DIGM Technology GSM-0308WPC Bedienungsanleitung

GSM WATER PUMP CONTROLLER AND

MONITORING SYSTEM

Model: GSM-0308WPC

GSM-0308WPC User Manual



2|Page

TableofContents

Application………..……………………………………………...…………………………………………3

Instructions…………….……………………………………………………………………………………4

InstallationDiagram….……………………………………………………………………..………….5

DeviceDesign…………..………………………………………………………….………………………5

TechnicalParameter..…………………………………………………………………………………..6

SetupInstruction………………………………………………………………………………………….6

1Administrator

1.1TemporaryAdministratorPrivilege……………………………………………………………………………………….6

1.2ChangingaPassword…………………………………………………………………………………………………………….6

1.3AddanAdministratorNumber……………………………………………………………………………………..……….7

1.4EnquirytoAdministratorNumbersinthelist………………………………………………………………………..7

1.5DeleteAdministratorNumberinthelist……………………………………………………………………………….8

1.6EnquirySignalStrength………………………………………………………………………………………………………...8

1.7TimeScheduletosendSMSRemindertotheAdministrator……………………………………………..….8



2SystemAlarmAlertProgramming

2.1CallAlertForTriggerTypeAlarm.………..……………………………………………………………….……………….9



3. PumpActivation.………..……………………………………………………………………………………….……………….9



GSM-0308WPC User Manual



3|Page

Applications:

Thisproductissuitableforwaterpumpcontrol,reservoircontrol,aquariumetc.CanuseSMSto

remotelyEnquiryfor,TextContentforAlarmAlert/CallAlarmAlert.



GSM-0308WPC User Manual



4|Page

Instructions:

Afterconnecttotheunit,connecttheinputtoyourtriggerunitondrycontactattheobject

youneedtomonitor.OncethedevicetriggerwillSMS/phonecalltoinformyou.Maximum

5groupadministratorcanbesetuptoreceivealarmalerts.



4simplestepstousethedevice:

1. InserttheSIMcard

2. Pluginthepowercableintothepowersupplysocket

3. SwitchontheOn/Offswitch

4. Afterthedevicestarts,makeacalltothedevice(calltheSIMcardphonenumber)

Note:Whenheara"~di"sound,youcandeterminetheequipmenthasbeenstart

successfully.

Whenitreplyasfollows,itisreadytouse.



GSM-0308WPC User Manual



5|Page

InstallationDiagram



DeviceDesign



GSM-0308WPC User Manual



6|Page

TechnicalParameter

• PowerSupply:SinglePhase220V‐240V50/60Hz

• GSMFrequency:GSM900/1800Mhz(OptionalGSM850/900/1800/1900Mhz)

• DevicePower:<2W

• BackupBattery:7.4V/600mAHLithiumPolymerBattery

• MaximumLoadForControl:NO:10A/277VAC,NC:12A/125VAC

• RemoteMonitoringDistance:GSMnetworkcoveragearea

• PhysicalCasingDimension:180mmx140mmx60mm

• EnclosureIPRating:IP65



SetupviaSMSCommand

1.Administrator

1.1TemporaryAdministratorPrivilege:

*100*AAAAAA#

SettingupaTemporaryAdministratorPrivilegeforProgrammingMode:

AAAAAA=6DigitsPassword

DefaultPassword=123456

Byusingthiscommando,youwillobtainadministratorprivilegefor10Minutes.

Thatmeansyoucandoallprogrammingwithinthose10Minutes.

Ifyouaddyourtel.no.intheadministratorlist,youdonotneedthisfunctionanymore.

Ifanotherusessamecommandowithinthe10Minutes,thenyouwillloseyourAdministrator

privilege.

Alltel.no.ontheAdministratorlisthavefullcontrolovertheunitatalltime.



1.2ChangingaPassword:

*100*AAAAAA*BBBBBB#

Changethepassword.

AAAAAA=6CharacterOldPassword

BBBBBB=6CharacterNewPassword.

Atthesametime,itwillgettheAdministratorPrivilege.

Example:Send*100*123456*obs123#,thesystemwillchangetheadmintoobs123



GSM-0308WPC User Manual



7|Page

1.3AddanAdministratorNumber

*101*A*BBBBBB#

AddadministratorstotheAdministratorList

A=Administratorno‐(1–5)

BBBBBBBB=Tel.no.ofnewadministrator.

YoucanaddaMinimumof3digitsandamaximumof20digits.

Example:Send*101*5*13812512456#,Systemwillset13812512456asAdmin5

Send*101*3*123456#,Systemwillset123456asAdmin3



1.4EnquirytotheAdministratorNumbersinthelist

*102#

Checkadministratorlist

Itwillreplywithafulllistofalladministratorsonthelist.



GSM-0308WPC User Manual



8|Page

1.5DeleteAdministratorNumberinthelist:

*103*A#

Deletingadministratortel.no.onthelist

A=administratorno.(1–5)

Example:Send*103*5#,thesystemwilldeletetheAdmin5



1.6EnquirySignalStrength:

*104#

ChecksignalstrengthontheGSMconnection

EnquiryforSignalStrength

CSQ=0–10(WeakSignal)

CSQ=11‐20(AverageSignal)

CSQ=21–30(GoodSignal)

CSQ=Above30(ExcellentSignal)



1.7TimeScheduletosendSMSRemindertotheAdministrator

*109*XXX#

SMScheckmessagetosaytheunitisstillupandrunning.

XXX=Days(Value=000‐255,mustbein3digits,everyweek=007)

Defaultas000(NotSendingSMSreminder)

DefaultTextreadsas“Hi!I'mOK”(Caneditthetextusing*111*Command)

Example:(send)*109*002#thesystemwillstarttocalculatefromthemomentitreceives

theSMS.After2days,itwillsendoutaSMSreminder.

Note:Ifthesystemhadbeenrestarted,itwillclearthetimetoZEROandrecalculateagainfor

2daysfromthemomentthesystemrestarted,thensendouttheSMSreminderafter2days.



GSM-0308WPC User Manual



9|Page

2. SystemAlarmAlertProgramming

2.1CallAlertforTriggerTypeAlarm:

*302*A*B#

B=0or1(0=OFF,1=ON)defaultaswhenalarm,willnotmessagebeforephonecall

alert

A=TriggerTypesasperbelow;

(1):SystemRestart

(2):PowerOutage

(3):PowerRecover

(7):LineCut

(8):LineCutRecover

Note:youcanchooseasmanyofthemyouwantwhichmeansyoucansimplechoose

toon/offthecallfunctionofthe5TypesofAlarmAlert



3. PumpActivation

Commandusetoprogramunitathilltopfromthemainunitinordertoactivatepump

*1000*A#A=0or1(0=OFF,1=ON)



Formoreadditionalcommand,pleasereferto“AdditionalCommandListForGSM‐0308Series”


