INSTALLATION and SERVICE INSTRUCTIONS
USE and CARE INSTRUCTIONS
distributed by
DèLonghi
Pty Ltd
OVENS
2
Dear Customer,
Thank you for having purchased and given your
preference to our product.
The safety precautions and recommendations reported
below are for your own safety and that of others. They
will also provide a means by which to make full use of
the features offered by your appliance.
Please keep this booklet in a safe place. It may be
useful in future, either to yourself or to others in the
event that doubts should arise relating to its operation.
This appliance must be used only for the task it has
explicitly been designed for, that is for cooking
foodstuffs. Any other form of usage is to be considered
as inappropriate and therefore dangerous.
The manufacturer declines all responsibility in the
event of damage caused by improper, incorrect or
illogical use of the appliance or be faulty installation.
PRODUCT LABEL
3
CONTENTS
Precautions and recommendations ................................................” 3
Installation......................................................................................” 5
Multifunction oven - Use and care ................................................” 12
Cleaning and maintenance............................................................” 28
USING THE OVEN FOR THE FIRST TIME
You are advised to carry out the following operations:
■Furnish the interior of the oven.
■Switch the empty oven ON at maximum temperature for about two hours to
eliminate traces of grease and smell from the components.
■Clean the interior of the oven with a cloth soaked in water and neutral
detergent and dry thoroughly.
IMPORTANT PRECAUTIONS AND RECOMMENDATIONS FOR
USE OF ELECTRICAL APPLIANCES
Use of any electrical appliance implies the necessity to follow a series of fundamental
rules. In particular:
■Never touch the appliance with wet hands or feet;
■Do not operate the appliance barefooted;
■The appliance is not intended for use by young children or infirm persons
with supervision
■Young children should be supervised to ensure they do not play with the
appliance
The manufacturer cannot be held responsible for any damages caused by improper,
incorrect or illogical use of the appliance.
IMPORTANT PRECAUTIONS AND RECOMMENDATIONS
After having unpacked the appliance, check to ensure that it is not damaged.
In case of doubt, do not use it and consult your supplier or a professionally qualified tech-
nician.
Packing elements (i.e. plastic bags, polystyrene foam, nails, packing straps, etc.) should not
be left around within easy reach of children, as these may cause serious injuries.
■Do not attempt to modify the technical characteristics of the appliance as this
may become dangerous to use.
■Do not carry out cleaning or maintenance operations on the appliance without
having previously disconnected it from the electric power supply.
■After use, ensure that the knobs are in the off position.
■Do not allow children or other incapable people to use the appliance without
supervision.
■During use the appliance becomes hot. Care should be taken to avoid touching
heating elements inside the oven.
■Keep children away from the cooker when it is in use.
■Some appliances are supplied with a protective film on steel and aluminium parts.
This film must be removed before using the appliance.
■Fire risk! Do not store flammable material in the oven.
■Make sure that electrical cables connecting other appliances in the proximity of
the oven become entrapped in the oven door.
■Do not line the oven walls with aluminium foil. Do not place baking trays or the
drip tray on the base of the oven chamber.
■The manufacturer declines all liability for injury to persons or damage to property
caused by incorrect or improper use of the appliance.
■WARNING: Taking care NOT to lift the oven by the door handle.
■IMPORTANT NOTE: This appliance shall not be used as a space
heater, especially if installed in marine craft or caravans.
This oven has been designed and constructed in accordance with the following codes
and specifications:
AS/NZS 3350-1 General Requirements for Domestic electrical appliances
AS/NSZ 3350-2-6 Particular Requirements for Domestic electrical cooking appliances
AS/NSZ 1044 Electromagnetic Compatibility Requirements.
4
INSTALLATION
CAUTION:
■This appliance must be installed in accordance with these installation
instructions.
■This appliance shall only be serviced by authorized personnel.
■This appliance is to be installed only by an authorised person.
■Incorrect installation, for which the manufacturer accepts no responsibil-
ity, may cause personal injury of damage.
■Always disconnect the oven from mains power supply before carrying
out any maintenance operations or repairs.
N.B. • The connection of the appliance to earth is mandatory.
• For connection to the mains, do not use adapters, reducers or
branching devices as they can cause overheating and burning.
If the installation requires alterations to the domestic electrical system call a qualified
electrician. He should also check that the socket cable section is suitable for the power
drawn by the appliance.
