Introduction

Thank you for purchasing your PRIME hardware. At Denon DJ, we know how serious music is to you. That’s why we

design our equipment with only one thing in mind—to make your performance the best it can be. We’re honored and

excited to play a part in your musical & creative DJ journey!

Support

For the latest information about this product (documentation, technical specifications, system requirements, compatibility

information, etc.) and product registration, visit denondj.com.

For additional product support, visit denondj.com/support.

Product Registration

Your product may include exclusive software and/or promotions which can only be accessed by registering your new

product on the Denon DJ website.

To check eligibility and access the available content, please register your product by following the instructions below:

1. Visit denondj.com and click Account.

2. Click Sign In to access your existing account, or create a new account.

3. Once signed in, click Register New Product.

4. Enter the product serial number into the box and click Check Serial.

5. Complete the form and click Register Your Product.

6. Upon successful registration, any applicable software downloads, exclusive content, and promotional offers will

be shown in your account.

Devices & File Analysis

All PRIME hardware can play music files from USB drives, SD cards, or other connected PRIME media players. Make

sure you are using only the supported file systems (for USB drives or SD cards) and file formats (for music files) listed

below.

Supported file systems:exFAT (recommended), FAT32

Supported file formats:

AC/M4A

IF/AIFF (44.1–192 kHz, 16–32-bit)

LAC

FLAC

MP3 (32–320 kbps)

MP4

Ogg Vorbis

WAV (44.1–192 kHz, 16–32-bit)

Although PRIME hardware can play tracks that have not been analyzed yet, pre-analyzing them allows its features to

work most effectively. You can analyze tracks in one of two ways:

•On PRIME hardware, load the track: When you load a track to play, the PRIME hardware will automatically

analyze it (if it has not already been analyzed). This may take a moment to complete, depending on the

length of the track. You can start playing the track from the beginning immediately, though you will need to

wait a moment for the analysis to finish.

•Use Engine DJ software: The included Engine DJ software can pre-analyze your music library to use with

your PRIME hardware. You can also use it to organize your library by creating playlists. It also manages your

PRIME hardware preferences (see Operation to learn more about this).

Visit enginedj.com/downloads to download the Engine DJ software.

To eject a USB drive or SD card:

1. Make sure none of its tracks are being played on any connected PRIME media players. Ejecting a device unloads

its tracks from all networked PRIME media players.

2. Press Eject, or open the Source menu. A list of connected devices will appear in the main display.

3. Tap the eject icon for the device you would like to eject. If a track on the device is currently playing, you will be

asked if you want to continue ejecting, which will stop the track and clear the deck. Tap Cancel to cancel

ejecting the device, or tap Eject Anyway to eject it.

To eject additional devices, repeat Step 3.

To return to the previous screen, press Eject again, or tap the Xin the upper-right corner.

Configuration

PRIME hardware has several settings that you can customize in the User Profile and Settings menus. See Control

Center to learn about these settings.

Features

PRIME 4

Top Panel

24 23

30 31

40 41 42 43

24 23

30 31

40 41 42 43

55 56 57 57 57 58

60 61

62 63 64

66 66

67 68

52 53

55 56 57 57

52 53

1. Touchscreen: This full-color multi-touch display shows information relevant to PRIME 4's current operation.

Touch the touchscreen (and use the hardware controls) to control the PRIME 4 interface. See Touchscreen

Overview for more information.

Tip: If you adjust the angle of the touchscreen, use the stand on its back panel to secure it in place.

2. Browse Knob: Turn this knob to navigate through lists. Press the knob to move

forward in the touchscreen or select an item.

Press and hold Shift and then press this knob to send the selected track to the

Prepare list.

3. Back: While in Library View, press this button to move to the previous window. While in

Performance View, press this button to enter Library View.

4. Forward (FWD): While in Library View, press this button to move to the next window.

While in Performance View, press this button to enter Library View.

Press and hold Shift and then press this button to turn Quantize on or off.

