DOLPHIN HOT AIR
HAND DRYER
User Manual
Please read carefully before use
2 BC2201SS User Manual www.dolphinsolutions.co.uk
Operating VoltageWarm Air Volume OutputWarm Air Temp OutputMotor TypeMotor Thermal ProtectionHeater ElementHeater Thermal ProtectionDrying TimeCircuit OperationSensor RangeTime ProtectionTime DurationCover TypeCover FinishNet WeightShipping WeightUnit Size230-240Vac,50/60Hz,2.0-2.4kW314.5m³/h (185 CFM)60°C at ambient T=20°C ¼ HP, 7500 rpm, Brush Type, 200W, Dual Ball BearingsAuto Resetting Thermostat turns unit off at 105°C (221°F)2200WAuto Resetting Thermostat turns unit off at 87°C (189°F)Thermal fuse cuts unit off at 141°C (286°F)Less than 15 secondsInfrared Automatic, self adjustingAdjustable;standard 18 cm± 2 cm1 minutes auto shut off2 seconds delayed turn off after last sensor readStainless steel, 1.5 mm thickStain finished4.5kg [9.9lbs]5.5kg [12.1lbs]W x H x D [254mm x 326mm x 120mm]Operating Instructions and Parts Manual (Automatic) Surface Mount 254 mm (10")326 mm (12-7/8")
AUTOMATIC HAND DRYER
120 mm (4-3/4")
3 BC2201SS User Manual www.dolphinsolutions.co.uk
General safety information:-- NOTE: Do not install dryer over washbasin -- Disconnect power at theservice breaker before installing or servicing. NOT FOR HOUSEHOLD USE - MAY CAUSE BURNS. " IMPROPRE A L'USAGE DOMESTIQUE - PUET OCCASIONNER." This product is intended for installation by a qualified service person. Use 1.5 mm² solid conductor for wiring. All units must be supplied with a 3-wire service. The ground wire must be connected to the dryer's backplate. Failure to properly ground unit could result in severe electrical shock and/or death.InstallationType Y attachmentIf the power supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similar qualified person in order to avoid a hazard.Means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules. 1. Make sure power supply breaker is switched off. Installation must be carried out in accordance with the current edition of the local wiring regulations code having jurisdiction. Installation should be performed only by a qualified electrician.2. Place template against wall at desired height (see mounting height recommendations) and mark locations of 4 mounting holes and wire service entry at knockout (KO) location. Note: For two or more dryers, dryers should be no closer than 24 inches (610 mm) on center. 3. Remove and retain 2 cover screws and cover.4. Connect supply wires to terminal block where indicated and connect ground wire to base plate with ground screw A. Connect the live wire (colored red or black or brown ) to the terminal block marked "L". B. Connect the neutral wire (colored white or blue) to the terminal block marked "N". C. Connect the ground wire (colored green or green and yellow) to the green screw marked " "). Note that colors of live and neutral wires depend on voltage of supply service. 5. Replace cover. Do not over-tighten screws. Connections:
4 BC2201SS User Manual www.dolphinsolutions.co.uk
OperationNo-touch operationShake excess water from hands.Place hands under the outlet to start operation.Rub hands lightly and rapidly.Stops automatically after hands are removed.Periodic cleaning of the unit is recommended to ensure optimum performance.Cleaning and MaintenanceDisconnect the electrical supply.Remove the two cover-mounting screws.Remove the cover.Clean all dust lint from the interior of the dryer.Wipe the cover with a damp cloth and mild cleaning solution. Do not Soak. Never use abrasives to clean the cover.Replace the cover. Do not over tighten the screws.Recommended mounting heights- from bottom edge of dryer above finished floor (AFF)MenWomenChildren 4-7 yearsChildren 8-10 yearsChildren 11-13 yearsChildren 14-16 yearsHandicaped(40")(38")(32")(34")(36")(38")(34") 1000 mm960 mm812 mm860 mm910 mm960 mm860 mm‘Unit should be mounted to give no less than 300mm clearance from the bottom of the unit to the nearest surface below’LIMITED THREE-YEAR WARRANTYPlease see our website by following this link: http://www.dolphindispensers.co.uk/
o
r contact our customer service team on 01424 202224 for more details.Warranty
LIMTED FIVE YEAR WARRANTY
5 BC2201SS User Manual www.dolphinsolutions.co.uk
Sensing Range AdjustmentThe exact sensing range was pre-set by maker.You’d better not change it.If you want to modify the Sensing Range, please proceed the following procedures.(And please also refer to TIMER ASSEMBLY DRAWING (-) as follows)First of all, cut off the power supply, please.Remove the ENCLOSURE / HOUSING of hand dryer.Remove the outer case of TIMER ASSEMBLY.Find the SENSING RANGE ADJUSTER inside the TIMER ASSEMBLY anduse tiny screw driver - type or + type to turn round the SENSING RANG ADJUSTER:(A) Clock-------------- Lengthen the sensing range (+)(B) Counterclockwise----- Shorten the sensing range (-)" "" "Lengthen the sensing range (+)Shorten the sensing range (-)
Diagram1234567891011121314171516
6 BC2201SS User Manual www.dolphinsolutions.co.uk
7 BC2201SS User Manual www.dolphinsolutions.co.uk
1234567891011121314151617Satin Finished - Stainless Steel #4Security Hex ScrewSecurity Hex WrenchBrush MotorBlowerThermostatBlower Housing AHeater ElementBlower Housing BMotor Bracket AssemblySensor Module + Circuit Board ModuleGrounding ScrewGrounding WasherTerminal BlockBase PlateCable ClampNylon BushingReferenceNumberQty.Description12111111111111111
Dolphin Solutions
Southpoint, Compass Park, Bodiam, Robertsbridge TN32 5BS
Tel: 01424 202224
Fax: 01424 205200
www: dolphinsolutions.co.uk
