Dimplex Winterwarm WWFH20E Bedienungsanleitung

08/54001/0 ISSUE: 2

Base Unit Heater

Model: WWFH20E

INSTRUCTION MANUAL

Installation and Operating

This product is supplied and operated with a Bluetooth Remote Control handset

IMPORTANT

THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR

FUTURE REFERENCE. Note also the information presented on the appliance

DO NOT COVER OR OBSTRUCT the air inlet or outlet grille.

The heater carries the Warning symbol indicating that it must not be covered.

A ‘Do Not Cover’ warning alerts the user to the risk of re that exists if the

heater is accidentally covered.

DO NOT use this heater in the immediate surroundings of a bath, shower or

swimming pool.

DO NOT place heater immediately below a socket outlet.

WARNING: The supply circuit to the heater must incorporate a double pole

isolating switch having a contact separation of at least 3mm in all poles.

This appliance can be used by children aged from 8 years and above and persons

with reduced physical, sensory or mental capabilities or lack of experience or

knowledge if they have been given supervision or instruction concerning the use

of the appliance in a safe way and understand the hazards involved. Children shall

not play with the appliance. Cleaning and user maintenance shall not be made by

children without supervision.

Children of less than 3 years should be kept away unless continuously supervised.

Children aged from 3 years and less than 8 years shall only switch on/o the

appliance provided that it has been placed or installed in its intended normal

operating position and they have been given supervision or instruction concerning

the use of the appliance in a safe way and understand the hazards involved. Children

aged from 3 years and less than 8 years shall not plug in, regulate and clean the

appliance or perform user maintenance.

DO NOT use this heater in areas where excessive dust exists.

CAUTION - Some parts of this product can become very hot and cause burns.

Particular attention has to be given where children and vulnerable people are

present.

Momentary contact with any part of the heater should not cause injury. However

aged, inrm persons or young children should not be left unsupervised in the

vicinity of the heater.

CAUTION - In order to avoid a hazard due to inadvertent resetting of the thermal

cut-out, this appliance must not be supplied through an external switching device,

such as a timer, or connected to a circuit that is regularly switched on and o by

the utility.

CAUTION: FAILURE TO FOLLOW THESE ISTRUCTIONS MAY CAUSE INJURY

AND/OR DAMAGE AND MAY INVALIDATE YOUR GUARANTEE

When connecting this recessed appliance it is necessary that the xed wiring

electrical supply is routed through an accesible switch in accordance with the

latest IEE wiring regulations.

If the supply cord is damaged it must be replaced by the manufacturer or service

agent or a similarly qualied person in order to avoid a hazard.

WARNING: KEEP BATTERIES OUT OF REACH OF CHILDREN

• Swallowing may lead to serious injury in as little as 2 hours or death, due to

chemical burns and potential perforation of the oesophagus.

• If you suspect your child has swallowed or inserted a battery go straight to a

hospital emergency room.

• Examine devices and make sure the battery compartment is correctly

secured, i.e. that the battery cover is tted securely. Do not use if the

compartment is not secure.

• Dispose of used batteries immediately and safely. Flat batteries can still be

dangerous.

Model Identiﬁer(s): WWFH20E

Nominal heat output Pnom 2.0kW

Front Cover Chassis

Height (mm) 100 88

Width (mm) 400 368

Depth (mm) - 203

Minimum heat

output (indicative) Pmin 1.0kW

Maximum continuous heat output Pmax,c 2.0kW

Auxiliary electricity Consumption

At nominal heat output elmax 0.00

At minimum heat output elmin 0.00

In standby mode elSB <0.0005

Type of heat output/ room temperature control

Electronic room temperature control plus week timer Yes

With open window detection No

With adaptive start control Yes

This product complies with Lot20 of the Energy Eciency Directive (2015/1188).

Energy Related Product Directive

Technical Details

All Models

Controls

Digitally controlled, Electronic Thermostat

Timer modes:

7 Day Programmable User Timer

Continuous heat modes:

Frost Protest, Runback, Comfort O

Controller UI

Button to initiate pairing with Bluetooth remote

Controller Functions

• Adaptive-Start

• Advance time period

• Adjustable SP range (7-30°C)

• Bluetooth for control

Construction Durable epoxy-polyester powder coated grille with moulded body

Element Modulating heat output via 2 stage stitched element with integral

thermal cut-out

Installation Screwed location to the plinth, Adjustable foot support at the rear

Safety Electrical reset, self-hold cut-out

IP Rating No Rating

Battery Backup

None. However all programmed timer proles will be retained during

short term power losses. In order to ensure their correct operation, it is

necessary to restore the time and date settings,this happens automatically

once paired with the remote.

