DLS SCANDINAVIA 6/2

IMPEDANCE CURVE

DLS SCANDINAVIA 6/2

FREQUENCY RESPONSE CURVE

DLS SCANDINAVIA 6/2

COMPETITION GRADE SPEAKER

DLS Scandinavia 6/2 is a mid bass driver specially

designed for competition use in a 2-way active or

passive systems. The extreme audio performance

makes it a winner in every Pro installation.

FEATURES AND BENEFITS:

- Extreme audio performance, transparent

and clear sound

- Great imaging and staging capabilities

-

High resolution and dynamics

- Passive filters available for use in 2-way con-

figuration with Scandinavia 1 tweeter.

Part.no: 10-25890

Size of midrange 6,5” / 16,5 cm

Art.no. 10-25806/2

Impedance 4 ohm

Fs / Qts / Vas 42,7 Hz / 0,45 / 15 litres

Rec. amp. power 50 - 200 Watt

Frequency range 50 Hz - 6000 Hz, +- 3 dB

Cone material Carbon fibre

Outer size 165 mm (6,5)

Mounting hole 140 mm (5,5”)

Installation depth

67 mm (2,63”)

Rec. X-over freq. 50 - 4000 Hz

Rec. enclosure 7-9 litres sealed (0,25 - 0,32 cuft)

Rec. cable DLS HQS 2 x 2,5

Rec. line cable DLS HQL

Break-in period

Allow the speakers to play at normal volume for at least

15-20 hours. After this time the performance is correct.

Technical Assistance

For technical assistance ask the shop where the product

was sold or the distributor in your country. You can also

send an e-mail to [email protected]

Information can also be found on our web-site www.dls.se

We follow a policy of continuous advancement in develop-

ment. For this reason all or part of specifications & designs

may be changed without prior notice.

Warranty service

This speaker is covered by warranty, depending on the

conditions in the country where it is sold. If the speaker

is returned for service, please include the original dated

receipt (or a copy) with the product.

DLS Svenska AB

P.O. Box 13029

SE-40251 Göteborg, Sweden

Tel: +46 31 840060

Fax: +46 31 844021

E-mail: [email protected]

www.dls.se

DLS COMPETITION GRADE SPEAKER

SCANDINAVIA 6/2

Baffle installation

It is very important

that the baffle is sta-

ble, but it is just as

important that it is

shaped in a way that

allows the driver to

”breath” backwards,

otherwise there will

be a lack in the dri-

vers bass reproduc-

tion.

DLS Svenska AB 2009-02-04
