dormakaba ED50 Owner's Manual Chapters 1 and 2
. Owner's Manual
This Owner's Manual applies to the ED low energy
automatic swing door system.
. Manual storage
This document must be kept in a secure place, and
accessible for reference as required.
If the door system should be transferred to another
facility, insure that this document is transferred as well.
. dormakaba.com website
Manuals are available for review, download, and printing
on dormakaba.com/us website.
. Dimensions
Unless otherwise specified, all dimensions are given in
inches (“).
. Symbols used in this manual
WARNING
This symbol warns of hazards which could result
in personal injury or threat to health.
General
information
To our customers
We are pleased that a dormakaba USA, Inc.
ED low energy automatic swing door system has
been selected for this installation.
dormakaba USA, Inc. designed, tested and built the
system to provide many years of service.
The purpose of this manual is to familiarize you with
your ED low energy automatic swing door system.
It is essential that you "know your system" and that you
recognize the importance of maintaining your door
system in compliance with industry standards for safety.
It is your responsibility as owner and caretaker of the
equipment, to inspect the operation of your door system
on a daily basis as outlined in Chapter , Daily Safety
Check Procedures to insure that it is safe for use by your
customers and employees.
WARNING
Should the door fail to operate as prescribed
in the Safety information checklist or at any
other time for any reason, do not attempt to
repair or adjust the ED low energy
automatic swing door system!
Call your local authorized dormakaba USA, Inc.
distributor for repair. The distributor's AAADM certified
technicians are trained to service the ED automatic
swing door system using the dormakaba USA, Inc.
Installation and Service Manuals, and in accordance
with applicable industry standards.
. Service availability
dormakaba USA, Inc. has a nationwide network of
authorized distributors for sales, installation and service
of its products.
. Compliance with industry standards for safety
Your ED automatic swing door system was designed
to the latest operating and safety standards. In order to
insure the continued safe operation of the door, it is
important that:
• Proper decals and labels be applied and maintained
on your doors (Chapter ).
• If decals and labels have been removed, or cannot be
read, contact your local authorized dormakaba USA,
Inc. distributor for replacement decals or labels.
Fig.1.1 ED50 header
Fig.1.2 ED50 operator
. ED header and operator