Supply

~230-240 V, 50Hz Class II

Colour / Finish

Trac White (RAL 9016)

Approvals CE

Warranty 1 Year

Country of Origin British Isles

Manufacturer Glen Dimplex Heating & Ventilation (GDC Group Ltd.)

General

This heater has been designed for tting in the space behind the plinth of oor standing

kitchen units or other tted furniture units. It is recommended that the heater is not

installed under cupboards used for storing perishable goods. It can be accommodated

in plinths with a minimum height of 120mm, and is suitable for cupboards of 500mm

width and above.

Installation

Before undertaking installation work, ensure the electricity supply is disconnected

from any relevant xed wiring.

The heater is more easily tted during the installation of new furniture units, or on

existing furniture units if they can be temporarily moved from their position against

the wall. If an existing furniture unit cannot be moved, then it may be necessary to

remove the back of the unit in order to gain access to carry out the wiring installation.

Before installing the unit consider the location with respect to the following;

• The electrical supply and cable length.

• Position heater to deliver heat eectively without causing personal discomfort

from overheating while standing at work surfaces etc.

• Minimum plinth height of 120mm and minimum furniture unit width of 500mm.

WARNING: The installation of this appliance should be carried out by a competent

electrician and be in accordance with the current IEE wiring regulations

and any local or insurance regulations.

500 Min

203

Side View

500 Min

368

88 120

Min

14 Min

500 Min

400

100

1. Cutting the aperture in the Plinth

Cut aperture in furniture unit plinth to dimensions shown. This must be positioned so

that the minimum distance from the bottom of the aperture to the TOP surface of any

oor covering is not less than 14mm.

If an overhang above the heater is greater than 75mm, then a distance of at least

100mm must be maintained between the overhang and the uppermost part of the

heater

NOTE:

If tted in corner with adjacent cupboards to left hand side of heater

then a distance of at least 150mm must be maintained between the left

hand end of the heater and the front of the adjacent cupboard door

*This dimension must be maintained above the top surface of any oor covering

material. All dimensions in millimetres

2. Power Supply Connection

Check that the supply voltage details on the heater are in accordance with your

electricity supply. The appliance is tted with 1.4 metres of exible cable type

H05VV-F size 2 x 1.0mm for electrical connection. The cable may be used to connect

the heater to the xed wiring of the premises through a suitable connection box. The

supply circuit to the heater must incorporate a double pole isolating switch having a

contact separation of at least 3mm. The power supply cable should be routed from

the furniture unit to the connection box, ensuring that the cable is left with enough

slack to allow removal of the appliance for maintenance. The cable must be protected

from any sharp edges. The isolating switch must be accessible after installation of the

unit and the furniture.

3. Fitting the Rear Support Bracket

The heater is supplied with a rear support bracket. Fit to the back of the appliance

with the two screws supplied. Adjust the rear support bracket so that unit is level. The

slots in the rear support bracket allow it to be adjusted to the required height.

4. Marking the Fixing Positions

Slide the heater into position in the plinth aperture. Mark the six xing holes, two on

each side and two on the top. Remove the heater and drill 2mm pilot holes.

5. Mounting the Heater into the Plinth

When the cable connection has been made and the rear support bracket adjusted,

slide the heater into the aperture ensuring that it is adequately supported and that

the inlet grille is not obstructed. Use the six screws provided to secure the heater to

the plinth.

The product is supplied with a Bluetooth remote control, the remote control should be

contained in the carrier bag along with these instructions. This remote control is required

to operate the appliance. When paired with the remote control various operational modes

and features can be accessed.

IMPORTANT NOTE:

The remote control is required to operate the appliance. It is important

that the remote control remains near the appliance at all times.

Remote Control

1Display Screen

2‘Menu’ Button

3‘Back’ Button

4‘Advance’ Button

5‘Up and Down’ Arrows

6‘Enter’ Button
