonghi

DeLonghi PAC EL376HGRFK Bedienungsanleitung

DeLonghi

DeLonghi PACA130HPEM Bedienungsanleitung

DeLonghi

DeLonghi PAC AN130HPE Bedienungsanleitung

DeLonghi

DeLonghi EX Series Bedienungsanleitung

DeLonghi

DeLonghi PINGUINO PAC CN86 Bedienungsanleitung

DeLonghi

DeLonghi EX Series Bedienungsanleitung

DeLonghi

DeLonghi PAC AN120EW Bedienungsanleitung

DeLonghi

DeLonghi Pinguino PAC26Super Bedienungsanleitung

Beliebte Klimaanlage Handbücher anderer Marken

Spheros

Spheros CC 355 Bedienungsanleitung

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Bedienungsanleitung

Panasonic

Panasonic CS-E12HKEW Bedienungsanleitung

nedis

nedis ACMB1WT7 Bedienungsanleitung

Samsung

Samsung AR KV Series Leitfaden

Daikin

Daikin FCFV50A Bedienungsanleitung

Fujitsu

Fujitsu Inverter ASBA30JFC Bedienungsanleitung

Toshiba

Toshiba RAS-M10SMUV-E Bedienungsanleitung

Daikin

Daikin FXLQ20MAVE Bedienungsanleitung

Hitachi

Hitachi RAS-E24CAK Bedienungsanleitung

CIAT

CIAT Magister 2 Series Leitfaden

Bestron

Bestron AAC6000 Bedienungsanleitung

Hisense

Hisense 7K Technisches Handbuch

Frigidaire

Frigidaire FFRE0533S1E0 Bedienungsanleitung

Samsung

Samsung AS09HM3N Bedienungsanleitung

Frigidaire

Frigidaire CRA073PU11 Betriebsanleitung

Soleus Air

Soleus Air GB-PAC-08E4 Bedienungsanleitung

McQuay

McQuay MCK020A Bedienungsanleitung
