Dictaphone 1244 Bedienungsanleitung
M
i
n
i
c
a
s
s
e
t
t
e
V
o
i
c
e
P
r
o
c
e
s
s
o
r
1244
Operating
Instructions
ii
CONTENTS
Machine Layout . . . . . . . . . . . . . . . . . .iv
Description . . . . . . . . . . . . . . . . . . . . . .1
Getting Started . . . . . . . . . . . . . . . . . . .2
Recording and Editing . . . . . . . . . . . . .3
Additional Features . . . . . . . . . . . . . . . .6
Optional Accessories . . . . . . . . . . . . . .8
Specifications . . . . . . . . . . . . . . . . . . . .10
Français . . . . . . . . . . . . . . . . . . . . . . .11
Deutsch . . . . . . . . . . . . . . . . . . . . . . . .25
Español . . . . . . . . . . . . . . . . . . . . . . . .39
Português . . . . . . . . . . . . . . . . . . . . . .53
iii
5 4 3
7 6
8
2
1
14
13
10
11
12
9
iv
MACHINE LAYOUT
1 Security Lock
2 Slide Control Record/Stop/Play/Rewind
3 LED for Record Mode and Low
Battery Indication
4 VOX Switch (Voice Activated Control)
5 Dictate/Conference Switch
6 Remote Microphone Jack
7 Microphone
8 Volume Control for Playback
9 Cassette Compartment
10 Speaker
11 AC Adapter Jack
12 Battery Compartment
13 Cassette and Battery Compartment Cover
14 Fast Play and Instruction Cues
DESCRIPTION
The Dictaphone Model 1244 portable recorder is a
compact minicassette recorder that provides the
following features:
•Conference recording
•VOX recording
•Record indicator
•Low battery indicator
•Fast play with audible feedback
•End-of-cassette warning tone
•Interview recording
•Choice of two power sources
The Model 1244 recorder comes packaged with an
M-30 minicassette, but does not include batteries.
1
GETTING STARTED
Loading Batteries
To load batteries:
•Slide front cover down and remove completely.
•Insert 2 AAA alkaline batteries (or nickel-cadmium
rechargeable battery pack) into battery
compartment.
The optional AC Adapter can be used instead
of batteries to power your Model 1244 portable
recorder:
To use the optional AC Adapter:
•Insert the power cord into the external power
jack (DC 3V).
•Connect the plug to a grounded AC wall outlet.
Caution: Use of other than the proper adapter may
apply improper voltage and may damage your
portable recorder.
Inserting Cassette
To insert cassette:
•Move the Slide Control to Stop position.
•Slide front cover down to access cassette
compartment.
•Insert minicassette with Side 1 facing upward and
exposed tape on the left.
2
3
RECORDING AND EDITING
Recording Dictation
To record dictation:
•Move Lock switch left to Off position.
•Move the Slide Control up to Rec position.
Record LED indicator will illuminate.
Reviewing and Correcting
To review your dictation:
•Move Slide Control down and hold in
Rew position. Tape rewinds with
audible feedback.
•Release Slide Control to return automatically
to Play mode for reviewing dictation.
•Adjust Vol control.
•To make corrections, locate the dictation
you want to change and record over
unwanted dictation.
Forward Scanning
Use Fast Play for high speed review of
your dictation:
•Move the Slide Control to Play.
•Press the F. Play button.
4
Reviewing and Editing Your Dictation
Reviewing:
•Move and hold the Slide Control in Rew.
Recorded areas on the tape produce audible
feedback
•Release the Slide Control to begin playback.
Adjust the Volume Control as needed.
Ending Your Dictation
When recording is complete:
•Move the Slide Control to the Stop position.
•Slide the Security Lock to the right to lock the
Slide Control. (Orange flag is visible when
recorder is locked.)
NOTE: If the Slide Control is not locked, it could be
moved accidentally, causing the battery power to be
drained or recording to be erased.
5
End of Letter Cues
The Alert Indexing feature permits you to record
cue tones to mark the end of letters. These tones
assist the transcriptionist in locating and processing
your dictation more efficiently.
To record a cue at the end of each letter:
•With the slide control in the Rec position, briefly
press and release the F. Play button. A single
tone is generated.
•During review, either the author or a
transcriptionist can easily locate a specific letter
if the number of the cue has been noted.
Instruction Cues
Instruction Marks - to mark the location of an
instruction
•Move the Slide Control to the Rec position and
press the F. Play twice, and then dictate your
instruction.
6
ADDITIONAL FEATURES
Microphone Recording
Plugging an external microphone into the
unit’s Mic Jack automatically disconnects the
built-in mic.
•Plug the Microphone into the Mic jack.
•Move the Slide Control to Rec and begin
dictating. The Record/Battery LED indicator
will illuminate.
Telephone Recording
Plugging the Telephone Record Adapter into the
unit’s MIC jack disconnects the built-in mic.
•Plug the Telephone Record Adapter into the
Mic jack.
•Move the Slide Control to Rec and begin
dictating. The Record/Battery LED indicator
will illuminate.
Conference Recording
The Model 1244 minicassette portable recorder can
be used to record conferences, meetings, seminars,
interviews, etc.
To record conferences:
•Move the Dict/Conf switch to Conf position.
•Move the On/Off switch to the On position.
•Move the slide control to Rec position.
•Place the recorder in a central location.
