Dometic SI 600 acs Bedienungsanleitung

SI 600 acs – 12V/24V

Pure Sine Wave Inverter

230Vac

from

12Vdc / 24Vdc source

Integrated automatic 230Vac transfer switch -

acs

User’s Manual / Benutzerhandbuch / Manuel de l'utilisateur

Användarhandbok / Manuale d'uso

/ Manual del usuario

Welcome to the Dometic world

Dometic Pure Sine wave Inverters – A sign of comfort

The SI 600acs Inverter is designed as a stand –alone power inverter with an

AC transfer switch feature with a bypass for an AC utility connection when

available. This Inverter is extremely suitable for RV, Commercial Vehicle,

Marine and Emergency appliances.

When utility AC power is cut off, the transfer relay is de-energized and the load

is automatically transferred to the SI 600acs output and driven by your 12 or 24

Vdc source. Once the AC utility is restored, the relay is energized and the load

is automatically reconnected to the AC utility.

You have made a wonderful choice to use Inverters from Dometic. Feel free to

contact our dealers for more information or other recommendations within

mobile power supply.

Best regards,

Dometic

Contents

Important Safety Instructions .............................................................1

1.1

General Safety Precautions........................................................1

1.2

Precautions When Working with Batteries..................................1

Basic Descriptions .............................................................................2

2.1

Mechanical drawings ..................................................................2

2.2

The Front panel interface............................................................3

2.3

The rear panel interface..............................................................4

2.4

The Remote Control panel..........................................................5

Functional Characteristics..................................................................6

3.1

General Information....................................................................6

3.2

Features .....................................................................................7

3.3

Electrical Performance................................................................8

Installation..........................................................................................9

4.1

Where to install...........................................................................9

4.2

AC Safety Grounding..................................................................10

4.3

Ground Fault Circuit Interrupters (GFCI):....................................10

4.4

Making DC Wiring Connections..................................................11

Operation...........................................................................................13

5.1

Controls and indicators:..............................................................13

5.2

System Status LEDs. ..................................................................14

Information.........................................................................................15

6.1

Troubleshooting..........................................................................15

6.2

Maintenance...............................................................................16

6.3

Warranty.....................................................................................16

reproduced or copied without the express permission of the owner.

1 Important Safety Instructions

WARNING !

Before you install and use your Dometic SI 600acs

Inverter, be sure to read these safety instructions.

1.1 General Safety Precautions

1-1-1. Do not expose the SI 600acs inverter to rain, snow, spray, bilge or dust.

To reduce risk of hazard, do not cover or obstruct the ventilation

openings. Do not install the SI 600acs Inverter in a zero-clearance

compartment. Overheating may result.

1-1-2. To avoid the risk of fire or electric shock, make sure that existing wiring

is in good electrical condition and that wire size is not under sized. Do

not operate the SI 600acs inverter with damaged or substandard wiring.

1-1-3.This equipment contains components which can produce arcs or sparks.

To prevent fire or explosion do not install in compartments containing

batteries or flammable materials or in locations which require ignition

protected equipment. This includes any space containing

gasoline-powered machinery, fuel tanks, or joints, fittings, or other

connections between components of the fuel system.

1.2 Precautions When Working with Batteries

1-2-1. If battery acid contacts skin or clothing, wash immediately with soap and

water. If acid enters eye, immediately flood eye with running cold water

for at least 20 minutes and seek medical attention at once.

1-2-2. Never smoke or allow a spark or flame in vicinity of battery or engine.

1-2-3. Do not drop a metal tool on the battery. The resulting spark or

short-circuit on the battery or other electrical part may cause an

explosion.

1-2-4. Remove personal metal items such as rings, bracelets, necklaces, and

watches when working with a lead-acid battery.

A lead-acid battery produces a short-circuit current high enough to weld

a ring or other metal, causing a severe burn.

2 Basic Descriptions

2.1 Mechanical drawings

2.2 The Front panel interface

2-2-1. Power ON / OFF / REMOTE switch:If you use the optional

remote control unit, put the “on/off “ switch to “remote”.

2-2-2. 230Vac input Circuit Breaker:The 7Amp circuit breaker protects

the model from overload. When an overload condition exists, the

circuit breaker stops output AC grid power. To reset, push the

circuit breaker switch and then the model will be back to a

normal operation. The source fault should be corrected prior

reset.

2-2-3. Remote port: Connect RJ-11 wiring with remote control unit.

2-2-4. Battery terminals:

Connect 12V/24V batteries or other 12V/24V power sources.

2-2-5. Chassis ground: Connect the inverter chassis ground terminal to

earth.

2.3 The rear panel interface

2-3-1. Ventilation:

Do not obstruct, allow at least 2-3 inches/ 50-75mm of clearance

for airflow.

2-3-2. 230V AC input: (source)

If available and desired, plug into 230Vac source directly.

2.4 The Remote Control panel



Inverting

R.O.F Acting

Ignition

 

Blinking

Solid Red

ON/OFF

PUSH

Inverter Status

The Remote control is a basic ON/ OFF remote control. The control has

features which disable and override the ON/OFF function such as:

Ignition Lockout function

This will automatically turn the Inverter OFF when the auxiliary input

wiring receives a continuous 12V/24V signal.

R.O.F (Remote override function)

This will automatically turn the Inverter ON when the auxiliary input

wiring receives a continuous 12V/24V signal. (The auxiliary input wire

must be placed with a 12/24 Volt fuse (0.5A))

The internal pin jumper that is placed inside the remote control

stipulates a choice, either the Ignition lockout or R.O.F function:

Pin jumper “Short” - Ignition lockout function.

Pin jumper “Open”

- R.O.F.

LED Signals

• The LED glows steadily red when the Inverter is on.

• The LED blinks fast when the R.O.F function is enabled.

• The LED blinks slowly when the Ignition Lockout function is

enabled.

Connect RJ-11 wire with the remote port in front of panel of the Inverter.

3 Functional Characteristics

3.1 General Information

The SI 600acs Inverter is designed as a stand –alone power inverter

with an AC transfer switch feature which is suitable for RV, marine and

emergency appliances.

When utility AC power is cut off, the transfer relay is de-energized and

the load is automatically transferred to the SI 600acs output. Once the

AC utility is restored, the relay is energized and the load is automatically

reconnected to the AC utility.

The SI 600acs is also GFCI compliant. This provides with the GFCI

safety receptacle easier use of appliances.

Please read all instructions and cautionary marking on this manual

before using SI 600acs series.

3.2 Features

Product:

600W continuous output with 800W power surge for electronic

appliances.

Pure sine wave output (THD < 3%) to operate higher-end electronic

equipment.

Built in 7A rating AC transfer switch with plug-in socket that is easy to

maintain.

Speed up transfer time and synchronized operation with the AC

source at all times which allows the transfer to be interruption-free

for sensitive equipment.

Built in advance microprocessor for user friendly interface and

operation.

Optional smart remote control.

3 tri-color LED indicators display all operation status.

UL 458 approval and FCC class B.

Protection:

Battery over- and under voltage protections.

Over temperature protection.

Over load protection.

Short Circuit protection.

Ground fault protection by GFCI receptacle.

Reverse polarity protection.

ROF (remote override function) or Ignition Lockout function option.

AC circuit breaker (7Amp).
