Application Note

Control ArtNet Player X 4/8/16/16+ with

ArtNet-DMX MUX16/24

Control ArtNet Player X with ArtNet-DMX MUX 2

General

This application note describes the procedure to control an ArtNet Player X4 / X8 /

X16 / X16+ with control elements (e.g. buttons) via an ArtNet-DMX MUX 16 / 24.

In this application note the 16 inputs of the ArtNet-DMX MUX16 are used for the

direct call of the first 16 programs in an ArtNet Player X16+.

The ArtNet Player X16+ (in the following only called ArtNet Player X) and the

ArtNet-DMX MUX16 (in the following only called ArtNet-DMX MUX) can also be

exchanged for other versions.

According to the ArtNet specification, the IP range 2.0.0.x with the subnet mask

255.0.0.0 is used in this application note. It is also possible to use other IP ranges

such as 192.168.1.x with the corresponding subnet mask 255.255.255.0.

The remote connection between ArtNet Player X and ArtNet-DMX MUX can be

made via ArtNet (Remote via ArtNet) or via DMX (Remote via DMX). Both variants

are described below and cannot be combined with one another.

Follow points 1,2,3,4 for remote via ArtNet and points 1,5,6,7

for remote via DMX.

Conditions

- DMX-Configurator

- ArtNet Player X with Firmware V1.02 or higher

(use the latest firmware)

- ArtNet-DMX MUX with Firmware V1.22 or higher

(use the latest firmware)

Control ArtNet Player X with ArtNet-DMX MUX 3

1. Create programs for ArtNet Player X

The ArtNet Player X requires a MicroSD card for the program which is inserted into

the SD card slot.

The program files must be in the main directory of the SD card and have the name

Pxxx.prg. Here xxx stands for the consecutive three-digit program number starting

with 001.

Create programs

For the ArtNet Player X the program files can be created by the software DMX-

Configurator, alternatively TPM2 or TMP2.NET files can also be used.

The current version of the DMX configurator is available as a free download on our

website.

The procedure for creating the programs can be found in the instructions for the DMX

configurator.

After the programs have been created, the export must be carried out in the

Project→Export→ArtNet Player X menu.

See the instructions for the ArtNet Player X and the DMX configurator for

further details

Control ArtNet Player X with ArtNet-DMX MUX 4

2. Connect ArtNet-Player X with ArtNet-DMX MUX via

ethernet cable via an ethernet switch

(Remote via ArtNet)

ArtNet-DMX MUX

GND

V+

IN1

IN2

IN3

IN4

IN5

IN6

IN8

IN9

IN10

IN11

IN12

IN13

IN14

IN15

IN16

GND

DMX-

DMX+

POWER 12-24V DC

ArtNet Player X

GND

V+

GND

DMX-

DMX+

GND

DMX-

DMX+

Ethernet Switch

IN8

GND

IN7

IN6

IN5

IN4

IN3

IN2

IN1

Control ArtNet Player X with ArtNet-DMX MUX 5

3. Configure ArtNet-Player X for ArtNet remote

(Remote via ArtNet)

The following settings must be made on the ArtNet Player X website:

To control the ArtNet Player X from the ArtNet-DMX MUX, the IP and the ArtNet

Remote option must be activated (Source →ArtNet).

Use a different Net setting for the ArtNet-Remote setting in

order to avoid a data conflict.

(in the example Net = 1)

Here in the example, the

ArtNet player X is configured

to IP 2.0.0.6.

Activate ArtNet Remote and define the target

parameters for Net, SubNet and Port.

Set Personality to Config 1 (3 Ch.).

Control ArtNet Player X with ArtNet-DMX MUX 6

4. Configure ArtNet-DMX MUX

(Remote via ArtNet)

The ArtNet-DMX MUX is set to the IP 2.0.0.5.

Under ArtNet Output Parameters the settings for the IP, Net, Subnet and Universe

must be set so that they match the remote settings of ArtNet Player X.

See also point 3 in this application note

Here in the example the destination IP is 2.0.0.6 corresponding to the IP from

ArtNet-Player X.

If the option Send Data only on change is activated, a data

package is sent one time by activation the input to the ArtNet

Player X.

If several ArtNet-DMX MUX are used to increase the number of

inputs this option must be activated!

Control ArtNet Player X with ArtNet-DMX MUX 7

For the inputs, Button is set as mode and under Parameter for each input is

defined which DMX values should be output:

DMX channel 1 corresponds to the program, DMX channel 2 to the speed (here all

255/100%) and DMX channel 3 to the brightness (here all 255/100%).

See user manual ArtNet Player X

Inputs 1-8:

Control ArtNet Player X with ArtNet-DMX MUX 8

Inputs 9-16:

It is possible to enter the parameter input in short form

„1=0/255/255“ by entering the DMX values sequential with a /

separately.

(Firmware 1.20 or higher necessary)

Control ArtNet Player X with ArtNet-DMX MUX 9

5. Connect DMX-Player X with ArtNet-DMX MUX per DMX

(Remote via DMX)

ArtNet-DMX MUX

GND

V+

IN1

IN2

IN3

IN4

IN5

IN6

IN8

IN9

IN10

IN11

IN12

IN13

IN14

IN15

IN16

GND

DMX-

DMX+

POWER 12-24V DC

ArtNet Player X

GND

V+

GND

DMX-

DMX+

GND

DMX-

DMX+

IN8

GND

IN7

IN6

IN5

IN4

IN3

IN2

IN1

Control ArtNet Player X with ArtNet-DMX MUX 10

6. Configure ArtNet-Player X for DMX remote

(Remote via DMX)

The following settings must be made on the ArtNet Player X website:

To control the ArtNet Player X from the ArtNet-DMX MUX via DMX, the DMX Remote

option must be activated (Source →DMX).

Here in the example the ArtNet

Player X is configured to the IP

2.0.0.6. This information is

necessary but will not be used in

the following.

Activate DMX Remote.

Set Personality to Config 1 (3 Ch.).
