Note: The parking guard function does not work when the camera is configured to turn on/ off manually. It works only when the
camera shuts down automatically with the ignition.
Motion detection
When motion detection mode is on, the device will remain in standby until movement is detected. When movement is detected,
recording will be triggered (for 10 seconds) and a small yellow dot will appear in the upper right-hand corner of the screen.
Menu Options Description Available options
Video Quality Sets the resolution of video files. Higher
resolutions use memory faster. Dual-cams
requires the last option.
UHD-4K (2 0×2160) @ 24 fps, QHD-2K (2560×1440) @ 30 fps,
FHD (1920×10 0) @ 60 fps, FHD (1920×10 0) @ 20 fps, HD
(10 0×720) @ 120 fps, 60 fps, or 30 fps, OR FHD P30
＋
FHD P30
10 0P front plus 10 0P 2
nd
cam (set this when both cameras in
operation.)
Loop recording Sets the video segment time 1 minute, 3 minutes, 5 minutes, 10 minutes, or Off
Shrink video
recording
Set the number of video frames 100MS, 200MS, 500MS, off
WDR Wide dynamic range: automatic adjustment of
lighting
On, Off
Exposure
compensation
Brightens or dims the video. Default is 0.
Positive is brighter. Negative is dimmer.
+2.0, +5/3, +4/3, +1.0, +2/3, +1/3, + 0.0, -1 / 3, -2/3, -1.0, -4/3,
-5/3, -2.0
Motion Detection Automatically record when detecting movement
(in standby mode.)
On, Off
Video, audio Record audio or not On, Off
Time watermark Watermark of the date and time On, Off
G-sensor Shock video is saved separately High, Medium, Low, Off
Parking
monitoring
When the car is stopped and the cam is in
standby, dash cam will start recording if any
vibration is detected.
On, Off
License plate
number
You can input license plate number of the car and
display it in the video file
Enter the number
ADAS Lane departure and object warning On, Off
Date / time Date and time Can set year, month, day, hour, minute, second
Automatic
shut-down
Auto turn off cam after vehicle is shut off 1 minute, 2 minutes, 3 minutes, 5 minutes, 10 minutes
Button sound the button sound when operating system On, off
language settings The language of the operation menu Set your language. Default is English.
TV mode Video output standard (USA is NTSC) NTSC, PAL
Light source
frequency
USA is 60 Hz 50HZ, 60HZ
Screen protector Option to turn off the screen but NOT stop
recording
Off, 1 minute, 3 minutes
Format Delete the data on the memory card TF card
Default setting Restore factory settings Cancel, Confirm
Version Factory software version Software version number
Product Specification Sheet:
File formats Video: MP4 / Photo: JPG
Video resolution 4K, 2K, 10 0p, 720p, or Dual 10 0p
Processor Dual core with WDR technology and 1GB Ram
