Digital Spectrum Solutions MemoryFrame MF-8000 Bedienungsanleitung

Model MF-8000, MF-8104, MF-8115

Premium Edition

User Manual

Version 2.3.0.0

Product Introduction

Congratulations! You are the proud owner of a MemoryFrameTM Wireless Digital Picture Frame. Boasting high-quality image resolution the MemoryFrameTM is the perfect product for

displaying your favorite digital images, video files, or listening to your favorite MP3’s. The MemoryFrameTM includes a patented changeable frame capture system. This allows you to use a

standard 8x10 and 15” frame so your MemoryFrameTM never goes out of style. You can decorate as your lifestyle and tastes change, whether in the home or office. The MemoryFrameTM

displays images in a slide show format, which may also be accompanied by background music. Embedded 802.11 b/g wireless functionality allows the MemoryFrameTM to seamlessly become

part of your home network. This allows the transferring of images, clips, and tracks; no wires, no hassle. The Premium edition of MemoryFrameTM is also web enabled so that you can play or

download images from popular photo sharing sites. MemoryFrameTM Premium also works with Windows Vista or Windows XP equipped with Media Player 11 as a sharing device. This way

Vista or XP can be your own home sharing site.

Features

9Display digital images and videos with or without a computer

9Listen to MP3 audio while displaying images

9Built-in stereo speakers with volume control and Mute

9Built-in 802.11 b/g wireless

9Bluetooth Capable (Requires Bluetooth USB Dongle – Not Included)

9The frame is changeable with standard 8x10 and 15” frames. Your choice is unlimited!∗

9Generous internal memory

9Web enabled for photo sharing

9Support for – CF/SD/XD/MMC memory cards

9Works with Windows Vista®and Windows XP equipped with WMP 11

9TFT-LCD with high resolution, wide view angle and rich color

9Easy to use remote control for displaying and managing your content

9Desktop/Wall Mount

9Landscape/Portrait

Package Contents

MemoryFrameTM comes packaged with the following items:

A. MemoryFrameTM unit

B. Removable Desktop Stand

C. A.C. Power Adapter

D. Remote Control

E. USB Cable

F. User Manual

G. xD Card reader

Setting up the MemoryFrameTM

A. Open the package and remove the protective foam. Remove the protective sleeve from the unit.

B. Install the removable Desktop Stand. There are 3 positions, Landscape, Portrait, and Insert/Remove.

C. Plug in the AC adapter into the power outlet. Plug the other end into the unit.

D. Turn power to the On position via the Power switch. The Power switch is on the right side of the MemoryFrameTM, in the rear.

E. During Power Up the display will present an opening screen with progress bar. When complete it will play the default slide show.

F. If the content is stored on a target flash media card, insert the media into the proper slot.

Connectivity – USB and Media Cards

MemoryFrameTM is equipped with both USB port types for complete USB connectivity. One USB port is used to connect to the PC. In this manner content can be sent to the

frame from the PC. In Explorer, the frame will be identified as an external storage device. The other USB port is for connecting devices such as cameras and thumb drives. A CF

slot is provided for CF cards and CF adapters. A MMC/SD slot is provided for MMC/SD. An external USB card reader is included to support XD media.

Remote Control

Function Description

Power On/Off

Mute Audio On/Off

Vol+ Increase Volume

Vol- Decrease Volume

Back Go back one screen

Play Play content

Clock Display Clock

Menu Go to Menu

Enter Enter/Select

◄Left

►Right

▲Up

▼Down

∗U.S. Patent 6,826,863 B1

Replacing Remote Control Battery

On Screen Menu Controls

This feature is included so that content can be managed and controlled. The menu system is activated by pressing the Menu button. The Main Menu is shown below.

Main Menu

The Main Menu is the starting point to navigate to the desired function.

Function Description Sample Screen


User can play a picture slideshow. User

can specify the source location for picture

files and can select specific pictures to

play. User can copy pictures to internal

memory and delete pictures from internal

memory.

Video

User can play Windows Media Video

(WMV) files*. User can specify the source

location for video and can select specific

videos to play. User can copy videos to

internal memory and delete videos from

internal memory.

Music

User can play music. User can specify the

source location for music files and can

select specific songs to play. User can

copy music files to internal memory and

delete music from internal memory.

Resume

Slideshow User can resume a slideshow for playback.

Theme Change the background color.

Settings

Change MemoryFrameTM settings

wireless

network

Search for available wireless networks

in the area

Stop

music

Stops music playback. If music is

playing selecting “Stop music” will

end the music.

*A WMV Converter utility is included with the MemoryFrameTM CD to allow users to convert different video formats into WMV.

Pictures

Function Description Sample Screen

Play

slideshow

Play picture slideshow and specify

source location. Playback functions

support Play All, Choose Individual,

or Pictures by date.

