Dimplex Duoheat Bedienungsanleitung



ContactDetails



Pleasenotethatsomeofthecontactdetailson

thisPDFdocumentmaynotbecurrent.



Pleaseusethefollowingdetailsifyouneedto

contactus:



Telephone:08448793588

Email:[email protected]



Thecustomersupportsectionofourwebsitealsofeaturesawide

rangeofinformationwhichmaybeofusetoyouandisavailable

24hoursaday.Itincludes:



•Operatingandinstallationinstructions

•Easy‘Howtouse’guidesforstorageheaters

•Serviceandrepairs

•Wheretobuyourproducts

•Literaturedownloads

•Heatingrequirementcalculator



Visit‐www.dimplex.co.uk/support

A division of GDC Group Ltd

Millbrook House Grange Drive Hedge End Southampton SO30 2DF

www.dimplex.co.uk

istered No: 1313016 En

land

VAT GB 287 1315 50004

EEE Producer Registration Number –

WEE/GE0057TS

Paper from sustainable sources

Quick Start Guide

Duoheat Radiator with RX010006 Programmer QS007

This guide is for quick reference only. Refer to the Duoheat and Programmer installation and operating instructions for further information

Duoheat Radiator Overview

Dimplex UK Ltd, Millbrook House, Hedge End, Southampton, SO30 2DF. For further assistance please contact Dimplex customer services on 0845 600 5111. Web-site: www.dimplex.co.uk

Room temperature control

Your DuoHeat radiator works by providing continual warmth from a

carefully balanced combination of retained and ‘direct response’

heating.

Some energy is taken in by the radiator when electricity tariffs are

low. The radiator will automatically determine how much heat

needs to be stored each night depending on changing weather

conditions.

The stored heat is supplemented whenever needed by top up heat

from the radiant front panel, to ensure room temperatures remain

to your preferred level throughout the day.

• Controls the amount of heat emitted from the radiator.

• When only background heating is required (e.g. the room is

unoccupied) set the control to minimum (1 bar).

• When more heat is required (e.g. when the room is occupied)

set the control to your preferred comfort setting

• To set the room temperature level required, press the ‘+’ or ‘-‘

buttons.

• The display will indicate the level you have selected.

• After the control has been adjusted, the brightness of the dis-

play will revert to a background level after a few seconds of

inactivity.

Child lock

• To activate the child lock,

press the ‘+’ and ‘-‘ buttons

together for approximately 3

seconds.

• A light in front of the key symbol on the display will illuminate,

indicating that the control is locked and cannot be adjusted.

• To deactivate the child lock, press the buttons simultaneously

again for 3 seconds, until the light in front of the key symbol is

no longer illuminated.

Pilot wire central programmer RX010006

The RX010006 central control can be used to

control the operation of multiple DuoHeat

radiators remotely.

Depending on the controller setting, DuoHeat

radiators will respond in the following way:

Min Max

Comfort Heater functions at the selected output set by the heater room temperature

control

Setback (background) Heater functions with room temperature control automatically set to

minimum output setting.

(NB room temperature control cannot be adjusted)

Frost protection No subsequent input charge is accepted. Front panel will maintain frost

protection temperature

Off Heater does not function – off peak and 24hr supplies both

disconnected