ELECTRICAL REQUIREMENTS
■The oven is supplied without a power supply plug and therefore if you are
not connecting directly to the mains, a standardized plug suitable for the
load must be fitted.
■Connection to the mains must be carried out by qualified personnel in
accordance with current regulations.
■The appliance must be connected to the mains checking that the voltage
corresponds to the value given in the rating plate and that the electrical
cable sections can withstand the load specified on the plate.
■The plug must be connected to an earthed socket in compliance with safety
standards.
■The appliance must be connected directly to the mains placing a two pole
switch with minimum opening between the contacts of 3 mm between the
appliance and the mains.
■The power supply cable must not touch the hot parts and must be
positioned so that it does not exceed 75°C at any point.
■Once the appliance has been installed, the switch or socket must always be
accessible.
■
If the supply cord is damaged it must be replaced by the
manufacturer or its Service Agent or a similarly qualified person in
order to avoid a hazard.
5
REPAIRS
REPLACING THE POWER SUPPLY CABLE
■Unhook the terminal board cover by inserting a screwdriver into the two
hooks “A” (fig. 2).
■Open the cable gland by unscrewing screw “F” (fig. 3), unscrew the
terminal screws and remove the cable.
■The new supply cable, of suitable type and section, is connected to the
terminal board following the diagram fig. 1.
FEEDER CABLE SECTION TYPE HO5RR-F
230 - 240 V 3 x 1,5 mm2
A
F
230 - 240 V
E
N
L1(L )2
Figure 2 Figure 3
Figure 1
6
S1S2
F1
PR
1
6
1a
6a
4
9
4a
9a
3
8
3a
8a
2
7
2a
7a
5
10
11
5a
10a
11a
C
G
S
V
CIR
TM
CF
N/7
1
1a
L/8
LF1
TL
T
N
L
M
LF2
ELECTRIC DIAGRAM - multifunction OVENS
(models with electronic programmer)
Figure 4
F1 Oven switch
TM Oven thermostat
TL Thermal overload
PR Electronic programmer
LF1 Oven lamp
LF2 Oven lamp
S1 Thermostat pilot lamp
S2 Line pilot lamp
C Top element
G Grill element
S Bottom element
V Fan
CIR Circular element
CF Cooling fan
M Terminal block
T Earth connection
7
ELECTRIC DIAGRAM - multifunction OVENS
(models with cut-off timer)
Figure 5
F1 Oven switch
TM Oven thermostat
LF Oven lamp
CC Oven cut-off
S1 Line pilot lamp
S2 Thermostat pilot lamp
TL Thermal overload
M Terminal block
C Top element
G Grill element
S Bottom element
CIR Circular element
CF Cooling fan
V Fan
T Earth connection
8
FITTING THE OVEN INTO A
BASE
The space available should be of the
dimensions shown in the figure 6.
Arrangements should be made for an
adequate supply of the air to the oven
to avoid overheating (fig. 7).
560
550 min
591
594
594
540
20
536 min
600
The walls surround-
ing the oven must
be made of heat-
resistant material.
Both the veneered
plastic and the adhe-
sive used must be
resistant to tempera-
tures of 120°C in
order to prevent
unsticking and defor-
mation.
FITTING REQUIREMENTS
WARNING: Taking care NOT to lift the oven by the door handle.
The oven must be built-in in a standard module of furniture of 60 cm width and
depth.
It is to be fit up in a module having the clearance as shown in the pictures.
On the lower side, the oven must lay on supports standing the oven weight.
The ovens are secured by four screws that pass through the surround. They must
locate firmly and squarely in the edges of the cabinet or add panels to achieve a
secure location.
Figure 6
Figure 7
9
560
50
585
FITTING THE OVEN INTO A
COLUMN
The cabinet should have the dimen-
sions as per fig. 8.
Furthermore it is necessary that the
oven is provided with a chimney as per
fig. 9.
If the column unit reaches the ceiling
an outlet must be provided through
which air can flow to the outside.
;
;
50 mm
50 550
Figure 8
Figure 9
10
WARNING
When correctly installed,
your product meets all safety
requirements laid down for
this type of product category.
However special care should
be taken around the rear or
the underneath of the appli-
ance as these areas are not
designed or intended to be
touched and may contain
sharp or rough edges, that
may cause injury.
