1. Introduction
Dear User,
This manual contains instructions on how to install and operate the suspended scale model ULD,
designed with technology and quality standards set by Digi-Tron, a company specialized in
precision instruments.
Its proper functioning, however, depends also on the treatment and care given by the user, as much
in the installation as in its daily use. It is, therefore, necessary to carefully read all the instructions
contained in this manual, as well as abide by them.
Only technicians certified by IPEM (Instituto de Pesos e Medidas/ Weights and Measures Institute)
are allowed to open the instrument’s seal. The breaking of the seal by persons not certified by
IPEM will result in the automatic annulment of the Digi-Tron guarantee and violates federal laws.
We recommend that any technical problem be directed to Digi-Tron´s Technical Assistance
Department so that we may direct you to an authorized technician.
2. Installation
Your product is a mass weighing instrument and you should take certain cautions during its use.
Before putting your scale to use, it is important to observe the following items:
-Verify that the instrument has not suffered any damage during delivery.
-Check accessories
-Take off protective insulation. (Instruments with dimensions up to 700x700mm)
-Fasten the articulated feet that are in the indicator’s packaging. (Scales 800x800mm
and up, follow the following instructions)
-Adjust the level and then lock the articulated feet using the nuts and bolts if the case
may be.
-The scale cannot undergo any kind of impact or overweighing on the weighing
platform so that there is no damage to the load receptor. Always place cargo as close
to the center of the scale as possible so that there is no lateral force on the load
receptors and so that you get the best weight distribution over the entire scale.
-Do not use the keypad with sharp objects in order to avoid damages to the keypad’s
circuits.
-The cleaning and keeping of the entire scale will also avoid unnecessary
maintenance. When possible, clean the scale with a damp cloth.
-Always clean the scale with the power cord unplugged.
-Always make sure that the scale’s cables and connectors are in perfect condition for
they are essential for proper function.
Maximum performance of your instrument depends on proper installation.
2.1 Accessories provided together with the scale:
- 01 Battery charger 12V 110/220V;
- 01 Remote Control to Tare Key (instruments up to 1000Kg);
- 02 Batteries 12V/12Ah (instruments up to 1000Kg);
- 02 Batteries 12V/7Ah (instruments until 500Kg).
