Diono SantaFe Bedienungsanleitung

Instruction Manual

US English Version

Scan QR code inside for installation assistance.

Product: SantaFe child booster seat

Model: 15500

Mfg. by: Diono LLC

3104 142nd Ave E

Sumner, WA 98390

CUSTOMER SERVICE

Tel: 888-336-7909

Email: us-sales@diono.com

diono.com

Contents

Page

4Warnings

7Safety Information

USING THE BOOSTER SEAT

10 LATCH Installation

11 Seat Belt Buckle Position

12 Securing the Child

13 CARE AND MAINTENANCE

14 WARRANTY INFORMATION

Failure to follow all written instructions and product labels can

result in death or serious injury in a crash. Carefully read and

understand this instruction manual prior to using this

restraint. If you have any questions visit diono.com or contact

Diono LLC. To insure proper long-term use, store this manual

under the bottom of the base.

•Use only with children whose height is between 38” and 63”

and whose weight is between 30 lbs and 120 lbs.

•Only use this restraint forward-facing.

•Use only the vehicle’s lap and shoulder belt

system when restraining the child in this

booster seat.

•NEVER use with only a vehicle lap belt to

restrain a child. This could result in serious

injury or death to a child.

•Some vehicle seat belt systems cannot be used with this

booster seat. Read vehicle owner’s manual and ‘Vehicle Seat

Belt Systems’ section of this manual.

•DO NOT use this booster seat without the backrest unless

there is vehicle headrest for that seating position.

•DO NOT use this booster seat without the backrest unless

proper vehicle seat belt placement can be achieved.

WARNING !

Death or SERIOUS INJURY can occur.

•DO NOT use this booster seat with any other backrest or

cushions.

•To prevent injury due to product deterioration, do not use this

booster seat if it has been involved in a severe accident or if it

is older than six years.

•Never leave a child alone in a vehicle, even for a short time.

•Always secure this booster seat using vehicle seat belt or

LATCH anchors even when not occupied. In a crash, an

unsecured item may cause injury to other vehicle occupants.

•Except as described in this manual, do not dissemble or

modify any part of this booster seat or vehicle seat belt.

•Register your child restraint with the manufacturer.

•Do not place anything under the booster seat to raise it o the

vehicle seat.

•This restraint is not a toy. Do not let a child play with it.

•Do not leave folding vehicle seats unlatched. In the event of a

sudden stop, a loose seat back could prevent the booster seat

from protecting the child as well as it should.

•In the event of an accident, the vehicle body itself provides the

most signicant passenger protection. While a properly

installed restraint will improve chances for survival in most

accidents, a booster seat will not protect a child if the vehicle

is too severely impacted.

•Follow all instructions on this child restraint and in the written

instructions. To insure proper long term use, store this manual

under the bottom of the base.

WARNING !

Death or SERIOUS INJURY can occur.

•According to accident statistics, the National Highway

Transportation Safety Administration (NHTSA) recommends

that parents select the rear seat as the safest location to

properly install a booster seat. Please read carefully the

section concerning vehicle seat belts in this guide to insure

the child’s safety. If in doubt about installing this booster seat,

please consult the vehicle owner’s manual.

WARNING: DO NOT place a child

restraint in the front seat of a vehicle

with a passenger air bag unless the

air bag is turned o. DEATH or

SERIOUS INJURY can occur. The

back seat is the safest place for

children under 12.

IMPORTANT: Children who weigh 40 lbs (18kg) or less are best

protected in a 5-point harness restraint. Sunshine Kids Juvenile

products® recommends that children remain in a 5-point

harness restraint until reaching the maximum weight or height

allowed.

• If the child will not keep the vehicle shoulder belt properly

positioned at all times, DO NOT use a booster seat. You must

use a harnessed child restraint.

•Maximum Child Height: Child is too tall if the top of the ears

are above the top of either the fully raised booster seat

headrest or fully raised vehicle headrest.

WARNING !