5. Load : Press this button to load the selected track to Deck 1 or Deck 3.

Quickly double-press this button to instant double the track currently playing on the focused right deck (2/4) to

the focused left deck (1/3).

6. Load : Press this button to load the selected track to Deck 2 or Deck 4.

Quickly double-press this button to instant double the track currently playing on the focused left deck (1/3) to the

focused right deck (2/4).

7. View: Press this button to cycle between Library View and Performance View. Double-press this button to enter

the Engine Lighting view.

Press and hold this button to show the Control Center, which includes quick links to other menus such as Source,

Wi-Fi, Record, User Profile and Settings. See Control Center for more information.

Press and hold Shift and then press this button to toggle between vertical and horizontal waveforms in

Performance View.

8. Channel FX: Use these buttons to route audio from the corresponding

channel to the Effect 1 or 2 module.

9. Channel Level: Turn this knob to adjust the level of the pre-fader,

pre-EQ audio signal for the channel.

10. Channel Level Meters: These LEDs display the audio signal level of

the channel.

11. Channel EQ: Turn these knobs to boost or cut the high, mid-range,

and low frequencies for the channel.

12. Sweep FX: Turn this knob to control the effect selected by the Sweep

FX buttons.

13. Channel Cue: Press this button to send the channel’s pre-fader

signal to the headphones’ cue channel.

14. Channel Fader: Use this fader to adjust the channel’s volume level.

15. Crossfader Assign: Routes the audio playing on the corresponding

channel to either side of the crossfader (Lor R), or bypasses the

crossfader and sends the audio directly to the program mix (center,

Thru).

16. Crossfader: Use this crossfader to mix between channels assigned

to the left and right sides of the crossfader.

17. Master Level Meters: These LEDs display the audio signal level of

the master mix (sent out of the Master Outputs).

18. Phones Mix: Adjusts the software’s audio output to the headphones,

mixing between the cue output and the master mix output.

19. Phones Level: Adjusts the volume of the headphones.

20. Split Cue: When this button is On (fully lit), the headphone audio will

be “split” such that all channels sent to cue channel are summed to

mono and sent to the left headphone channel and the master mix is

summed to mono and sent to the right channel. When this button is

Off (dim), the cue channel and master mix will be “blended”

together. You can swap the left/right position of these channels in

the Settings menu.

21. Sweep FX Buttons: Press one of these buttons to enable or disable

an effect that you can control with the Sweep FX knobs. Only one

of these buttons can be enabled at a time.

•Filter: This effect applies a filter to the channel. Starting from the

center (12:00) position, turn a Sweep FX knob counter-clockwise

to apply a low-pass filter, or turn it clockwise to apply a high-pass

filter.

•Echo: This effect is a brief echo. Starting from the center (12:00)

position, turn a Sweep FX knob counterclockwise to decrease

the length of the delay and increase the feedback, or turn it

clockwise to increase the length of the delay as well as the

feedback.

•Noise: This effect adds noise to the signal. Starting from the

center (12:00) position, turn a Sweep FX knob counterclockwise

to add pink noise, or turn it clockwise to add white noise.

•Wash Out: This creates a transition effect. Turn a Sweep FX

knob to its most counter-clockwise (minimum) position to apply

a 1-beat echo that will also mute the channel’s normal audio

signal, or turn it to its most clockwise (maximum) position to

apply a 1/2-beat echo.

22. Platter: This capacitive, touch-sensitive platter controls the audio

playhead when the wheel is touched and moved. When the Vinyl

button is on, move the platter to “scratch” the track as you would with

a vinyl record. When the Vinyl button is off (or if you are touching only

the side of the platter), move the platter to temporarily adjust the

track’s speed.

23. Platter Display: This display shows track artwork and information

relevant to the performance, including the current playhead position,

the current auto loop size, or current layer. See Platter Display

Overview for more information.

24. Deck: Selects which deck in the software is controlled by that

hardware deck. The left deck can control Deck 1 or 3; the right deck

can control Deck 2 or 4.

Press and hold Shift and then press the Deck 3 or Deck 4 buttons to

switch between four-deck and two-deck operation.

