DOD hummer Bedienungsanleitung
Copyright ©2016 DOD Tech
All Rights Reserved
1
Table of Contents
Safety Precautions···················································································· 2
Package Contents ····················································································· 4
Camera Controls······················································································· 5
Installing Your Camera·············································································· 7
Mount Your Camera ················································································15
Getting Started························································································16
Basic Camera Operation ··········································································18
Camera Settings ······················································································24
Playback on PC / DOD Video Player ··························································31
Mobile Viewer / DOD Dashcam App·························································35
Firmware Update ····················································································44
2
Safety Precautions
Product
Do not disassemble, repair, modify your camera or power related accessories.
For warranty service, please contact DOD Tech Support.
Do not adjust camera while riding.
Avoid exposing your camera to extended periods of humidity and/or heat.
Prolonged exposure may reduce the product’s lifespan.
Keep away from fluids may cause fire, electric shocks, or malfunctions.
Avoid installing camera where it may obstruct the driver’s view
Power Cable
Use only the power adapter supplied with your unit.
Other power adapters may create a safety hazard or damage the unit.
Do not use damaged power adapters or cords. If damaged, please disconnect
the power adapter and contact DOD Tech Support for assistance.
3
Safety Precautions
Power Cable
Do not pull, insert, or bend the power cable using excessive force.
Do not operate or handle power cable with wet hands.
Battery
Keep the device away from heaters or other hot objects.
Store the camera at lower temperatures to reduce the rate of self-discharge
and preserves the initial energy stored in the battery. The battery in the device
self discharges over a period of time naturally whether the battery is used or
not.
Charge the unit for 5 minutes if you are unable to turn on the camera.
4
Package Contents
●
1
●
2
●
3
DOD Hummer User Manual
Hardwiring Cable
(Mini & Low profile fuse adaptor)
●
4
●
5
●
6
Waterproof Power Charger Handlebar Mount DOD Player Installation CD
Note: Supplied accessories may vary by region.
5
Camera Controls
●
1Power/Mode[ / ]
Press and hold to turn on/off the unit.
Press to switch between 3 Modes：
Video Recording-Starts/Stops recording.
Photo-Takes a photo.
Video Playback-Plays/Pauses video.
6
Camera Controls
●
2Record/Shutter/Confirm[ /OK]
Video Recording-Starts/Stops recording.
Photo-Takes a photo.
Video Playback-Plays/Pauses video.
Settings-Selects highlighted item.
●
3Menu/SOS Emergency File Lock
[ / ]
Access the settings menu.
Press while recording videos to lock the
current file from being overwritten.
Note: Cannot access menu while recording.
●
4Arrow Key [▲]/[ /▼]
Used to navigate through menus and
select videos for playback.
During Standby mode, press[ /▼]to
turn on the Wi-Fi.
●
5Power LED
Steady Blue- Charging.
●
6Recording Status
Flashing Red- Recording.
Steady Red- Standby mode.
●
71.5”LCD Screen
●
8Micro SD Slot
●
9USB Port
●
10 Reset Button
Press to force the device to reboot.
If camera freezes, use a small pin to press
button.
7
8
Installing Your Camera
Waterproof PowerCharger
Cigarette Plug Adaptor
Rubber Grommet
Connector Cable
Dust Cover
