DIG RBC 7000 Bedienungsanleitung

Battery Powered

In-line Valve

with Watering Timer

RBC 7000

INSTRUCTION MANUAL

TABLE OF CONTENTS

1. Introduction ………………………………………………………… 1

2. About the RBC 7000 battery timer …………………………………… 1

3. Component identiﬁcation …………………………………………… 1

4. LCD display and controls …………………………………………… 2

5. Installing the batteries ……………………………………………… 3

6. Installation…………………………………………………………… 4

7. Programming………………………………………………………… 7

8. Setting current time and date ………………………………………… 7

9. Setting watering day schedules ……………………………………… 9

10. Setting watering start times …………………………………………12

11. Setting watering run time duration ……………………………………14

12. Setting rain delay – optional feature …………………………………16

13. Manual watering ……………………………………………………17

14. Connecting a rain sensor ……………………………………………18

15. Changing the batteries ………………………………………………19

16. Maintenance, troubleshooting and repairs ……………………………20

17. Warranty ……………………………………………………………22

18. Technical assistance …………………………………………………23

19. To order replacement or spare parts …………………………………23

1. INTRODUCTION

Thank you for purchasing DIG’s RBC 7000 Single Station Battery Operated Timer.

This manual describes how to get the RBC series timer up and running quickly.

After reading this manual and becoming familiar with the basic functionality of the

timer, use the manual as a reference for less common tasks in the future.

2. ABOUT THE RBC 7000 BATTERY OPERATED TIMER

The RBC 7000 watering timer employs the latest irrigation programming features

to allow for complete control of any irrigation system and can be installed on either

an outdoor faucet or a PVC main water line. The RBC 7000 is available in single

station with a rain sensor connection, and is powered by two AA batteries that can

last up to 3 years [using name brand alkaline batteries]. The timer is enclosed in a

compact, waterproof housing to protect it from the elements.

3. COMPONENT IDENTIFICATION

1. Timer cover

2. Quick reference label

3. LCD Display displays the icon-based

applications/ programs

4. 7 button programming keypad: Use for

programming, system on/off, manual run

and reviewing program

5. Battery compartment cap for

two AA alkaline batteries (not included)

6. Rain sensor yellow wire connection

7. Collapsible 36 in. solenoid wire

8. DC solenoid

9. Manual ﬂow control

10. Solenoid Adapter

11. 3/4 in. professional grade in-line valve

4. LCD DISPLAY AND CONTROLS

LCD Display

1. Time and Date Icon – Indicates current time and day is displayed

2. Sensor Icon – Appears when a rain sensor is active or when yellow wire loop

has been cut and watering is halted

3. Watering Icon – Appears when valve is open

4. Set Watering Days Icon – Choose either speciﬁc days, odd/even days, every X

hours, or up to once every 30 days

5. Start Time Icon – Up to 4 start times per day available

6. Run Time Icon – Watering duration from 1 minute to 5 hours and 59 minutes

7. Rain Delay Icon – Delay irrigation setting from 1 to 99 days with automatic restart

8. Manual Run Icon – Appears when manual button is pushed

9. Battery Level Indicator – Flashes when batteries are low and need to be replaced

10. Day of the Week Underscore –Shows which day of the week the timer

will operate

11. Represents Month

12. Represents Year

ry u i

Control Buttons

Select programming mode

Turn program(s) ON/OFF

Start/stop a manual cycle

Move left/right to select a value

Raise/lower the selected value

5. INSTALLING THE BATTERIES

1. Open the battery compartment cap by

turning it counter-clockwise.

2. Install two, fresh, brand name, AA

alkaline batteries (not included)

and note the proper direction of the

positive and negative orientation on the

underside of the timer.

3. Insert and screw the battery cap

clockwise. Make sure to securely

tighten the cover ﬁrmly by hand only.

The timer display appears with a day,

PM, and the hour digit ﬂashing. The timer

is ready to be installed and programmed.

6. INSTALLATION

The RBC 7000 timer has a 3/4 in. inlet and outlet with

female pipe thread so it can be installed directly onto

3/4 in. PVC male pipe thread ﬁttings as part of a sprinkler

valve manifold or as a stand-alone unit. (Figure 1)

The RBC 7000 timer can be attached to a hose or faucet/

spigot using the two adapters that are included with the

timer. (Figure 7)

Warning: Wrap all pipe thread ﬁttings with Teﬂon tape.

