Digikeijs DR 4088 series Bedienungsanleitung

DR4088CS / GND / OPTO 2021-08-11

P 1

www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz

DR 4088xx

Instrucon manual

(2021-08-11)

rights reserved. No informaon, images or any part of

this document may be copied without the prior wrien

permission of Digikeijs.

DR4088CS / GND / OPTO 2021-08-11

P 2

www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz

1 Index

1.0 General informaon 2

1.1 Index 2

1.2 Warranty and warranty condions 3

1.3 Legal informaon 3

2.0 Product overview 4

2.1 General product informaon 4

2.2 Technical Specicaons 4

2.3 Hardware Overview 5

3.0 Programming 6

3.1 DR4088xx programming (start address in the

DR500xx assigned 6

3.2 DR4088xx reset 7

4.0 Connecon examples 7

4.1 Feedback modules DR4088CS; 2-wire track 8

4.2 Feedback modules DR4088CS and DR5033

Booster; 2-wire track 9

4.2 Feedback modules DR4088OPTO; Hall sensors,

3-wire track 10

4.3 Feedback modules DR4088OPTO; Hall sensors,

2-wire track 11

4.4 Feedback modules DR4088GND

3-wire track 12

1 General Informaon

DR4088CS / GND / OPTO 2021-08-11

P 3

www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz

1.2 Warranty and warranty condions

All our products come with a 24-month manufacturer's warranty. Please read these operang instrucons carefully.

Damage to the product caused by non-compliance with these instrucons will invalidate the warranty.

ATTENTION: The warranty is void if the housing of the product is opened.

1.3 Legal informaon

Prinng errors and mistakes, technical or other changes as well as changes in the availability of individual products are expressly reserved.

Data and illustraons are non-binding. All changes to hardware, rmware and soware are reserved.

We reserve the right to change the design of the product, the soware and / or the rmware without prior noce.

All Digikeijs operang instrucons and other wrien instrucons supplied and/or downloadable are protected by copyright.

Reproducon is not permied without the wrien permission of Digikeijs.

DR4088CS / GND / OPTO 2021-08-11

P 4

www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz

2.0 Product overview

2.1 General product informaon

The DR4088xx is a feedback module that can be connected to the central unit via the S88(N)®.

The DR4088-xx has 16 feedback inputs.

The DR4088xx is available as CS version (current sensor 2-wire track), as OPTO version (connecon of reed contacts, 3-wire track signal to track ground) and as

GND version (3-wire track).

2.2 Technical specicaons

The connecon terminals of the 16 feedback units are designed for a cross-secon of 0.5mm², the two terminals for "C" are designed for a cross-secon of

0.75mm².

Number of

inputs

Suitable

for

Minimum load for safe

reporng

Max. load per

contact Load

per contact

Max. load per con-

tact Load capacity

per contact for

max. 100 ms

Peak load for 8 feedbacks at

"C" total.

DR4088CS 2 x 8 2 conductors 2 mA 2 A 5 A 6 A an „C“

DR4088OPTO 2 x 8 3 conductors

when using the

DR50xx

- - -

DR4088GND 2 x 8 3 conductors

Important! DR4088GND 3-wire operaon:

Due to the H-bridge (track output) in the DR50xx, feedback devices in the DR4088GND version must not be used against track ground, as

is usually the case with 3-wire tracks. This inevitably leads to the destrucon of the DR50xx.

If a 3-wire driver sll wants to drive with the DR50xx and report back against track ground, the DR4088OPTO

can be used.

DR4088CS / GND / OPTO 2021-08-11

P 5

www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz

2.3 Hardware Overview

1Connecon feedback 1 to 8

2Common connecon "C" for the right or le detector group.

3Connecon feedback 9 bis16

4S88® OUT connecon

(connue to the next DR4088xx)

5S88® OUT connecon

(to central or previous DR4088xx)

6red LED

(ashing during load or acvity at S88N connecon)

7S88N® IN connector (standard RJ45 patch cable).

(connue to next DR4088xx)

8S88® IN connecon

(connue to the next DR4088xx)

123

45678

DR4088CS / GND / OPTO 2021-08-11

P 6

www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz

3.0 Programming

First, something fundamental about the S88(N) Bus®:

• The S88(N)® bus is a universal bus system.

• The S88(N)® bus supports a maximum of 256 feedback addresses.

• The addresses are always assigned automacally and connuously. No universal and unique addressing is possible because the S88(N)® bus is not desig-

ned for individual address assignment!

• The S88(N)® can only be set up as a bus (line) network. This always means from 1. feedback to 2. feedback, etc.

3.1 Programming DR4088xx (Assign start address in DR50xx)

The S88(N)® bus system does not provide programming in the actual sense. It only has to be dened in the central with which address the S88(N)® bus starts

and how many modules are located on the bus.

Programming the start address in the DR50xx

1. Start the DR50xx tool.

2. Call up the sengs for the S88(N)® bus with the buon in the ext88N tool.

3. The start address and the number of modules must now be entered in this input mask.

DR4088CS / GND / OPTO 2021-08-11

P 7

www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz

4.0 Connecon examples

In this chapter you will nd some connecon examples for the DR4088xx. Please note that we are not able to show all possibilies.

3.2 Reset DR4088xx

Important! The DR4088xx The DR4088xx has no funcon for reseng to factory sengs!

Since no sengs or funcons are stored in the feedback module, this is not necessary!

Important! DR4088GND 3-wire operaon:

Due to the H-bridge (track output) in the DR50xx, feedback devices in the DR4088GND version must not be used against track ground, as is usu-

ally the case with 3-wire tracks. This inevitably leads to the destrucon of the DR50xx.

If a 3-wire driver sll wants to drive with the DR50xx and report back against track ground, the DR4088OPTO

can be used.

DR4088CS / GND / OPTO 2021-08-11

P 8

www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz

4.1 Feedback modules DR4088CS; 2-wire track

® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz

DR5000 in conjuncon with S88N® feedback modules

The ext88N connector of the DR5000 is a compable S88N® bus.

In this example the feedback modules DR4088CS (current sensors) are used. These feed-

back modules are connected to the DR5000 and to each other with normal RJ45 cables. A

maximum of 16 S88N® modules with 16 inputs each can be connected to the central unit. A

total of 256 feedback modules (S88N®/ext88N ) can be managed by the DR5000.

DR4088CS / GND / OPTO 2021-08-11

P 9

www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz

® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz

4.2 Feedback modules DR4088CS and DR5033 Booster; 2-wire track

Both sides

track isolaon

DR4088CS / GND / OPTO 2021-08-11

P 10

www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz

power supply

4.3 Feedback modules DR4088OPTO; Hall sensors, 3-wire track

Light barrier, Hall sensors or

the like

(posive switching PNP)

5V-20V

DC/AC

Feedback "Track mass" switch track reed contact

DR4088OPTO

More DR4088xx

feedback unit
