Diamond Multimedia Stealth X550 Bedienungsanleitung

X550

19748 Dearborn Street

Chatsworth, CA 91311

Tel: (818) 534-1414

Fax: (818) 773-9619

www.diamondmm.com

Featuring:RADEONTM X550

Memory: 256MB DDR

Slot Type: PCI Express

With:  SVGA & DVI/TV-Out

Stealth X550

Cinematic 2D/3D Graphics Card

Get the most from your gaming, digital

photography, video editing and web

surfing experiences with the Stealth®

X550, an affordable graphics upgrade

featuring ATI’s industry-leading

performance, technology and support.

The Stealth X550 fully supports the PCI

Express®bus, the newest PC industry

standard for delivering maximum real-

time performance for your graphics-

intensive software applications.

Overview

Diamond, Diamond Multimedia and Stealth are registered trademarks of Diamond Multimedia.ATI, Graphics by ATI, and Radeon are trademarks

LATEST TECHNOLOGIES

NATIVE PCI EXPRESS

Takes advantage of the latest 0.11 micron process to bring the fastest performing programmable

shaders into the mainstream.

Enables unprecedented flexibility for new applications and enhanced performance. Full 16 lane

support with 8GB/sec bidirectional peak bandwidth support (vs. bridged AGP bottleneck).

SMARTSHADER & VIDEOSHADER

Provides superior programmability and performance by implementing Microsoft DirectX 9.0-level

shaders at full precision at all times. Includes: Four advanced programmable shaders; full precision,

full speed all the time; MPEG1, MPEG2, MPEG4, DivX, Windows Media 9, and Real Media hardware

acceleration; adaptive per-pixel de-interlacing, dynamically selected for every pixel.

DUAL MONITOR SUPPORT

Drive two monitors simultaneously – great for IT staff, engineers, designers and anyone who

frequently moves back and forth between productivity applications. At home, use the Stealth X550

to play a DVD on your TV while you work seperately on your VGA or DVI monitor.

2 FAST GEOMETRY ENGINES

With each engine capable of delivering two times the output over those available in competing

technologies

4 FULL PRECISION PIPELINES

Over double what other graphics technologies can offer to provide over 2 GigaPixels/sec of unmatched

shader power

SPECIFICATIONS:

SYSTEM REQUIREMENTS:

•GPU: Radeon X550

•Bus Type: PCI-Express x16

•Memory: 256MB DDR – 128bit

•Core Clock: 400 MHz

•RAMDACS: Dual 400 MHz

• API Support: DirectX

9.0, OpenGL 2.0

•Output: DVI, VGA, TV-Out

•Supports for Hardware and Transform 

 and Lighting (T&L)

•

Intel®Pentium®4 or AMD®Athlon® 64 FX CPU's

•CPU running at 2.4 GHz or higher

•420 Watt power supply or higher

•Super VGA or DVI-I compatible monitor

•Microsoft Windows

XP, 2000, MCE

•PCI Express X16 compliant slot

•CD-ROM or DVD-ROM drive

•64MB system RAM

•150MB available hard disk space

Final Fantasy XI

Benchmark 3 v1.00

AquaMark3 v1.0

(default=4xAF)

Tomb Raider v49 PS2.0

Half-Life 2 Prison Time

demo 1024x768

Far Cry v1.3

Training Level

3DMark05 build 110

(defaults & DST enabled)

Stealth®X550 128MB, 128bit GeForceTM 6200 256MB GeForceTM 6200 TurboCacheTM 256MB

0.00 0.20 0.40 0.60 0.80 1.00 1.20 1.40 1.60

*Radeon X550 128MB 128-bit compared with GeForceTM 6200 with 256MB TurboCacheTM and GeForce 6200TM 256MB. Test system:

 Intel Pentium 4, 3.4GHz, 512 MB RAM. Graphics settings: 1024x768. Drivers:ATI 8.121rc1, NVIDIA 71.84.

VIDEOSHADER are trademarks and/or registered trademarks of ATI Technologies Inc. All other company and/or product names are

trademarks of their respective owners. Features, performance and specifications may vary by operating environment and are subject

to change without notice.
