Digital Projection TITAN HD-600 Bedienungsanleitung

TITAN HD-600

High Brightness Digital Video Projector

16:9 widescreen display

User Manual

108-452A

Downloaded From projector-manual.com Digital Projection Manuals

Digital Projection TITAN HD-600 User Manual

Downloaded From projector-manual.com Digital Projection Manuals

Digital Projection TITAN HD-600 User Manual

Declaration of Conformity

Directives covered by this Declaration

89/336/EEC Electromagnetic Compatibility Directive, amended by 92/31/EEC and 93/68/EEC.

73/23/EEC Low Voltage Equipment Directive, amended by 93/68/EEC.

Products covered by this Declaration

Large screen video projector type The CE mark was ﬁrst applied in:

TITAN HD-600 October 2007

Basis on which Conformity is being declared

The products identiﬁed above comply with the protection requirements of the above EU directives, and the

manufacturer has applied the following standards.

EN 55022:1998 - Limits and Methods of Measurement of Radio Disturbance Characteristics of Information

Technology Equipment.

EN 55024:1998 - Limits and Methods of Measurement of Immunity Characteristics of Information Technology

Equipment.

EN 55103:1997 - Product family Standard for Audio, Video, Audio-Visual and Entertainment Lighting Control

apparatus for Professional Use.

EN 60950:2000 - Speciﬁcation for Safety of Information Technology Equipment, including Electrical Business

equipment.

The technical documentation required to demonstrate that the products meet the requirements of the Low Voltage

directive has been compiled by the signatory below and is available for inspection by the relevant enforcement

authorities.

Signed:

Authority: D.J. Quinn, Product Development Director

Date: 15 October 2007

Attention!

The attention of the speciﬁer, purchaser, installer, or user is drawn to special measures and limitations to use which

must be observed when these products are taken into service to maintain compliance with the above directives.

Details of these special measures are available on request, and are also contained in the product manuals.

Downloaded From projector-manual.com Digital Projection Manuals

Digital Projection TITAN HD-600 User Manual

Downloaded From projector-manual.com Digital Projection Manuals

Rev A. March 2008 Page v

Please read this user manual carefully before using the projector, and keep

the manual handy for future reference.

A serial number is located on the side of the projector. Record it here:

Symbols used in this guide

Warnings

ELECTRICAL WARNING: this symbol indicates that there is a danger of

electrical shock unless the instructions are closely followed.

WARNING: this symbol indicates that there is a danger of physical

injury to yourself and/or damage to the equipment unless the

instructions are closely followed.

NOTE: this symbol indicates that there is some important information that

you should read.

Trademarks

IBM is a registered trademark of International Business Machines Corporation.

Macintosh and PowerBook are registered trademarks of Apple Computer, Inc.

Other product and company names mentioned in this user’s manual may be the

trademarks of their respective holders.

Product revision

Because we at Digital Projection continually strive to improve our products, we

may change speciﬁcations and designs, and add new features without prior

notice. Projectors built prior to this revision of the User Manual may therefore not

include all the features described.

Manual revision

Date Description Revision

March 2008 Rev A

•

Important Information

Downloaded From projector-manual.com Digital Projection Manuals

Page vi Rev A. March 2008

Important Information Digital Projection TITAN HD-600 User Manual

General precautions

Do not open the cabinet. There are no user serviceable parts inside.

Use only the power cable provided.

Ensure that the power outlet includes a Ground connection, as this

equipment MUST be earthed.

Take care to prevent small objects such as paper or wire from falling

into the projector. If this does happen, switch off immediately, and have

the objects removed by authorised service personnel.

Do not expose the projector to rain or moisture, and do not place any

liquids on top of the projector.

Unplug before cleaning, and use a damp, not wet, cloth.

Do not touch the power plug with wet hands.

Do not touch the power plug during a thunder storm.

Handle the power cable carefully and avoid sharp bends. Do not use a

damaged power cable.

There are no user-serviceable parts inside the lamp module. The whole

module should be replaced.

Take care when removing the lamp module.

NEVER touch the lamp or reﬂector.

Take care not to touch the glass surface of the lamp module. If you

do accidentally touch the glass, it should be cleaned before use. (see

section 5. Maintenance.)