Do not use pipe dope/pipe cement on valve! This will

damage the valve and void the warranty!

ATTENTION: PLEASE NOTE THE DIRECTION OF THE

VALVE WHEN INSTALLING. THE SOLENOID AND TIMER MOUNT IS POSITIONED

TOWARDS THE OUTLET SIDE OF THE VALVE.

IN-LINE INSTALLATION

Rated operating pressure: 10-125 PSI

Recommended Operating Pressure:

10-80 PSI

1. Shut off main water supply.

2. Install a 3/4 in. ball or gate valve onto the PVC pipe

or to the valve manifold before installing the timer (Figure 2 and 3). This valve can

be very useful as an emergency

backup to turn the system off. This

type of arrangement is used by

professional installers.

3. Turn water supply on to ﬂush the line

and then shut the water off using the

ball or gate valve.

4. Install the timer wrapping Teﬂon

tape on all male pipe thread ﬁttings.

Figure 1

Figure 2

Below ground installation

Figure 3

water

flow

WATER FLOW

5. Turn water supply on to pressurize the system. The timer will open momentarily

and then will shut off.

6. The unit is now ready to be programmed.

FAUCET INSTALLATION

1. Wrap the swivel adapter and the nipple male pipe threads with 4-6 layers of

Teﬂon tape in a clockwise direction.

2. Screw the swivel adapter male threads into the inlet side of the controller valve

and tighten with a wrench or pliers. Repeat the steps with the ¾” MPT x MHT

nipple. (see Figure 4).

Note: Do not apply any Teﬂon tape to the male hose thread faucet.

3. Make sure the washer is in place inside the female swivel adapter, and then

screw the female swivel threaded clockwise onto the faucet and tighten by

hand only. Do not use pliers or a wrench. (Figure 5)

4. Turn on the faucet and check for leaks.

Warning: Do not tighten the swivel nut with pliers or wrench: Over-

tightening can cause damage to the swivel and washer resulting in leaks

and/or disconnection from the faucet.

Basic installation of converting the controller with pipe thread into a hose thread

Figure 2

3/4 in. FHT x MNPT

swivel adapter

Nipple pipe

x hose thread

Figure 5Figure 4

water

flow

If a backﬂow preventer is part of the faucet (new houses) do not install any other

backﬂow preventer to the faucet. If backﬂow preventers are part of your city code

and you have purchased a unit as part of your drip system, install the device on the

downstream side of the RBC 7000 (Figure 6 and 6a).

It is best to include a ﬁlter on a drip system. The ﬁlter cleans small particles out of

the water that would otherwise clog the drippers. The ﬁlters can also automatically

apply fertilizer through a drip system (Figure 7 and 8).

backﬂow preventer

Hose end drip system installation using a pressure regulator

pressure regulator

swivel adapter

to drip system

Figure 6 Figure 6a

Hose end drip system installation using a ﬁlter and a pressure regulator

Figure 8Figure 7

ﬁlter

pressure regulator

swivel adapter

to drip system

water

flow

water

flow

backﬂow preventer

Figure 8

7. PROGRAMMING

The RBC 7000 timer can be programmed to operate on any day of the week, odd

days or even days. In cyclical mode the RBC can also operate from every 1 hour up to

every 12 hours or from once a day up to every 30 days. The RBC has four start times

per day and durations from 1 minute up to 5 hours and 59 minutes.

This section explains the programming features, and the steps necessary to assign

irrigation schedules. To program the timer use the to select the desired

programming mode, the to make the entry ﬂash and the buttons to

change the value.

NOTE: Only a ﬂashing value can be changed.

NOTE: If the last data entered stops ﬂashing, press again to resume

programming and repeat the steps.

8. SETTING CURRENT TIME AND DATE

The timer can display the time in either a 12 or 24 hour format.

To change the time format, from the home screen:

1. Press the button for three seconds until the display switches format

(AM/PM disappears).

SETTING THE CURRENT TIME AND DATE

To enable the timer to operate properly, the current time and date must

be set.

1. Press the button, until the icon appears along with the time and the day

of the week.

2. If the current time has not been set or needs to be updated press and the

hour digit starts ﬂashing.

3. To set the current hour, press or (note AM and PM designations).

4. To set the minutes, press again and the minute digit starts ﬂashing. Press

the or to set the current time in minutes.

5. Repeat the steps to set the current date including, month, day and year. When

the date is selected and updated, the day of the week will be update at the

same time to correspond with the date.

MONTH DAY YEAR
