Quick Setup Guide



Quick Setup

Guide

Table of Contents

Chapter 1

Quick Setup Guide.............................................

Chapter 2

nglish......................................................................

Chapter 3

Français (French).................................................

Chapter 4

Deutsch (German)................................................

Chapter 5

spañol (Spanish)..................................................



Quick Setup Guide

Quick Setup

Guide

Chapter 1 - Quick Setup Guide

Table of Contents

1.1 System Board Layout..................................................................................................

1. Jumpers.....................................................................................................................................

1.3 Ports and Connectors................................................................................................

1.4 Award BIOS Setup Utility.......................................................................................

Quick Setup Guide



Quick Setup

Guide

1.1 System Board Layout



Quick Setup Guide

Quick Setup

Guide

1.2 Jumpers

1.2.1 Clear CMOS Data - JP5

-3 On:

Clear CMOS Data

1- On:

Normal (default)

1.2.2 Wake-On-Keyboard / Wake-On-Mouse - JP2

1- On:

Disable the Wake-On-

KB/Mouse function

(default)

-3 On:

Enable the Wake-On-

KB/Mouse function

Important:

The 5VSB power source of your power supply must support

≥

720mA.

Quick Setup Guide



Quick Setup

Guide

1.2.3 Wake-On-USB Keyboard - JP1 and JP4

Important:

 If you are using the ake-On-USB Keyboard function for 2 USB

ports, the 5VSB power source of your power supply must

support

≥

1.5A.

 If you are using the ake-On-USB Keyboard function for 4 USB

ports, the 5VSB power source of your power supply must

support

≥

2A.

-3 On:

Enable the

Wake-On-USB KB

1- On:

Disable the

Wake-On-USB KB

(default)

1 3

Regardless of the USB port (USB 1, , 3 or 4) used, these jumpers

settings must be identical.



Quick Setup Guide

Quick Setup

Guide

1.2.4 PC Speaker or Buzzer Select - JP6

-3 On:

PC Speaker

1- On:

Buzzer (default)

1 3

Quick Setup Guide



Quick Setup

Guide

1.3 Ports and Connectors

1.3.1 PS/2 Mouse and PS/2 Keyboard Ports

Make sure to turn off your

computer prior to connecting or

disconnecting a mouse or keyboard.

Failure to do so may damage the

system board.

PS/ Mouse

PS/ Keyboard

1.3.2 Parallel Port

Parallel Port