If an LC6000 PRIME unit is connected to Rear USB Ports 3 and/or 4,

the respective Deck button(s) will be disabled.

25. Track Skip: Press either of these buttons to skip to the previous or

next track.

Press the Previous Track button in the middle of a paused track to

return to the beginning of the track.

Press and hold Shift and then press one of these buttons to search

backward or forward through the track.

26. Beat Jump: Press either of these buttons to skip backward or forward

through the track.

Press and hold Shift and press one of these buttons to increase or

decrease the beat jump size.

27. Sync /Sync Off: Press this button to activate sync.

Press and hold Shift and press this button to deactivate Sync. You can

also set Sync to deactivate without using Shift by changing the Sync

Button Action setting in the User Profile menu.

28. Cue: During playback, press this button to return the track to the

initial cue point and stop playback. (To move the initial cue point,

make sure the track is paused, move the platter to place the audio

playhead at the desired location, and then press this button.) If the

deck is paused, press and hold this button to temporarily play the

track from the initial cue point. Release the button to return the track

to the initial cue point and pause it. To continue playback without

returning to the initial cue point, press and hold this button and then

press and hold the Play button, and then release both buttons.

During playback, press and hold Shift and press this button to set the

initial cue point at the current playhead position.

29. Play/Pause: This button pauses or resumes playback.

Press and hold Shift and then press this button to “stutter-play” the

track from the initial cue point.

30. Vinyl: Press this button to activate/deactivate a “vinyl mode” for the

platter. When activated, you can use the platter to “scratch” the track

as you would with a vinyl record.

31. Key Lock /Key Sync: Press this button to activate/deactivate Key

Lock. When Key Lock is activated, the track’s key will remain the

same (0%) even if you adjust its speed. Press and hold Shift and

press this button to reset Key Lock.

During playback, press and hold this button to activate key sync for

the current track.

24 23

30 31

32. Pitch Fader: Move this fader to adjust the speed (pitch) of the track.

You can adjust its total range with the Pitch Bend buttons.

When you select another Deck with the Deck select buttons, the

position of the Pitch Fader may not match the Pitch setting for the

previous Deck. Slowly move the Pitch Fader in the direction indicated

by the green takeover LED arrow until it turns off. At this point, the

Pitch Fader matches the Pitch setting of the previous deck and can

control it again.

33. Pitch Bend –/+: Press and hold one of these buttons to momentarily

reduce or increase (respectively) the speed of the track.

Press and hold Shift and then press one of these buttons to set the

range of the pitch fader.

34. Shift: Press and hold this button to access secondary functions of

other controls.

35. Edit Grid: Press and hold this button to enable beat grid editing.

Press and hold Shift and then press this button while beat grid editing is

enabled to reset the beat grid.

Press and hold Shift and then press and hold this button while beat grid

editing is disabled to manually adjust cue/loop point locations left or

right using the touchscreen controls.

36. Grid Marker: When beat grid editing is enabled, press either of these buttons to move a downbeat marker backward

or forward based on the current analyzed grid.

Press and hold Shift and then press these buttons to halve or double the current tempo.

37. Slip: Press this button to enable or disable Slip Mode. In Slip Mode, you can jump to cue points, trigger loop

rolls, or use the platters, while the track’s timeline continues. In other words, when you stop the action, the track

will resume normal playback from where it would have been if you had never done anything (i.e., as if the track

had been playing forward the whole time).

38. Censor /Reverse: Press this button to activate/deactivate the Censor feature: the playback of the track will be

reversed, but when you release the button, normal playback will resume from where it would have been if you

had never engaged the Censor feature (i.e., as if the track had been playing forward the whole time).

Press and hold Shift and then press this button to reverse the playback of the track normally.

39. Performance Pads: These pads have different functions on each deck depending on the current pad mode. See

Pad Modes for more information.