Do not use the lamp for more than 2000 hours, as this may cause

serious lamp failure, damage the lamp module and cause extra cost on

replacement.

HID lamps produce high intensity light. Do not look directly at the light

coming from the lamp housing, or the lens, or allow items such as

magnifying lenses to be placed in the light path. This could result in

serious eye damage.

Do not touch the ventilation outlets, as they will become hot in use.

Do not cover or obstruct the ventilation outlets or inlets.

Do not cover the lens whilst the projector is switched on. This could

cause a ﬁre

Always allow the projector to cool for 5 minutes before disconnecting

the power, moving the projector or changing the lamp.

Never use strong detergents or solvents such as alcohol or thinners to

clean the projector and lens.

Notes

Downloaded From projector-manual.com Digital Projection Manuals

Rev A. March 2008 Page vii

Digital Projection TITAN HD-600 User Manual Important Information

Installation precautions

Connect the LAN cable only to a computer LAN connection. Other

similar connectors may have a dangerously high voltage source.

The projector must be installed only by suitably qualiﬁed personnel, in

accordance with local building codes.

The projector should be installed as close to the power outlet as

possible.

The power connection should be easily accessible, so that it can be

disconnected in an emergency.

Ensure that there is at least 30cm (12in) of space between the

ventilation outlets and any wall, and 10cm (4in) on all other sides.

Do not install the projector close to anything that might be affected by

its operational heat, for instance, polystyrene ceiling tiles, curtains etc.

The projector weighs approximately 31 kg (68 lbs). Use safe handling

techniques when lifting the projector.

When stacking projectors, the stack MUST be vertical, to ensure that

the stresses are distributed to all frame couplings.

Before installation, make sure that the surface, ceiling or rigging that is

to support the projector is capable of supporting the combined weight

of the projector and lens (see speciﬁcation for exact weights).

Separate backup safety chains or wires should always be used for each

projector.

Do not place heavy objects on top of the projector chassis. Only the

chassis corners and the rigging frame are capable of withstanding the

weight of another projector.

Do not stack more than 3 projectors.

Do not drop or jarr the projector.

Place the projector in a dry area away from sources of dust, moisture,

steam, smoke, sunlight or heat.

Do not tilt the projector more than ±12° in either direction when in use,

as this may cause serious lamp failure, damage the lamp module and

cause extra cost on replacement.

Operation and conﬁguration precautions

Do not make changes to the networking conﬁguration unless you

understand what you are doing, or have taken advice from your

Network Manager. If you make a mistake, it is possible that you will lose

contact with the projector. Always double-check your settings before

pressing the APPLY button. Always keep a written note of the original

settings, and any changes you have made.

Software update should NOT be carried out except by, or with the

supervision of, Digital Projection Service personnel.

Notes

±12°

Downloaded From projector-manual.com Digital Projection Manuals

Page viii Rev A. March 2008

Important Information Digital Projection TITAN HD-600 User Manual

Compliance with international standards

Noise

GSGV Acoustic Noise Information Ordinance

The sound pressure level is less than 70 dB (A) according to ISO 3744 or ISO 7779.

RF Interference

FCC

The Federal Communications Commission does not allow any modiﬁcations or

changes to the unit EXCEPT those speciﬁed by Digital Projection in this manual.

Failure to comply with this government regulation could void your right to operate

this equipment.

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant with Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area may cause harmful interference, in

which case the user will be responsible for correcting any interference.

This equipment contains an FCC approved RF transmitter module with FCC ID:

R68WIPORT.

European Waste Electrical and Electronic Equipment

(WEEE) Directive

Digital Projection Ltd is fully committed to minimising Waste Electrical and

Electronic Equipment. Our products are designed with reuse, recycling

and recovery of all components in mind. To this end, at end of life, your

projector may be returned to Digital Projection Ltd or its agent so that the

environmental impact can be minimised.

Notes

Downloaded From projector-manual.com Digital Projection Manuals

Rev A. March 2008 Page ix

Digital Projection TITAN HD-600 User Manual Important Information

Digital Projection Contact details

Digital Projection Limited,

Greenside Way, Middleton, Manchester M24 1XX, UK.

