Recording Hold mode.
In the Min/Max Recording Hold mode, press to stop the recording of readings, press again to
resume recording.
However, the multimeter is operating even though it is in the Data Hold state, therefore, the buzzer will sound for
an over range or in continuity mode and if it is in autorange the range will change.
4. Delay Data Hold DELAY HOLD
When is pressed for over a second, to toggle in and out of the Data Hold mode, and the “ ”
annunciator turns on or off.
5. Min/Max Recording Hold MIN / MAX
Press to enter the Min/Max Recording Hold mode. The minimum, maximum values are then reset to
the present input, the readings are stored in memory, and the “ ” annunciator turns on. Push the button to cycle
through the minimum ( MIN ), the maximum ( MAX ), and present readings. The “ MIN ” or “ MAX ” annunciator
turns on to indicate what value is being displayed.
In the Min/Max Recording Hold mode, press to stop the recording of readings, press again to
restart recording. If recording is stopped, the minimum, maximum, or present values and analog display are
frozen. In the Min/Max Recording Hold mode, when a new minimum value is exceed the actual minimum readings
or a new maximum value is overload, the minimum or maximum value will held on the display, but the analog
display continues to be active. In case of in the auto-range, the mode is held to just before range.
6. Relative Display REL
Press to enter the Relative Display mode, the “ REL ” annunciator turns on, zero the display, and
store the displayed reading as a reference value.
In the Relative Display mode mode, the value shown on the LCD is always the difference between the stored
reference value and the present reading. If the new reading is the same as the reference value, the display will be
zero.
The bargraph is displayed absolute value, not relative value. And the over-range also occur against the absolute
value.
In case of the autorange, the range is held just before range.
Press and hold down the for over one second, to exit the relative mode.
7. RANGE
Press to select the Manual Range mode and turn off the “ AUTO ” annunciator.
In the Manual Range mode, each time the is pressed, the range (and the input range annunciator)
increments, and a new value is displayed.
To exit The Manual Range mode and return to autoranging, press and hold down over one second. The “
AUTO ” annunciator turns back on.
The DC V, AC V, Resistance and Capacitance measurement are always first set to the auto range.
The frequency measurement is always set to the auto range.
The Continuity, Diode, ADP, DC A and AC A measurement are always fixed range.
When power is turned-on, the default range is selected.
8. Data Memory MEM STO
Press to enter the Data Memory mode and turn on the “ MEM ” annunciator, all of display data is
stored in the memory. The stored data can be read out and display on the LCD, then becomes the Data Recall
Hold mode.