Copy

picture(s) Copy pictures from a specified

source location into internal memory

Delete

picture(s) Delete pictures from internal

memory

picture(s)

Share pictures from device to

another MemoryFrameTM Premium

Edition.

Play Slideshow

When Play Slideshow is selected, the user can specify the location of the picture files.

Note – The entire list of media sources may not be displayed. MemoryFrameTM will only display the removable media types which are inserted and have media files.

Picture Selection

When a source location is selected, the user can specify playing all the pictures found or individual photo selections.

Function Description Sample Screen

Play all

picture(s) Play all the pictures found in the

source location

Choose

individual

picture(s)

Select specific pictures for

playback, once selection is

complete, press ‘Play’ button in

remote control

Choose by

Date Play slideshow by date stamp of


Choose Individual Picture(s)

Press the arrow keys to navigate to the desired pictures. Press ENTER to select a picture. Press ENTER again to unselect a picture. Once all the selections have been made, press

‘Play’ in remote control or navigate to Play option and press ENTER.

Video

MemoryFrameTM can play properly formatted WMV video files. A WMV converter utility is provided on the software CD to ensure a consistent video experience, and to allow

compatibility with a variety of popular video formats. From the Main Menu, navigate to Video and press ENTER.

The Video Menu features the option to play a specific video file as well as the ability to copy video files into MemoryFrame’sTM internal memory or delete video files from internal

memory. The procedures to play, copy, or delete video files are the same as the corresponding procedures to play, copy, or delete picture files.

Note: Video playback over a network is not currently supported. Video files must originate from internal memory or removable media inserted into MemoryFrameTM.

Music

MemoryFrameTM can play MP3 and WMA music files. From the Main Menu, navigate to Music and press ENTER.

The Music Menu features the option to create a song list, as well as the ability to copy music files into MemoryFrame’sTM internal memory or delete music files from internal

memory.

Press ‘Select new song list’ to select songs that will be added to the song list.

The procedures to play, copy, or delete music files are the same as the corresponding procedures to play, copy, or delete picture files.

Playing Background Music during Picture Slide Show

While a song list is being played, the user can resume the previous picture slideshow by pressing the PLAY button on the remote control. Volume can be adjusted using the Vol+

and Vol- buttons on the remote control. During slideshow playback, volume can also be adjusted by pressing the up and down arrow buttons on the MemoryFrameTM. To stop

music press Menu, then select Stop Music.

Settings

This function is used to personalize the frame operation and configuration. This includes slideshow, photo sharing, set clock, sleep settings, language, orientation, network

information, and automatic updates.

From the Main Menu, navigate to Settings and press ENTER.

Function Description Sample Screen

Resume slideshow Exits the Settings menu and resumes playback of

previous picture slideshow

Frame orientation Toggles between landscape (horizontal) and portrait

(vertical) display settings

Slideshow Settings Sets slideshow preferences, including slide duration,

transition type, picture order, and music options

Slide Duration This is used to set the slideshow timing. The setting

are 5, 10, 15, 30 seconds, and 1, 5, 30 minutes, and 1

hour.

Slide Transition

This lets you select the transition style between

images in a slideshow. There are 12 settings. One of

them is Random, which randomizes transitions

during a slideshow.

Picture Order This lets you select the ordering of images during a

slideshow. The selections are sequential or random.

Music Option This lets you select the way music is played. This

includes Music order and loop control.

Auto Slideshow Update This lets the frame automatically update a slideshow

when new images are added to a photo sharing

account.

Show Online Status

This is a small antenna icon in the lower right of the

screen that shows whether the network is connected

or not. When set to No, the antenna icon is not

shown.

Play received Pictures

only

This lets you play all pictures from a photo sharing

site, or just newly added images. If set to No, all

pictures will be played.

Prompt me for new

Pictures

This lets you approve each picture that is in your

photo sharing account and prompts you when a new

image has arrived. When set to No new pictures will

automatically be added to the slideshow.

Video Repeat This lets you set the loop control for video playback.

When set to No, video will be played once. When set

to Yes, the video will loop.

Set time Sets the date and time.

Set time zone

Specify the local time zone

Language Specify the language.

Configure Photo Sharing Enter User Account information for photo sharing

site. User may enter more than 1 account. User may

also input RSS Feeds by inserting RSS URL.

Network Info

Displays network status and configuration

information

Check Updates Checks if a software update is available. This feature

requires an Internet connection.

FrameID, Frame Email, Software version #,

Firmware version #.

To register your frames go to

http://www.MemoryFrame.com and sign up for a

free account. This allows pushing albums/pictures to

the frame from MemoryFrame.com photo sharing

site.