Registered in England No. 2207264, Registered Ofﬁce: as above

Tel +44 (0) 161 947 3300

Fax +44 (0) 161 684 7674

Email [email protected], [email protected]

Web Site www.digitalprojection.co.uk

Digital Projection Inc.

55 Chastain Road, Suite 115, Kennesaw, GA 30144. USA

Tel (USA) 770 420 1350

Fax (USA) 770 420 1360

Email [email protected]

Web Site www.digitalprojection.com

Notes

Downloaded From projector-manual.com Digital Projection Manuals

Page x Rev A. March 2008

Important Information Digital Projection TITAN HD-600 User Manual

Downloaded From projector-manual.com Digital Projection Manuals

Andere Handbücher für TITAN HD-600

Inhaltsverzeichnis

Andere Digital Projection Projektor Handbücher

Digital Projection

Digital Projection TITAN WUXGA 3D Bedienungsanleitung

Digital Projection

Digital Projection M-Vision 1080p-260 series Bedienungsanleitung

Digital Projection

Digital Projection E-Vision Laser 8500 Series Betriebsanleitung

Digital Projection

Digital Projection TITAN sx+ Pro Series 3 Bedienungsanleitung

Digital Projection

Digital Projection TITAN 1080p-600 Bedienungsanleitung

Digital Projection

Digital Projection E-Vision Laser 5900 Series Betriebsanleitung

Digital Projection

Digital Projection E-Vision 7500 Series Bedienungsanleitung

Digital Projection

Digital Projection Titan 930 Bedienungsanleitung

Digital Projection

Digital Projection TITAN SX+ 500 Bedienungsanleitung

Digital Projection

Digital Projection TITAN LASER WUXGA Datenblatt

Digital Projection

Digital Projection E-Vision Laser 13000 WU Series Datenblatt

Digital Projection

Digital Projection TITAN WUXGA 3D Bedienungsanleitung

Digital Projection

Digital Projection HIGHlite 730 Series Bedienungsanleitung

Digital Projection

Digital Projection LIGHTNING 30-1080p Bedienungsanleitung

Digital Projection

Digital Projection HIGHlite Laser 3D Series Bedienungsanleitung

Digital Projection

Digital Projection M-Vision 1080p-260 series Bedienungsanleitung

Digital Projection

Digital Projection Titan series Montage- und Bedienungsanleitung

Digital Projection

Digital Projection M-Vision Laser 18K Series Bedienungsanleitung

Digital Projection

Digital Projection E-Vision WXGA 600 Bedienungsanleitung

Digital Projection

Digital Projection THUNDER 9000gv Bedienungsanleitung

Digital Projection

Digital Projection HIGHlite 740 Series Bedienungsanleitung

Digital Projection

Digital Projection INSIGHT 4K Dual LED Series Betriebsanleitung

Digital Projection

Digital Projection TITAN 1080p-600 Betriebsanleitung

Digital Projection

Digital Projection Titan 1080p-500 Bedienungsanleitung

Beliebte Projektor Handbücher anderer Marken

iEmmet

iEmmet MP-312 Bedienungsanleitung

Epson

Epson VS400 Bedienungsanleitung

Sony

Sony VPL-HS10 Marketing Specifications & Features Bedienungsanleitung

Sony

Sony VPL-HW65ES Service-Handbuch

Toshiba

Toshiba TLP-791U Bedienungsanleitung

Philips

Philips LC1341 Referenzhandbuch

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Bedienungsanleitung

NEC

NEC NP600S EDU Bedienungsanleitung

BenQ

BenQ SH753P Bedienungsanleitung

Eiki

Eiki EK-623U series Bedienungsanleitung

Epson

Epson PowerLite Pro Cinema 6020UB Bedienungsanleitung

Epson

Epson PowerLite Home Cinema 705HD Bedienungsanleitung

Christie

Christie LHD700 Bedienungsanleitung

Navitar

Navitar FX Bedienungsanleitung

InFocus

InFocus LitePro 560 Bedienungsanleitung

Sony

Sony SRX-R815P Bedienungsanleitung

Vivitar

Vivitar DP1500 X Bedienungsanleitung

Acer

Acer C20 Series Bedienungsanleitung