40. Hot Cue: Press this button to enter Hot Cue Mode.

41. Loop: Press this button once to enter Manual Loop Mode, and press it again to enter Auto Loop mode.

42. Roll: Press this button to enter Roll Mode.

43. Slicer: Press this button to enter Slicer Mode, and press it again to enter Slicer Loop mode.

44. Parameter /: Use these buttons for various functions in each Pad Mode. See Pad Modes for more information.

45. Auto Loop/Loop Move: Turn this knob to set the size of an automatic loop. The value will be shown in the

touchscreen and platter display.

Press this knob to activate or deactivate an automatic loop at the current location of the track.

Press and hold Shift and turn this knob to shift the active loop to the left or right.

46. Loop In/Loop Out: Press either of these buttons to create a Loop In or Loop Out point at the current location.

Their placement will be affected by the Quantize and Smart Loops settings. See Looping & Beat-Jumping for

more information.

40 41 42 43

Andere Handbücher für PRIME 4

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Denon DJ-Equipment Handbücher

Denon

Denon DN-MC6000 Bedienungsanleitung

Denon

Denon PRIME GO Bedienungsanleitung

Denon

Denon DN-X100 Bedienungsanleitung

Denon

Denon DS1 Bedienungsanleitung

Denon

Denon PRIME 4 Bedienungsanleitung

Denon

Denon engine dj SC LIVE 4 Bedienungsanleitung

Denon

Denon DN-X100 Bedienungsanleitung

Denon

Denon DN-X500 Bedienungsanleitung

Denon

Denon X1800 Prime Bedienungsanleitung

Denon

Denon PRIME 4 Bedienungsanleitung

Denon

Denon MC4000 Bedienungsanleitung

Denon

Denon DN-S3700 Montage- und Bedienungsanleitung

Denon

Denon PRIME 2 Bedienungsanleitung

Denon

Denon DN-S700 - Compact Tabletop CD/MP3 Disc... Bedienungsanleitung

Denon

Denon MCX8000 Bedienungsanleitung

Denon

Denon MC6000MK2 Bedienungsanleitung

Denon

Denon DN-X1500 Bedienungsanleitung

Denon

Denon MCX8000 Bedienungsanleitung

Denon

Denon DNHD2500 - Dual DJ MP3 Player Bedienungsanleitung

Denon

Denon MC7000 Bedienungsanleitung

Denon

Denon SC5000 PRIME Bedienungsanleitung

Denon

Denon VL12 PRIME Bedienungsanleitung

Denon

Denon DN-MC6000 Bedienungsanleitung

Denon

Denon SC5000 PRIME Bedienungsanleitung

Beliebte DJ-Equipment Handbücher anderer Marken

ALPHA LITE

ALPHA LITE ALPHA 1500 Betriebsanleitung

Chauvet

Chauvet OVATION E-930VW Bedienungsanleitung

Zumtobel

Zumtobel APHRODITE Home Bedienungsanleitung

Snow Masters

Snow Masters Zig Oscillator Bedienungsanleitung

EuroLite

EuroLite 50530554 Bedienungsanleitung

Beamz

Beamz BUV243 Bedienungsanleitung

thomann

thomann Stairville DJ Lase 40-G MK-III Bedienungsanleitung

Eagletone

Eagletone 6 Eyes Flower Bedienungsanleitung

EuroLite

EuroLite FLD-1508 Bedienungsanleitung

Technical Pro

Technical Pro LG8xSEA Bedienungsanleitung

JB Systems

JB Systems Lounge Laser DMX Bedienungsanleitung

Lightmaxx

Lightmaxx Vega Halo 90 Bedienungsanleitung

Elation

Elation FUZE WASH Z350 Bedienungsanleitung

Maverick

Maverick MK3 WASH Bedienungsanleitung

Infinity

Infinity TF-260C7 Fresnel Bedienungsanleitung

Chauvet

Chauvet EVE E-50Z Bedienungsanleitung

Eliminator Lighting

Eliminator Lighting E 138 Bedienungsanleitung

EuroLite

EuroLite Mini Multicolor LED Flashing Light SC Bedienungsanleitung
