Light User Manual
Section I Introduction
• Type of protection against electric shock:
Class 1 Equipment
• Degree of protection against the ingress of
water: Ordinary
• Equipment not suitable for use in the presence
of a ammable anesthetic mixture with air or
with oxygen or nitrous oxide.
• Mode of operation: Continuous
Color Temperature: 5000° to 5700° Kelvin
Light Intensity:
High: 3345 Footcandles (36,000 Lux)
Med: 2508 Footcandles (27,000 Lux)
Low: 1672 Footcandles (18,000 Lux)
Light Pattern: 16.5 cm (6-1/2") x 8.9 cm (3-1/2")
Unit Weight: Post Mount: 12 kg (27 lbs.)
Recommended Environmental Conditions
Transport and Storage:
Temperature range of - 10º C to + 70º C
Relative humidity range of 10% to 100%
Atmospheric pressure range of 500-1060 kPa
Operation:
Temperature range of + 10º C to + 40º C
Relative humidity range of 30% to 75%
Atmospheric pressure range of 700-1060 kPa
This manual contains installation, operation and
care instructions and user service information for
the Simplicity® post-mounted LED Light.
To ensure correct installation, carefully read
all the instructions contained in this manual
paying close attention to all notes, notices,
cautions and warnings.
After the light is installed, please review the op-
eration procedures and care guidelines with the
doctor's sta.
Leave this manual in the doctor's oice.
The Simplicity® LED Light is intended to be used
by trained professional dental care personnel to
provide shadow free illumination to the oral cavity
for dental practices. The operatory light arm
system allows optimal light positioning, which
for a reclined patient, is normally from the sag-
ittal plane directly above or slightly behind the
patient's oral cavity. The operator will typically be
positioned behind or to one side of the patient.
The arm assembly is counterbalanced so that
minimum force is required to move the light head
assembly. The operatory light is not designed to
handle any external loads, such as hanging for-
eign objects from the light system.
The Simplicity® LED Light is designed to provide
trouble-free service when installed, operated, and
maintained according to the procedures set forth
in this manual.
IEC Type B
Conforms to:
AAMI Std. ES 60601-1
IEC Std. 80601-2-60
Certied to:
CSA Std. C22.2 60601-1
IEC Std. 80601-2-60
Specications
Classications
Power Supply:
Primary: 100 240V Ac, 50/60 Hz
Secondary 17V
Operating Amperage: 1.0 max.
Note:115V uses two 1 amp slo-blo fuses. 220V
uses two .5 amp slo-blo fuses.
Focal Length: 50.8 cm (20") to 114.3 cm (45")