Death or SERIOUS INJURY can occur.

GENERAL

• Cover this booster seat if vehicle is left in direct sunlight.

Portions of the booster seat can become hot enough to burn a

child and cover fabric can become faded.

• Store this booster seat in a safe place when not in use. Do not

store near direct heat source or place heavy objects on top of it.

• Always make sure vehicle seat is locked in its upright position.

Reclining the vehicle seat will adversely aect the safety and

performance of the child seat in an accident.

CERTIFICATION

This child restraint system conforms to all applicable Federal

Motor Vehicle Safety Standards. This restraint is not certied

for use in aircraft. Lap belts in aircraft cannot be used safely

with this booster seat.

REGISTRATION

Visit www.diono.com to register your restraint online. Child

restraints can be recalled for safety reasons. You must register

this restraint to be reached in a recall. Send your name, address

and this restraint’s model and serial number and manufacturing

date to Diono LLC, 3104 142nd Ave. S., Suite 105, Sumner, WA

98390, or call 1-888-336-7909. For recall information call the

U.S. Government’s Vehicle Auto Safety Hotline at 1-888-327-

4236 (TTY 1-800-424-9153) or go to www.nhtsa.gov.

Safety Information

VEHICLE SEAT BELT SYSTEMS

IMPORTANT: Some vehicles have no seating positions

compatible with booster seats. If in doubt, please contact the

vehicle manufacturer for assistance.

In order to protect a child in an accident, this booster must be

used with a compatible vehicle seat belt.

The following seat belt types are NOT compatible with this

booster seat:

• Two-point seatbelts of any kind.

• Three-point seat belts with separate retractors for lap and

shoulder sections.

• Motor-driven, automatic seat belts.

• Seat belts with anchorage points on the door.

WARNING: ONLY use this booster seat with a 3-point

(lap-and-shoulder) vehicle seat belt that is NOT

motorized or anchored to the vehicle door.

The vehicle owner’s manual will have complete information on

the types of seat belts in the vehicle. If the seat belt type is listed

above, choose another seating position in the vehicle.

Safety Information (continued)

VEHICLE SEATING POSITIONS

Sunshine Kids Juvenile Products® and the U.S. Department of

Transportation warn that children under 12 must ride in the rear

seats and away from front airbags. The only exception is if the

airbag is turned o. When using a vehicle with airbags, refer to

the vehicle owner’s manual for additional booster seat installa-

tion instructions and precautions.

WARNING: Only use this booster seat in forward-

facing vehicle seats. DO NOT use this booster seat in

side-facing or rear-facing seats in vans or station

wagons.

CUP HOLDERS

Cup holders are located on both sides

of seat bottom: swivel outward to the

locked position for use. Swivel inward

to the recessed and locked position

when not in use.

IMPORTANT: Do not step on or put

excess weight on cup holder which could cause it to break.

CAUTION: DO NOT use with hot liquids as this could burn a child.

Seats which face

sides of vehicle. Seats which face rear of vehicle.

LATCH Installation

WARNING: Unsecured objects can become ying

hazards and can cause serious injury in an accident.

Sunshine Kids Juvenile Products® always recom-

mends utilizing LATCH installation in vehicles

equipped with lower anchors.

To improve safety and performance, this booster seat is

equipped with a unique, one-pull, LATCH system that allows

secure attachment to a vehicle’s lower LATCH anchor locations.

Disengage LATCH connectors from storage slots and lay booster

seat on its side.

1While depressing the cam lock lever,

2pull LATCH connectors away from

the booster seat and extend both

straps all the way.

3Attach both LATCH connectors

to the vehicle anchors, starting with

the connector that is furthest from

you. For ease of use, make sure

open end of hooks face upward

during use.

4While pushing booster against

vehicle seat,

5pull one adjuster strap tight and

then the other.

NOTE: Even with LATCH properly

attached and adjusted, child

seat will still have movement

against the vehicle seat back

and bottom.
