EN 1-channel remote control for roller shutter
TYXIA 1701
EN
32
Technical characteristics
• Power supplied by 3V lithium battery, CR2430
• Class III insulation
• X3D Transmission frequency:
868.7 MHz to 869.2 MHz
• Maximum radio power < 10 mW
• Receiver category II
• Wireless range: 100 to 300 metres outside,
variable depending on the associated equipment
(the range can vary depending on the installation
conditions and the electromagnetic environment)
• Wall-mounted
• Dimensions: 46 x 121 x 10.7 mm
• Degree of protection: IP 40
• Operating temperature: 0 to +55°C
• Storage temperature: -10 to +70°C
• Installation in an environment with normal
pollution levels
Contents
1/ Location/Mounting ............................................. 4
1.1 Mounted on the wall ......................................4
1.2 Placed on a at surface .................................5
2/ Wireless association........................................... 6
2.1 Pairing of a motor in
individual control mode ........................................6
2.2 Pairing of a Tyxia receiver for a roller
shutter motor (e.g. Tyxia 5630 or 5730)..........8
2.3 Pairing of several motors
or receivers in group control................................ 9
3/ Save the favourite positions...........................10
4/ Use ..........................................................................11
5/ Troubleshooting .................................................13
EN
54
1.2 Placed on a flat surface
1/ Location/Mounting
1.1 Mounted on the wall
WARNING !
Do not ingest battery, chemical Burn Hazard.
This product contains a coin/button cell battery.
If the coin/button cell battery is swallowed, it can cause severe
internal burns in just 2 hours and can lead to death.
Keep new and used batteries away from children.
If the battery compartment does not close securely, stop using the
product and keep it away from children.
If you think batteries might have been swallowed or placed inside
any part of the body, seek immediate medical attention.
EN
76
2/ Wireless association
If you own a solar motor, refer to its instructions.
2.1 Pairing of a motor in
individual control mode
When connecting to the power supply, a motor that
has never been wirelessly paired before will always
perform a brief movement. It is set to pending
pairing for 10 minutes.
2.1.1 If only a single motor is turned on
❶On the remote control, press
12
and
12
at the
same time and hold for 3 seconds, until the LED
ashes. Release the buttons.
When the motor is detected, the LED briey lights up
green.
❷ After a few seconds, the shutter activates
twice to conrm pairing, and the remote control
automatically exits pairing mode.
❸Then proceed with the setting of the stops (see
motor instructions).
2.1.2 If several motors are switched on
❶On the remote control, press
12
and
12
at the
same time and hold for 3 seconds, until the red
LED ashes. Release the buttons.
The remote control searches for the various motors.
The LED ashes red, then briey green as soon as a
new motor is found.
❷ When the LED starts ashing red slowly, press
the
12
button as many times as required to
select the motor to be paired.
The corresponding shutter activates briey.
❸Once themotor has been found, press
12
.
❹After a few seconds, the shutter activates twice
to conrm pairing.
❺To exit pairing mode, press
12
for 3 seconds.
❻Then proceed with the setting of the stops (see
motor instructions).
EN
98
2/ Wireless association
2.3 Pairing of several motors
or receivers in group control
Important: if you pair several motors with the
remote control, you will no longer have access to
the stop settings from this remote control.
❶Set the motors to pending pairing (press the
12
button on their individual control for 3 seconds,
or via the Tydom app).
and/or
Set the receivers to pairing mode (press their
button for 3 seconds, or via the Tydom app).
❷On the remote control, press
12
and
12
at the
same time and hold for 3 seconds, until the LED
ashes. Release the buttons.
The remote control searches for the various motors
or receivers.
The LED ashes red, then briey green as soon as a
new receiver is found.
❸ Once the LED on the remote controle slowly
ashes red, press the
12
and
12
buttons at
the same time for 3 seconds, until the shutters
activate briey, then release the buttons.
2.2 Pairing of a Tyxia receiver for a roller shutter
motor (e.g. Tyxia 5630 or 5730)
❶Switch on and set the receiver to pairing mode
by pressing its button for 3 seconds until its LED
ashes red, then release.
❷On the remote control, press
12
and
12
at the
same time and hold for 3 seconds until the red
LED ashes, then release the buttons.
When the receiver is detected, the LED briey lights
up green and the receiver stops ashing.
The shutter activates briey to conrm the pairing.
The remote control automatically exits pairing mode.
EN
1110
3/ Save the favourite positions
You can save up to 2 favourite positions from the
remote control:
12
and
12
.
❶❷ Set the shutter to the required position
(
12
or
12
).
❸Press
12
+
12
or
12
+
12
for 3 seconds to
save the positions.
The LED changes from red to green if the receiver
has correctly received the information. The shutter is
activated briey to conrm the association.
Release.
> 3s
1
2
1
1
1
4/ Use
• Press
12
to raise, and
12
to lower.
Press
12
to stop the shutters.
The LED changes from red to green if the receiver has
correctly received the information.
• Press
12
to go to favourite position 1 (if it has
been saved).
• Press
12
to go to favourite position 2 (if it has
been saved).
Control in silence mode (Tymoov RP2 motors):
In order to reduce the noise level, you can control
the motor in slow mode by performing a long press
on or (2 seconds).
1
2
EN
1312
5/ Troubleshooting
• The red LED ashes several times
every time a button is pressed.
The battery is low. Change the battery.
• Remove an association
- Remove the front face of the remote control.
- Press button A. The red LED ashes.
- Press
12
as many times as required
to select the motor (receiver) to
remove.
- Press the
12
button. The shutter starts.
- Press button A to exit.
• Remove all associations
To release the remote control from all association.
- Remove the front face of the remote control.
- Press button A. The red LED ashes.
- Press the
12
and
12
buttons at the same time and
hold for 3 seconds. The shutters start.
- Press button A to exit.
• Your remote control is lost or not functioning
Initial condition: The lost remote control was only
associated with a single motor
Turn off the power to the motor, wait 10 seconds, then
turn the motor back on.
From a new remote control:
- Press the B button 2 times, until the LED ashes
orange.
- Press
12
and
12
for 3 seconds until the ashing stops.
The motor (receiver) has not been associated before
- Restart the association process for your new remote
control.
• The green LED does not ash after briey pressing
button B.
- Several motors are associated with the remote
control. Therefore, you cannot access the setting
modes in this case.
The remote control must only be associated with one
motor for the settings.
