DE’LONGHI

COOKING

INSTALLATION and SERVICE INSTRUCTIONS

USE and CARE INSTRUCTIONS

DEF905E

CERAMIC COOKER

distributed by

DeLonghi Australia Pty Ltd

DeLonghi New Zealand Ltd

Dear Customer,

Thank you for having purchased and given your preferen-

ce to our product.

The safety precautions and recommendations reported

below are for your own safety and that of others. They will

also provide a means by which to make full use of the fea-

tures offered by your appliance.

Please keep this booklet in a safe place. It may be useful

in future, either to yourself or to others in the event that

doubts should arise relating to its operation.

This appliance must be used only for the task it has

explicitly been designed for, that is for cooking fo-

odstuffs. Any other form of usage is to be considered

as inappropriate and therefore dangerous.

The manufacturer declines all responsibility in the

event of damage caused by improper, incorrect or illo-

gical use of the appliance or be faulty installation.

PRODUCT LABEL

This appliance has been designed and constructed in accordance with the following codes

and specications:

AS/NZS 60335.1 General Requirements for Domestic electrical appliances

AS/NZS 60335.2.6 Particular Requirements for Domestic electrical cooking appliances

AS/NZS CISPR 14.1 Electromagnetic Compatibility Requirements.

Important:

This appliance is designed and manufactured solely for the coo-

king of domestic (household) food and is not suitable for any non

domestic application and therefore should not be used in a com-

mercial environment.

The appliance guarantee will be void if the appliance is used within

a non domestic environment i.e. a semi commercial, commercial

or communal environment.

FIRST USE OF THE OVEN

It is advised to follow these instructions:

■Furnish the interior of the oven as described at chapters “USE

AND CARE” and “CLEANING AND MAINTENANCE”.

■Switch on the empty oven on max to eliminate grease from the

heating elements.

■Let the oven cool down and clean the interior of the oven with a

cloth soaked in water and neutral detergent, then dry carefully.

IMPORTANT PRECAUTIONS AND RECOMMENDATIONS FOR

USE OF ELECTRICAL APPLIANCES

Use of any electrical appliance implies the necessity to follow a se-

ries of fundamental rules. In particular:

■Never touch the appliance with wet hands or feet.

■Do not operate the appliance barefooted.

■ The appliance is not intended for use by young children or inrm

persons without supervision.

■Young children should be supervised to ensure they do not play

with the appliance.

The manufacturer cannot be held responsible for any damages cau-

sed by improper, incorrect or illogical use of the appliance.

IMPORTANT PRECAUTIONS AND RECOMMENDATIONS

After having unpacked the appliance, check to ensure that it is not

damaged and that the oven door closes correctly. In case of doubt,

do not use it and consult your supplier or a professionally qualied

technician.

Packing elements (i.e. plastic bags, polystyrene foam, nails, packing

straps, etc.) should not be left around within easy reach of children,

as these may cause serious injuries.

■ Some appliances are supplied with a protective lm on steel and

aluminium parts. This lm must be removed before using the

appliance.

■Do not attempt to modify the technical characteristics of the ap-

pliance as this may become dangerous to use.

■Do not carry out cleaning or maintenance operations on the ap-

pliance without having previously disconnected it from the elec-

tric power supply.

■After use, ensure that the knobs are in the off position.

■Keep children away from the appliance when it is in use.

■WARNING: Accessible parts will become hot when in use. To

avoid burns and scalds, young children should be kept away.

■Young children should be supervised to ensure that they do not

play with the appliance.

■Children, or persons with a disability which limits their ability to use

the appliance, should have a responsible person to instruct them

in its use. The instructor should be satised that they can use the

appliance without danger to themselves or their surroundings.

■During and after use of the appliance, certain parts will become

very hot. Do not touch hot parts. Care should be taken to avoid

touching heating elements inside the oven.

■Make sure that electrical cables connecting other appliances in

the proximity of the cooker cannot come into contact with the hob

or become entrapped in the oven door.

■Do not allow heavy or sharp objects to drop on the glass cera-

mic hob. If the hob is cracked or otherwise damaged by falling

objects etc., disconnect the electrical power cord and call Custo-

mer Service.

■Do not scratch the hob with sharp objects. Don’t use the hob as

a work surface.

■WARNING: When correctly installed, your product meets all sa-

fety requirements laid down for this type of product category.

However special care should be taken around the rear or the

underneath of the appliance as these areas are not designed or

intended to be touched and may contain sharp or rough edges,

that may cause injury.

■Do not line the oven walls with aluminium foil. Do not place ba-

king trays or the drip tray on the base of the oven chamber.

■Fire risk! Do not store ammable material in the oven or in the

storage compartment.

■Always use oven gloves when removing the shelves and food

trays from the oven whilst hot.

■Do not hang towels, dishcloths or other items on the appliance or

its handle – as this could be a re hazard.

■Clean the oven regularly and do not allow fat or oils to build up in

the oven base or tray. Remove spillages as soon as they occur.

