DeLonghi DRAGON HM3 Handbuch

DRAGON HM3

We were thinking of you

when we thought of it

Australia

P.O.Box 597

Riverwood NSW 2210

Customer Service Ph: 1800 126659

Fax: 1800 706932

e-mail: [email protected]

Proudly distributed by

De’Longhi

25 CARBINE ROAD

MT WELLINGTON

PO BOX 58056

GREENMOUNT

Auckland, New Zealand

Customer Service Ph: (09) 915 7273

Fax: (09) 915 7280

e-mail:[email protected]

IMPORTANT

DO NOT OPERATE WITHOUT READING

INSTRUCTIONS FIRST

Spare copies of this leaflet can be obtained

from your dealer

Fig.1

Dragon HM3 2

Thank you for choosing this De’Longhi radiator. To get the

very best out of your new radiator it is advisable to read

these instructions before using it.This will ensure that you

gain optimum results and use the appliance safely.

General instructions

Ta ke the radiator out of its packing box and remove any poly-

styrene pieces or any other packaging material that might be

lodged inside it.

Make sure that the radiator has not been damaged during transit

and that the mains cable is in working order. Do not operate the

radiator if damaged.

“Easy wheel”system

Turn the radiator upside-down on a rug or a soft surface in order to

prevent damaging the paint finish. Fully unfold the castors by turning

them outwards (Fig. 1).Turn the radiator back to its upright position.

Electrical connection

-Before plugging the radiator into the mains, check that your

supply voltage is the same as that shown on the rating plate of

the radiator.

- If using more than one appliance at a time, it is important to

ensure that the ring main is adequate to cope with the power

requirements.

- It is important to ensure that the socket is adequately earthed.

- This radiator complies with EEC Directive 89/336 relating to

electromagnetic compatibility.

How to use it

Switching on

Plug the radiator in; position the thermostat slider to maximum

and turn the radiator on as follows using the power selector:

•Turn the power selector to position 1 to select minimum out-

put (the light on the left will come on).

•Turn the power selector to position 2 to select medium output

(the light on the right will come on).

•Turn the power selector to position 3 to select maximum out-

put (both lights will come on).

Adjusting the thermostat

Leave the thermostat at its highest setting until the room has

reached the required temperature.Then slowly turn the ther-

mostat slider back until you hear a click.The temperature

selected in this way will then be regulated automatically and

kept constant by the thermostat.

Frost protection function

With the thermostat slider in the minimum position and a power

selected, the unit maintains the room at a temperature of about

5˚C, preventing freezing with minimum energy consumption.

Models with 24-hour timer

Using the timer

If you wish to use the timer, position the switch in the middle posi-

tion (Fig. 4).

Setting the correct time

Check the time on your watch. If for example it is 4.00 pm.

(16.00), turn the dial in a clockwise direction until the number 16

is lined up with the triangular pointer (fig.2).

N.B.: Never turn the dial in an anti-clockwise direction!

The timer is in effect an electric clock and works only if the plug is

connected to the power supply. Whenever the plug is disconnect-

ed or there is a power failure, the clock must be re-set.

To program the timer

1) Set the operating times by pushing in with your thumbnail to

the outer rim, the notches on the dial corresponding to the

period required (fig.3) (each notch represents 15 mins.)

2) Make sure that the timer indicates the correct time (see

instructions on setting the correct time).

3) Turn the radiatior on and set it to the heat setting and temperature

level on the thermostat as required.

Once programmed in this way, the appliance will repeat the pre-

established program every day, if the selector is in the position.

Timer override

If you wish to override the timer settings, push the timer switch to

position 1 (fig.4) manual (timer override).To return to timed oper-

ation push the switch back to the middle position (fig.4).

NOTE: if the timer switch is at the 0position (fig.4), the heater is

off and will not operate).

IManual (timer override)

Timer operation

Heater off

Fig.2

pointer

operating time

fig.3

fig.4

Dragon HM3

Cleaning and maintenance

Your oil filled raditor is absolutely free from maintenance, fully reli-

able and will give many years of trouble free service.Wipe radiator

with soft damp cloth; do not use detergents or abrasives.

If necessary, use a vacuum cleaner to remove any built-up dirt.

Important notes

-Do not use your radiator close to bath, wash-basin, shower and

swimming pool.

-Do not use your radiator to dry laundry.

-Never place the power cable on top of the radiator while it is hot.

-Only use the radiator in an upright position.

-The heater must be positioned at least 50 cm from furniture or

other objects.

-If the power cable has been damaged, it must be replaced by the

manufacturer or the technical service centre or by a qualified person

so as to avoid all risks.

-In order to eliminate the radiator’s “new” smell, set it to maximum

power for at least 8 hours when used for the first time. During this

operation, the room in which the radiator is located must be ventilat-

ed.

-The power cord should be fully removed from the cord storage unit

when in use.

-The appliance is not intended for use by young children or infirm

person without supervision.

-Young children should be supervised to ensure that they do not play

with the appliance.

-The appliance is fitted with a tilt-switch which turns the appliance off

if it should fall over.

To r estart the appliance, simply place it upright again.

-It is perfectly normal for the radiator to make “creacking” sounds

when used for the first time. (or in the case of unfrequent use).

-The radiator must not be located immediately below a fixed socket-

outlet.

-The body of this radiator is filled with a precise quantity of special

oil, so that repairs requiring the opening of the oil body must only be

made by the service agent. Any oil leakage must be reported to the

service agent.

-Do not use this appliance in rooms having a floor area of less than

4m2as this can lead to overheating.

-If the appliance is scrapped, provisions on the disposal of oil must be

respected.

-The use of an extension lead is not recommended, as overheating of

the extension lead may occur during the operation of the radiator.

Dragon HM3

-As with any electrical appliance, whilst the instructions aim to cover

as many eventualities as possible, caution and common sense should

be applied when operating your appliance, particularly in the vicinity

of young children.

The appliance is fitted with a safety device which will switch off

it in case of accidental overheating.To reset, disconnect the plug

from the power for 30 minutes, remove the cause of overheat-

ing then plug the appliance in again.

ATTENTION: in order to avoid any danger caused by an acci-

dental resetting of the safety system, this appliance must not be

powered through an external timer.

IMPORTANT: Do not cover the radiator during opera-

tion as this could lead to dangerous overheating,

Dragon HM3 5
