E-9 E-10
ELECTRONIC VOLUME CONTROL
- THIS UNIT USES AN ELECTRONIC VOLUME CONTROL .
- TO INCREASE OR DECREASE THE LOUDNESS OF UNIT, PRESS
THE VOLUME UP (VOL +) OR VOLUME DOWN (VOL -) KEYS RESPECTIVELY.
- RELEASE THE KEY WHEN VOLUME LEVEL IS AT THE DESIRED LOUDNESS.
- SOMETIMES, ESPECIALLY DURING LISTENING TO THE RADIO, YOU MAY NOTICE
A "CLICK-CLICK-CLICK" (REPEATING) SOUND WHEN YOU ARE INCREASING OR
DECREASING THE VOLUME. THIS IS A NORMAL CONDITION & THE SOUND WILL
DISAPPEAR WHEN YOU RELEASE THE VOLUME KEY (WHEN YOU REACH THE
DESIRED VOLUME LEVEL).
(PUSH BUTTON TYPE)
RADIO MEMORY (STATION PRESET MEMORY STORAGE)
- AT ANY TIME, THE CURRENTLY DISPLAYED STATION OR FREQUENCY CAN BE
STORED INTO ONE OF THE MEMORY POSITIONS.
- PRESS MEMORY KEY UNTIL "C01" FLASHES IN THE DISPLAY.
- PRESS SKIP- /SEARCH- AND SKIP+ /SEARCH+ KEYS TO SELECT DESIRED
MEMORY POSITION. (THERE ARE TOTAL 30 MEMORY POSITIONS).
- PRESS MEMORY KEY ONCE TO SAVE THE SELECTED STATION INTO THE
SELECTED MEMORY POSITION.
- TO RECALL ANY SAVED MEMORY, SIMPLY PRESS SKIP- /SEARCH- AND
SKIP+ /SEARCH+ KEYS THE SAVED RADIO-BAND WILL BE RECALLED.
- TO CLEAR THE MEMORY OF ANY POSITION, SIMPLY SAVE A NEW STATION TO THE
SAME MEMORY POSITION.
OPERATION OF RADIO
AUTOMATIC FREQUENCY ADJUSTMENT (SEEK MODE)
- PRESS AND HOLD (FOR 2 SECONDS) THE SKIP- /SEARCH- AND
SKIP+ /SEARCH+ KEYS TO “SEEK” (AUTOMATICALLY ADJUST) THE RADIO
FREQUENCY “UP” OR “DOWN” TO THE NEXT AVAILABLE RADIO STATION.
- THE RADIO DIGITAL DISPLAY WILL INDICATE THE EXACT FREQUENCY OF THE NEXT
STATION THAT IS FOUND.
- WHEN A DESIRED STATION IS REACHED. IT CAN BE SAVED INTO ONE OF THE
“MEMORY” POSITIONS. (SEE “RADIO MEMORY” SECTION).
- PRESS THE "ON/ OFF" KEY ONCE TO SWITCH ON THE UNIT.
- PRESS THE FUNC./CL-SET KEY REPEATEDLY UNTIL THE DISPLAY SHOWS "FM".
- EXTEND AND ADJUST THE FM-WIRE ANTENNA TO OBTAIN THE BEST RECEPTION.
- USE THE ST/MO KEY TO SELECT THE DESIRED MODE (STEREO/ MONO).
IN SOME CASES, WHERE RECEPTION IS POOR, IT MAY BE ADVISABLE TO
SELECT “MONO” MODE, TO IMPROVE CLARITY OF THE RADIO SIGNAL.
MANUAL FREQUENCY ADJUSTMENT (SCAN MODE)
- PRESS (AND IMMEDIATELY RELEASE) THE SKIP- /SEARCH- AND
SKIP+ /SEARCH+ KEYS TO “SCAN” (MANUALLY ADJUST) THE RADIO
FREQUENCY “UP” OR “DOWN” BY 1-STEP AT A TIME.
- THE RADIO DIGITAL DISPLAY WILL INDICATE THE EXACT FREQUENCY AT EACH
STEP’S POSITION.
- WHEN A DESIRED FREQUENCY OR STATION IS REACHED. IT CAN BE SAVED INTO
ONE OF THE “MEMORY” POSITIONS. (SEE “RADIO MEMORY” SECTION).
MUSIC EQUALIZER
- AT ANYTIME DURING PLAYBACK, PRESS KEY REPEATEDLY TO
CHOOSE THE DESIRED SOUND EFFECT ACCORDING TO THE MUSIC YOU ARE
LISTENING TO :
EQ/SLEEP
E-0 = EQ OFF E-1 = CLASSIC
IMPORTANT
PLEASE NOTE THAT WHEN CONNECTING A iPod VIDEO, THE ERROR MESSAGE
“THE CURRENTLY ATTACHED ACCESSORY IS NOT SUPPORTED BY THIS iPod.”
WILL BE DISPLAYED AS THERE IS NO VIDEO INPUT/OUTPUT. HOWEVER,
ALL AUDIO FUNCTIONS WILL OPERATE NORMALLY AS OUTLINED ABOVE.
OPERATION WITH THE iPod
- TURN ON BOTH THE UNITAND THE iPod.
- CONNECT THE iPod TO THE UNIT AS DESCRIBED.
- PRESS THE FUNC./ CL-SET KEY REPEATEDLY UNTIL THE DISPLAY SHOWS “iPod”.
- PRESS THE PLAY/ PAUSE KEY ON THE UNIT, THEN THE FIRST SONG WILL
START PLAYING.
- THE iPod DISPLAY WILL INDICATE THE INFORMATION OF THE CURRENT SONG.
- YOU CAN OPERATE THE iPod USING EITHER THE UNIT'S BUTTONS, OR DIRECTLY
WITH THE iPod ITSELF.
- WHEN THE iPod HAS BEEN CONNECTED WITH THE UNIT, IT WILL START CHARGING
THE BATTERY OF THE iPod.
- NEVER REMOVE (OR UNPLUG) THE iPod FROM THE SET DURING PLAYBACK,
ALWAYS PAUSE PLAYBACK FIRST AND THEN PRESS THE FUNC/ CL-SET KEY TO SWITCH
TO ANOTHER SOURCE (EG. “RADIO” OR “AUX”) BEFORE REMOVING OR UNPLUGGING
THE iPod, TO PREVENT DAMAGE TO YOUR SONG FILES OR MEMORY DEVICES.
- AT ANYTIME DURING PLAYBACK, PRESS THE PLAY/PAUSE KEY TO PAUSE
PLAYBACK. PRESS PLAY/PAUSE KEY TO RESUME PLAYBACK OF THE SAME
SONG & POSITION.
- AT ANYTIME DURING PLAYBACK, PRESS AND RELEASE THE SKIP- /SEARCH-
OR SKIP+ /SEARCH+ KEYS TO SKIP FORWARD OR BACKWARDS BY ONE SONG,
AS DESIRED.
- AT ANYTIME DURING PLAYBACK, PRESS AND HOLD THE SKIP- /SEARCH-
OR SKIP+ /SEARCH+ KEYS TO FAST-FORWARD (CUE) OR FAST-REVERSE (REVIEW)
THE SPECIFIC SONG, WHICH IS CURRENTLY PLAYING.
E-2 = JAZZ
E-3 = ROCKE-4 = POP