■Do not stand on the open oven door.

■Always stand back from the appliance when opening the oven door

to allow steam and hot air to escape before removing the food.

■Safe food handling: Leave food in the oven for as short a time

as possible before and after cooking. This is to avoid contamina-

tion by organisms which may cause food poisoning. Take parti-

cular care during warmer weather.

■The manufacturer declines all liability for injury to persons or dama-

ge to property caused by incorrect or improper use of the appliance.

■WARNING: Taking care NOT to lift the oven by the door

handle.

■IMPORTANT NOTE: This appliance shall not be used as a

space heater, especially if installed in marine craft or cara-

vans.

■Do not operate your appliance by means of an external timer

or separate remote-control system.

■This appliance is for domestic use only.

INSTALLATION

CAUTION:

■This appliance must be installed in accordance with these installation instructions.

■This appliance shall only be serviced by authorised personnel.

■This appliance is to be installed only by an authorised person in compliance

with the current electrical regulations and in observation of the instructions

supplied by the manufacturer.

Failure to comply with this condition will render the guarantee invalid.

■Incorrect installation, for which the manufacturer accepts no responsibility, may

cause personal injury of damage.

■Always disconnect the appliance from mains power supply before carrying out

any maintenance operations or repairs.

LOCATION

■The cooker can be installed in a cabinet (Fig. 1).

■The cooker must be installed no less than 50 mm away from any side wall which

exceed the height of the cooktop.

■The appliance must be housed in heat resistant units.

■The walls of the units must be capable of resisting temperatures of 75 °C above

room temperature.

■Do not install the appliance near inammable materials (eg. curtains).

■If you stand the cooker on a pedestal, make sure you provide safety measures

to keep it in place.

Figure 1

50 mm

500 mm

650 mm

450 mm

Cooker overall dimensions [mm]

■ height: min 900 - max 925

■ width: 900

■ depth: 600

FITTING THE ADJUSTABLE FEET

The adjustable feet must be tted to the base of the cooker before use (g. 2).

Rest the rear of the cooker on a piece of the polystyrene packaging exposing the base for

the tting of the feet.

Fit the no. 4 (four) legs by screwing them tight into the support base as shown in gure 3.

LEVELLING THE COOKER

The cooker may be levelled by screwing the lower ends of the feet IN or OUT (g. 4).

Figure 3 Figure 4Figure 2

MOVING THE COOKER

WARNING: When raising cooker to upright

position always ensure two people carry

out this manoeuvre to prevent damage to

the adjustable feet (g. 5).

WARNING - Be carefull: Do not lift the co-

oker by the door handle when raising to the

upright position (g. 6).

WARNING: When moving cooker to its -

nal position DO NOT DRAG (g. 7). Lift feet

clear of oor (g. 5).

Figure 5

Figure 7Figure 6

ANTI-TILT BRACKET

Important!

To restrain the appliance and prevent it

tipping accidentally, t a bracket to its

rear to x it securely to the wall. Make

sure you also t the supplied lock pin to

the anti-tilt bracket.

To t the anti-tilt bracket:

1. After you have located where the co-

oker is to be positioned, mark on the

wall the place where the two screws

of the anti-tilt bracket have to be tted.

Please follow the indications given in

g. 8.

2. Drill two 8 mm diameter holes in the

wall and insert the plastic plugs sup-

plied.

Important!

Before drilling the holes, check that

you will not damage any pipes or

electrical wires.

3. Loosely attach the anti-tilt bracket with

the two screws supplied.

4. Move the cooker to the wall and adjust

the height of the anti-tilt bracket so that

it can engage in the slot on the coo-

ker’s back, as shown in g. 8.

5. Tighten the screws attaching the anti-

tilt bracket.

6. Push the cooker against the wall so

that the anti-tilt bracket is fully inserted

in the slot on the cooker’s back.

7. Access the bracket and t the lock pin:

■ Open the pivoting panel (g. 9).

■Fit the lock pin through the bracket, as

shown (g. 10).

■Close the pivoting panel.

min 220

max 245

(depending on feet adjustment)

450 450

+ 25

900 mm

Pivoting

panel

Lock pin

correctly

fitted

Lock pin

Slot on the

cooker’s back

Cooker’s

back

Anti-tilt bracket

attached on the

rear wall

min 220

max 245

(depending on feet adjustment)

450 450

+ 25

900 mm

Pivoting

panel

Lock pin

correctly

fitted

Lock pin

Slot on the

cooker’s back

Cooker’s

back

Anti-tilt bracket

attached on the

rear wall

min 220

max 245

(depending on feet adjustment)

450 450

+ 25

900 mm

Pivoting

panel

Lock pin

correctly

fitted

Lock pin

Slot on the

cooker’s back

Cooker’s

back

Anti-tilt bracket

attached on the

rear wall

Figure 8

Figure 9

Figure 10

ELECTRICAL REQUIREMENTS

■The appliance must be connected to the mains checking that the voltage correspon-

ds to the value given in the rating plate and that the electrical cable sections can

withstand the load specied on the plate.

