DELTA Temp BREEZER Bedienungsanleitung
QUICK GUIDE
BREEZER - ADIABATIC COOLER
Delta-Temp Belgium
Lange Ambachtstraat 13, 9860 Oosterzele
T: +32 (0)9 362 74 87
www.delta-temp.be
Delta-Temp Germany
Carl-Still-Straße 19, 45659 Recklinghausen
T: +49 800 4048120
www.delta-temp.de
1. Mounting the fan head:
• Lock each of the rear wheels by pressing down
on the brakes.
• Lift the fan head straight up and out of the tank
and align it with the fan head support pole.
• Turn the fan head until you feel it engage.
• Once installed, the atomizer (metal disk) will be
facing the tank, air will be blown over the tank
when the unit is turned on.
3. Insert water inlet hose:
• Remove water inlet hose from the front hole in
the tank and insert into bulkhead tting. Ensure
that connection is sealed.
2. Fan Head power connector
• Insert fan head power connector into fan head.
Ensure female end of power connector is aligned
to male connector and twist together.
4. Insert atomizer drain hose:
• Insert atomizer drain hose into the front hole
on top of the tank, from where the water inlet
hose was originally removed.
• Atomizer drain hose should not be submerged
below water line.
• Once assembled, the atomizer drain hose should
be exible, but not so loose that water gets
backed up in the hose.
I. SETUP
>>
Delta-Temp Belgium
Lange Ambachtstraat 13, 9860 Oosterzele
T: +32 (0)9 362 74 87
www.delta-temp.be
Delta-Temp Germany
Carl-Still-Straße 19, 45659 Recklinghausen
T: +49 800 4048120
www.delta-temp.de
II. OPERATION
1. Turning on your unit:
1a. Press the power button and hold for one second.
The LED light for the power button will be lit and the fan blades will begin to slowly rotate to indicate the unit is
powered on.
1b. Press the fan speed button to increase the fan speed. Adjust the fan speed by pressing the or buttons.
1c. Press the oscillation button once to activate the oscillation feature.
1d. Press the atomizer button once to activate the misting feature.
1
2
2. Adjusting the misting level:
1a. Press the power button and hold for one second if unit is not already on.
1b. Set fan speed to desired level.
1c. Locate the water valve. The water valve is located inside the reservoir tank
towards the rear of the tank.
1d. Start with the water valve closed, at the 6 o’clock position as shown.
1e. Start the atomizer by pressing the atomizer button once.
2a. Open the water valve slightly and check the distance of the mist. There will be a
short delay before misting begins.
2b. If there is a strong mist at 6 feet away, then the moisture setting is too high for
conditions. To reduce misting, rotate the water valve lever back towards the 6
o’clock position.
Optimal moisture settings can also be adjusted according to personal preference.