■A suitable disconnection switch must be incorporated in the permanent wiring, mounted

and positioned to comply with the local wiring rules and regulations. The switch must

be of an approved type installed in the xed wiring and provide a 3 mm air gap contact

separation in all poles in accordance with the local wiring rules.

In Australia and New Zealand, a switch of the approved type with a 3 mm air gap must

be installed in the active (phase) conductor of the xed wiring.

■The switch must always be accessible.

■The power supply cable must not touch the hot parts and must be positioned so that it

does not exceed 75°C above ambient.

■To connect the cooker to the mains electricity supply, do not use adapters, reducers or

branching devices as they can cause overheating and burning.

■This cooker must be connected to a suitable double pole control unit adjacent to the

cooker. No diversity can be applied to this control unit.

■This cooker must be connected to electrical supply using V105 insulated cable.

In New Zealand, this appliance must be connected to the electrical supply using a

cable tted with an appropriately rated plug. The plug must be compatible with the

socket-outlet tted to the nal subcircuit in the xed wiring that is intended to supply

the appliance.

■Once the appliance has been installed, the switch or socket must always be accessible.

■If the supply cord is damaged it must be replaced by the manufacturer or it’s Service

Agent or a similarly qualied person in order to avoid a hazard.

N.B. The connection of the appliance to earth is mandatory.

If the installation requires alterations to the domestic electrical system call a qualied elec-

trician. He should also check that the domestic electrical system is suitable for the power

drawn by the appliance.

Replacing the power cord must be done by a qualied electrician in accordance with

the instructions supplied by the manufacturer and in compliance with established

electrical regulations.

Inhaltsverzeichnis

Andere DeLonghi Kocher Handbücher

DeLonghi

DeLonghi DTR 906 DF CR-1 Montageanleitung

DeLonghi

DeLonghi DEMX 96 B5 ED Bedienungsanleitung

DeLonghi

DeLonghi DSC 606G Betriebsanleitung

DeLonghi

DeLonghi D 61 E Kurzanleitung

DeLonghi

DeLonghi DEF1407S Bedienungsanleitung

DeLonghi

DeLonghi GSI 502 Betriebsanleitung

DeLonghi

DeLonghi TR 906-G Betriebsanleitung

DeLonghi

DeLonghi DRS 900-G Betriebsanleitung

DeLonghi

DeLonghi DEFL605G Kurzanleitung

DeLonghi

DeLonghi DSC 90 DF FSD Betriebsanleitung

DeLonghi

DeLonghi A 726 G Kurzanleitung

DeLonghi

DeLonghi DFG 903 Betriebsanleitung

DeLonghi

DeLonghi DE 926 GWF Installationsanleitung

DeLonghi

DeLonghi A 1346 G Kurzanleitung

DeLonghi

DeLonghi DFS 903 Betriebsanleitung

DeLonghi

DeLonghi GDF 601 SS Betriebsanleitung

DeLonghi

DeLonghi DTR 906-DF Series Technisches Handbuch

DeLonghi

DeLonghi GSS603 Betriebsanleitung

DeLonghi

DeLonghi GEMMA 96 M ED Bedienungsanleitung

DeLonghi

DeLonghi DTC 90 DF Betriebsanleitung

DeLonghi

DeLonghi D3VR 908-DF Bedienungsanleitung

DeLonghi

DeLonghi D 61 EII Kurzanleitung

DeLonghi

DeLonghi DEMX 664 IN Bedienungsanleitung

DeLonghi

DeLonghi GDF 603 L Betriebsanleitung

Beliebte Kocher Handbücher anderer Marken

Modena

Modena FC 7645 SGM Betriebsanleitung

Electrolux

Electrolux Insight EKG6049 Bedienungsanleitung

Stanley

Stanley Donard 60 Bedienungsanleitung

Bartscher

Bartscher 201TC Bedienungsanleitung

Parkinson Cowan

Parkinson Cowan 50 GR/BU Bedienungsanleitung

Siemens

Siemens HK9P00020U Bedienungsanleitung

Creda

Creda S150E Leitfaden

Creda

Creda HB48309 Bedienungsanleitung

Bosch

Bosch HCE743220F Bedienungsanleitung

Tricity Bendix

Tricity Bendix SE545P Bedienungsanleitung

NEFF

NEFF E1461A2/01 Bedienungsanleitung

Zanussi

Zanussi ZCM 700 X Bedienungsanleitung

Smeg

Smeg SNL61MA9 Bedienungsanleitung

RiverGrille

RiverGrille TF2002501-RG Bedienungsanleitung

Vollrath

Vollrath 69504F Bedienungsanleitung

Tricity Bendix

Tricity Bendix CSIE500 Bedienungsanleitung

AEG

AEG Competence 5731 V Bedienungsanleitung

Euromaid

Euromaid ES60 Bedienungsanleitung
